双酚S对斑马鱼幼鱼早期视觉发育的影响
Effects of Bisphenol S on Early Visual Development of Zebrafish Larvae
-
摘要: 塑料添加剂双酚S （bisphenol S，BPS）广泛应用于多种工业产品和日用品的生产，在环境及人体样本中频繁检出，其视觉毒性近年来备受关注。本研究采用1、10、100、1 000 μg·L-1 BPS暴露斑马鱼受精卵15 d，通过石蜡切片分析视网膜结构，并检测视黄酸代谢基因和视蛋白基因表达量变化，探究了BPS对斑马鱼幼鱼早期视觉发育的影响。结果表明，10、100、1 000 μg·L-1 BPS暴露抑制了其视黄酸合成相关基因的表达，并下调了感光细胞发育相关基因神经视网膜亮氨酸拉链基因的表达量；100、1 000 μg·L-1 BPS暴露组斑马鱼幼鱼多种视蛋白基因（紫外敏感视蛋白、蓝光敏感视蛋白和绿光敏感视蛋白）表达量增加；苏木精-伊红染色结果显示不同浓度BPS暴露会导致斑马鱼幼鱼视网膜及视网膜核层中神经节细胞层、内核层和外核层厚度显著降低；且对体长、头宽与眼睛直径数据的比较及皮尔逊相关性分析表明，BPS诱导15 dpf的斑马鱼幼鱼出现小眼现象。综上所述，BPS可能通过干扰视黄酸代谢影响斑马鱼早期视网膜发育，其对视觉系统的潜在健康风险需引起人们的广泛关注。Abstract: The plastic additive bisphenol S (BPS) has been widely used in various industrial and household products, and frequently detected in environmental and human samples. For the past few years, increasing concern has been focused on the visual toxicity of BPS. Here, after zebrafish embryos were exposed to BPS (1, 10, 100, and 1 000 μg·L-1) for 15 days, retinal histology and expression of genes involved in retinoic acid metabolism and opsin genes were examined to investigate the effect of BPS on the early visual development of larval zebrafish. The results showed that exposure to 10, 100 and 1 000 μg·L-1 BPS inhibited the expression of genes related to retinoic acid synthesis and the expression of neural retina leucine zipper gene (nrl) that related to photoreceptor cell development, while the expression of opsin genes (zfblue, zfuv and zfgr) was increased in 100 μg·L-1 and 1 000 μg·L-1 BPS groups. The results of hematoxylin-eosin staining showed that the thickness of the retina, the ganglion cell layer, the inner nuclear layer, and the outer nuclear layer was significantly decreased by different doses of BPS. In addition, BPS also induced small eyes in 15-dpf zebrafish larvae, based on Pearson correlation analysis of the body length, the head width, and the eye diameter. In summary, our study suggested that BPS probably affected early retinal development of zebrafish by interfering with retinoic acid metabolism, and its potential health risk to the visual system should arouse extensive attention.
-
Key words:
- bisphenol S /
- zebrafish /
- visual toxicity /
- retinoic acid
-
-
Yan Z Y, Liu Y H, Yan K, et al. Bisphenol analogues in surface water and sediment from the shallow Chinese freshwater lakes:Occurrence, distribution, source apportionment, and ecological and human health risk [J]. Chemosphere, 2017, 184:318-328 Jin H B, Zhu L Y. Occurrence and partitioning of bisphenol analogues in water and sediment from Liaohe River Basin and Taihu Lake, China [J]. Water Research, 2016, 103:343-351 Wu L H, Zhang X M, Wang F, et al. Occurrence of bisphenol S in the environment and implications for human exposure:A short review [J]. The Science of the Total Environment, 2018, 615:87-98 Liao C Y, Liu F, Alomirah H, et al. Bisphenol S in urine from the United States and seven Asian countries:Occurrence and human exposures [J]. Environmental Science & Technology, 2012, 46(12):6860-6866 Rochester J R, Bolden A L. Bisphenol S and F:A systematic review and comparison of the hormonal activity of bisphenol A substitutes [J]. Environmental Health Perspectives, 2015, 123(7):643-650 Huang C, Wu L H, Liu G Q, et al. Occurrence and ecological risk assessment of eight endocrine-disrupting chemicals in urban river water and sediments of South China [J]. Archives of Environmental Contamination and Toxicology, 2018, 75(2):224-235 Li A J, Zhuang T F, Shi W, et al. Serum concentration of bisphenol analogues in pregnant women in China [J]. The Science of the Total Environment, 2020, 707:136100 Liu Y H, Yan Z Y, Zhang Q, et al. Urinary levels, composition profile and cumulative risk of bisphenols in preschool-aged children from Nanjing suburb, China [J]. Ecotoxicology and Environmental Safety, 2019, 172:444-450 Fox D A. Retinal and visual system:Occupational and environmental toxicology [J]. Handbook of Clinical Neurology, 2015, 131:325-340 Maurya M, Bora K, Blomfield A K, et al. Oxidative stress in retinal pigment epithelium degeneration:From pathogenesis to therapeutic targets in dry age-related macular degeneration [J]. Neural Regeneration Research, 2023, 18(10):2173-2181 Li M H, Yang T, Gao L X, et al. An inadvertent issue of human retina exposure to endocrine disrupting chemicals:A safety assessment [J]. Chemosphere, 2021, 264(Pt 1):128484 Pannetier P, Poulsen R, Gölz L, et al. Reversibility of thyroid hormone system-disrupting effects on eye and thyroid follicle development in zebrafish (Danio rerio) embryos [J]. Environmental Toxicology and Chemistry, 2023, 42(6):1276-1292 Liu W M, Zhang X N, Wei P H, et al. Long-term exposure to bisphenol S damages the visual system and reduces the tracking capability of male zebrafish (Danio rerio) [J]. Journal of Applied Toxicology, 2018, 38(2):248-258 Wei S H, Qiu L G, Ru S G, et al. Bisphenol S disrupts opsins gene expression and impairs the light-sensing function via antagonizing TH-TRβ signaling pathway in zebrafish larvae [J]. Food and Chemical Toxicology:An International Journal Published for the British Industrial Biological Research Association, 2023, 172:113588 Lobo G P, Pauer G, Lipschutz J H, et al. The retinol-binding protein receptor 2(Rbpr2) is required for photoreceptor survival and visual function in the zebrafish [J]. Advances in Experimental Medicine and Biology, 2018, 1074:569-576 Prabhudesai S N, Cameron D A, Stenkamp D L. Targeted effects of retinoic acid signaling upon photoreceptor development in zebrafish [J]. Developmental Biology, 2005, 287(1):157-167 Sanjurjo-Soriano C, Erkilic N, Damodar K, et al. Retinoic acid delays initial photoreceptor differentiation and results in a highly structured mature retinal organoid [J]. Stem Cell Research & Therapy, 2022, 13(1):478 Cho K, Lee S M, Heo J, et al. Retinaldehyde dehydrogenase inhibition-related adverse outcome pathway:Potential risk of retinoic acid synthesis inhibition during embryogenesis [J]. Toxins, 2021, 13(11):739 Fares-Taie L, Gerber S, Chassaing N, et al. ALDH1A3 mutations cause recessive anophthalmia and microphthalmia [J]. American Journal of Human Genetics, 2013, 92(2):265-270 Esteban J, Serrano-Maciá M, Sánchez-Pérez I, et al. In utero exposure to bisphenol-A disrupts key elements of retinoid system in male mice offspring [J]. Food and Chemical Toxicology:An International Journal Published for the British Industrial Biological Research Association, 2019, 126:142-151 Huang L X, Wang C G, Zhang Y Y, et al. Phenanthrene causes ocular developmental toxicity in zebrafish embryos and the possible mechanisms involved [J]. Journal of Hazardous Materials, 2013, 261:172-180 Qiu L G, Wei S H, Yang Y X, et al. Mechanism of bisphenol S exposure on color sensitivity of zebrafish larvae [J]. Environmental Pollution, 2023, 316(Pt 2):120670 Bilotta J, Saszik S. The zebrafish as a model visual system [J]. International Journal of Developmental Neuroscience, 2001, 19(7):621-629 Amann P M, Eichmüller S B, Schmidt J, et al. Regulation of gene expression by retinoids [J]. Current Medicinal Chemistry, 2011, 18(9):1405-1412 Thompson B, Katsanis N, Apostolopoulos N, et al. Genetics and functions of the retinoic acid pathway, with special emphasis on the eye [J]. Human Genomics, 2019, 13(1):61 Begemann G, Schilling T F, Rauch G J, et al. The zebrafish neckless mutation reveals a requirement for raldh2 in mesodermal signals that pattern the hindbrain [J]. Development, 2001, 128(16):3081-3094 Dobbs-McAuliffe B, Zhao Q S, Linney E. Feedback mechanisms regulate retinoic acid production and degradation in the zebrafish embryo [J]. Mechanisms of Development, 2004, 121(4):339-350 Wang C, Kane M A, Napoli J L. Multipleretinol and retinal dehydrogenases catalyze all-trans-retinoic acid biosynthesis in astrocytes [J]. Journal of Biological Chemistry, 2011, 286(8):6542-6553 Sharma M K, Saxena V, Liu R Z, et al. Differential expression of the duplicated cellular retinoic acid-binding protein 2 genes (crabp2a and crabp2b) during zebrafish embryonic development [J]. Gene Expression Patterns, 2005, 5(3):371-379 Nagpal I, Wei L N. All-trans retinoic acid as a versatile cytosolic signal modulator mediated by CRABP1[J]. International Journal of Molecular Sciences, 2019, 20(15):3610 Novák J, Beníšek M, Hilscherová K. Disruption of retinoid transport, metabolism and signaling by environmental pollutants [J]. Environment International, 2008, 34(6):898-913 Isla-Magrané H, Zufiaurre-Seijo M, García-Arumí J, et al. All-trans retinoic acid modulates pigmentation, neuroretinal maturation, and corneal transparency in human multiocular organoids [J]. Stem Cell Research & Therapy, 2022, 13(1):376 Chen X F, Lin Z C, Qi Z H, et al. Effects of pollutant toxicity on the eyes of aquatic life monitored by visual dysfunction in zebrafish:A review [J]. Environmental Chemistry Letters, 2023, 21(2):1177-1201 Zhang S Y, Gan X F, Shen B G, et al. 6PPD and its metabolite 6PPDQ induce different developmental toxicities and phenotypes in embryonic zebrafish [J]. Journal of Hazardous Materials, 2023, 455:131601 Chinen A, Hamaoka T, Yamada Y, et al. Gene duplication and spectral diversification of cone visual pigments of zebrafish [J]. Genetics, 2003, 163(2):663-675 Chen L G, Huang Y B, Huang C J, et al. Acute exposure to DE-71 causes alterations in visual behavior in zebrafish larvae [J]. Environmental Toxicology and Chemistry, 2013, 32(6):1370-1375 Garelli A, Rotstein N P, Politi L E. Docosahexaenoic acid promotes photoreceptor differentiation without altering Crx expression [J]. Investigative Ophthalmology & Visual Science, 2006, 47(7):3017-3027 An M J, Lee H M, Kim C H, et al. c-Jun N-terminal kinase 1(JNK1) phosphorylates OTX2 transcription factor that regulates early retinal development [J]. Genes & Genomics, 2023, 45(4):429-435 Oel A P, Neil G J, Dong E M, et al. Nrl is dispensable for specification of rod photoreceptors in adult zebrafish despite its deeply conserved requirement earlier in ontogeny [J]. iScience, 2020, 23(12):101805 张瑞祺, 郝月月, 宋银都, 等. 鳜视觉和侧线感觉调控捕食行为的动态观察[J]. 中国水产科学, 2020, 27(10):1136-1144 Zhang R Q, Hao Y Y, Song Y D, et al. Predation behavior of mandarin fish (Siniperca chuatsi) regulated by visual and lateral line sensory [J]. Journal of Fishery Sciences of China, 2020, 27(10):1136-1144(in Chinese)
Kamermans M, Hawryshyn C. Teleost polarization vision:How it might work and what it might be good for [J]. Philosophical Transactions of the Royal Society of London Series B, Biological Sciences, 2011, 366(1565):742-756 Mussen T D, Cech J J Jr. The roles of vision and the lateral-line system in Sacramento splittail's fish-screen avoidance behaviors:Evaluating vibrating screens as potential fish deterrents [J]. Environmental Biology of Fishes, 2013, 96(8):971-980 Camargo-dos-Santos B, Gonçalves B B, Bellot M S, et al. Water turbidity-induced alterations in coloration and courtship behavior of male guppies (Poecilia reticulata) [J]. Acta Ethologica, 2021, 24(2):127-136 -
