安莹, 李云辉, 李震, 吴志超. 改良型AO法组合工艺中有机物的三维荧光分析[J]. 环境工程学报, 2013, 7(1): 159-163.
引用本文: 安莹, 李云辉, 李震, 吴志超. 改良型AO法组合工艺中有机物的三维荧光分析[J]. 环境工程学报, 2013, 7(1): 159-163.
shu
An Ying, Li Yunhui, Li Zhen, Wu Zhichao. Analysis of EEM fluorescence spectra of dissolved organic matter in improved AO combined process[J]. Chinese Journal of Environmental Engineering, 2013, 7(1): 159-163.
Citation: An Ying, Li Yunhui, Li Zhen, Wu Zhichao. Analysis of EEM fluorescence spectra of dissolved organic matter in improved AO combined process[J]. Chinese Journal of Environmental Engineering, 2013, 7(1): 159-163.
shu

改良型AO法组合工艺中有机物的三维荧光分析

  • 1.

    上海电力学院环境与化学工程学院,上海 200090

  • 2.

    上海竹园第二污水处理厂,上海 200137

  • 3.

    同济大学环境科学与工程学院污染控制与资源化研究国家重点实验室,上海 200092

  • 基金项目:

    上海市科学技术委员会科研计划项目(11231200400)

    上海市高校青年教师培养资助计划(sdl11002)

    上海电力学院科研基金项目

    上海竹园第二污水处理厂科研基金项目

  • 中图分类号: X703.1

Analysis of EEM fluorescence spectra of dissolved organic matter in improved AO combined process

  • 1.

    School of Environmental and Chemical Engineering, Shanghai University of Electric Power, Shanghai 200090, China

  • 2.

    Zhuyuan Second Wastewater Treatment Plant, Shanghai 200137, China

  • 3.

    State Key Laboratory of Pollution Control and Resource Reuse, School of Environmental Science and Engineering, Tongji University, Shanghai 200092, China

  • Fund Project:

  • 摘要: 采用三维荧光(EEM)光谱技术,对上海竹园第二污水处理厂改良型AO法组合工艺运行过程中的各种溶解性有机物(DOM)进行分析,并对比研究传统好氧活性污泥法曝气池出水和A/O脱氮工艺硝化池出水DOM 的 EEM 光谱的迁移变化特性。结果表明,各种DOM中主要的荧光物质有类蛋白质(荧光峰A和B)及类腐殖质(荧光峰C),经改良型AO法组合工艺处理后,荧光峰的强度降低了14%~60%,同时类蛋白质和腐殖质的结构也发生了变化;腐殖酸溯源表明DOM中的腐殖酸以微生物代谢产生的带有荧光基团的腐殖酸类为主。
    Abstract: Through excitation-emission matrix (EEM) fluorescence spectra analysis, the characteristics of dissolved organic matter (DOM) in the improved AO combined process of Zhuyuan Second Wastewater Treatment Plant were studied. Meanwhile, the comparison of DOM between traditional aeration activated sludge process and anoxic/aerobic process was also carried out. The results indicated that the fluorescent components in DOM were mainly protein-like (Peak A and Peak B) and humic-like fluorophores (Peak C). The fluorescent intensity was reduced by 14%~60% and the structure of protein-like fluorophores and humic-like fluorophores was changed during the treatment process. Humic acid produced by microbial metabolism with fluorescence-based groups was primary source of humic acid in DOM.
  • 加载中
  • [1] 郝瑞霞,曹可心,邓亦文. 城市污水处理过程中有机污染物三维荧光特性的变化规律. 分析测试学报,2007,26(6):789-792 Hao Ruixia, Cao Kexin, Deng Yiwen. The variation trend of three-dimensional characteristic fluorescence of dissolved organic matter in the wastewater treatment process. Journal of Instrumental Analysis, 2007, 26(6): 789-792 (in Chinese)
    [2] Barker D. J., Stuckey D. C. A review of soluble microbial products (SMP) in wastewater treatment systems. Water Research, 1999, 33(14): 3063-3082
    [3] Wang Z.W., Wu Z.C., Tang S.J. Characterization of dissolved organic matter in a submerged membrane bioreactor by using three-dimensional excitation and emission matrix fluorescence spectroscopy. Water Research, 2009, 43(6): 1533-1540
    [4] 陈茂福,吴静,律严励,等. 城市污水的三维荧光指纹特征. 光学学报,2008,28(3):578-582 Chen Maofu, Wu Jing, Lü Yanli, et al. Fluorescence properties of municipal wastewater. Acta Optica Sinica, 2008, 28(3): 578-582(in Chinese)
    [5] 张军政,杨谦,席北斗,等. 垃圾填埋渗滤液溶解性有机物组分的光谱学特性研究. 光谱学与光谱分析,2008,28(11):2583-2587 Zhang Junzheng, Yang Qian, Xi Beidou, et al. Study on spectral characteristic of dissolved organic matter fractions extracted from municipal solid waste landfill leachate. Spectroscopy and Spectral Analysis, 2008, 28(11): 2583-2587(in Chinese)
    [6] 唐书娟,王志伟,吴志超,等. 膜-生物反应器中溶解性有机物的三维荧光分析. 中国环境科学,2009,29 (3):290-295 Tang Shujuan, Wang Zhiwei1, Wu Zhichao, et al. Analysis of EEM fluorescence spectra of dissolved organic matter in membrane bioreactor. China Environmental Science, 2009, 29(3): 290-295(in Chinese)
    [7] Baker A. Fluorescence excitation-emission matrix characterization of some wastewater-impacted rivers. Environmental Science & Technology, 2001, 35 (5): 948-953
    [8] Baker A. Spectrophotometric discrimination of river dissolved organic matter. Hydrological Process, 2002, 16 (16): 3203-3213
    [9] Sheng G. P., Yu H. Q. Characterization of extracellular polymeric substances of aerobic and anaerobic sludge using three-dimensional excitation and emission matrix fluorescence spectroscopy. Water Research, 2006, 40 (6): 1233-1239
    [10] 李卫华,盛国平,王志刚,等. 废水生物处理反应器出水的三维荧光光谱解析. 中国科学技术大学学报,2008,38 (6):601-608 Li Weihua, Sheng Guoping, Wang Zhigang, et al. Analysis of EEM fluorescence spectra of effluents from ioreactors. Journal of University of Science and Technology of China, 2008, 38(6): 601-608(in Chinese)
    [11] 何磊,王志伟,吴志超,等. 膜-生物反应器处理餐饮废水过程中溶解性有机物的迁移变化特性研究. 环境污染与防治,2011,33(1):20-26 He Lei, Wang Zhiwei, Wu Zhichao, et al.Research on the transformation and variations of dissolved organic matter’s properties in MBR used for restaurant wastewater treatment. Environmental Pollution and Control, 2011, 33(1):20-26(in Chinese)
    [12] 张自杰. 排水工程下册(第四版). 北京:中国建筑工业出版社,2000
    [13] 王丽莎,胡洪营,藤江幸一. 污水氯和二氧化氯消毒过程中溶解性有机物变化的三维荧光光谱解析. 环境科学,2007,28(7):1524-1527 Wang Lisha, Hu Hongying, Koichi Fujie. Characterization of the change in DOM during wastewater chlorine and chlorine dioxide disinfections by 3DEEM. Environmental Science, 2007, 28(7):1524-1527 (in Chinese)
    [14] McKnight D. M., Boyer E. W., Westerhoff P. K. Spectrofluorometric characterization of dissolved organic matter for indication of precursor organic material and aromaticity. Limnology and Oceanography, 2001, 46 (1): 38-48
    [15] 吉芳英,谢志刚,黄鹤,等. 垃圾渗滤液处理工艺中有机污染物的三维荧光光谱. 环境工程学报,2009,3(10):1783-1788 Ji Fangying, Xie Zhigang, HuangHe, et al. Three dimensional excitation-emission fluorescence spectra of dissolved organic matter in landfill leachates treatment process. Chinese Journal of Environmental Engineering, 2009, 3(10): 1783-1788 (in Chinese)
