云南省树皮样品中多环芳烃和有机氯农药的浓度分布及来源解析
Distribution and source analysis of polycyclic aromatic hydrocarbons (PAHs) and organochlorine pesticides (OCPs) in the tree bark from Yunnan Province
-
摘要: 2012年8月于云南省采集了16个树皮样品，分析了其中多环芳烃和有机氯农药（包括六六六和滴滴涕）的浓度水平和分布特征.树皮中∑16PAH的浓度范围为317-1194 ng·g-1，平均值为639 ng·g-1；研究区域树皮中∑4HCH和∑6DDT的浓度分别为为0.10-3.86 ng·g-1干重（平均值为1.10 ng·g-1干重）和0.78-7.29 ng·g-1干重（平均值为3.32 ng·g-1干重），PAHs浓度是藏东南林芝地区的2-3倍，而有机氯农药的浓度低于藏东南林芝地区.树皮中脂肪可影响研究区域持久性有机污染物（Persistent organic pollutants, POPs）的分布，但影响不显著.同时HCHs、DDTs和2环及3环PAHs的浓度随海拔的升高而增加，呈典型的高山冷捕获效应；4环、5环和6环PAHs的浓度随着海拔的升高而降低，这可能是云南本地污染源影响所致.较低质量的PAHs（2-3环）是研究区域PAHs的重要组成部分，平均占总浓度的77%以上，说明研究区域受到污染物大气远距离传输的重要影响.PAHs特征单体比值表明，草、木材等生物质和煤炭燃料等的低温燃烧是研究区域PAHs的主要来源，同时较低的α/γ-HCH和较高的o，p’-DDT/p，p’-DDT比率表明，林丹和三氯杀螨醇的使用对研究区域树皮中有机氯农药的污染有一定的贡献.根据反向气团轨迹模型及PAHs和OCPs的浓度分布，推断研究区域的OCPs主要受印度季风和西风环流的影响，而PAHs是大气远距离传输源和云南本地污染源共同作用的结果.Abstract: Sixteen tree bark samples were collected from Yunnan Province in August 2012 and analyzed for polycyclic aromatic hydrocarbons (PAHs) and organochlorine pesticides (OCPs) including HCHs and DDTs. The concentrations of ∑16PAH ranged from 317 to 1194 ng·g-1, with a mean value of 639 ng·g-1. ∑4HCH and ∑6DDT in bark samples were in the range of 0.10-3.86 ng·g-1 dw (mean 1.10 ng·g-1 dw) and 0.78-7.29 ng·g-1 dw (mean 3.32 ng·g-1 dw), respectively. The concentrations of PAHs were 2-3 times higher than those from Nyingchi, but the concentrations of HCHs and DDTs were lower than those from Nyingchi in southeast TP. The distribution of POPs in the study area was influenced by the lipid content in bark, but not significantly. Meanwhile HCHs, DDTs, 2 ring and 3 ring PAHs increased with altitude, showing a typical mountain cold-trapping effect; 4 ring, 5 ring, and 6 ring PAHs decreased with altitude, which may be caused by the local pollution sources in the study area. Lower molecular weight PAHs (2-3 rings) were the dominant PAHs which accounted for 77% of the total PAHs on average, indicating the significant influence of long-range atmospheric transport (LRAT) in the study area. The special diagnostic ratios of PAHs suggested that the PAHs in the study area were mainly produced by low temperature combustion of biomass (grass or/and wood)and coal fuels, and the relatively low ratios of α/γ-HCH and high ratios of o,p'-DDT/p,p'-DDT implied that widely applications of lindane and dicofol contributed to the OCPs contamination in this area. According to the backward airmass trajectory models and distribution of PAHs and OCPs, it was deduced that the OCPs were mainly influenced by the westerly wind and Indian Monsoon, and the PAHs were the results of the interaction between the long-range atmospheric transport and the local pollution sources in Yunnan Province.
-
Key words:
- Yunnan Province /
- PAHs /
- OCPs /
- bark /
- source analysis
-
-
[1] WANG X P, YAO T D, CONG Z Y, et al. Gradient distribution of persistent organic contaminants along northern slope of central-Himalayas, China[J]. Science of the Total Environment, 2006, 372(1):193-202. [2] GONG P, WANG X P, SHENG J J, et al. Variations of organochlorine pesticides and polychlorinated biphenyls in atmosphere of the Tibetan Plateau:Role of the monsoon system[J]. Atmospheric Environment, 2010, 44(21-22):2518-2523. [3] ABAKUMOV E V, LODYGIN E D, GABOV D A, et al. Polycyclic aromatic hydrocarbons content in Antarctica soils as exemplified by the Russian polar stations[J]. Gigiena i sanitariia, 2014, (1):31-35. [4] XIAO H, SHEN L, SU Y, et al. Atmospheric concentrations of halogenated flame retardants at two remote locations:The Canadian High Arctic and the Tibetan Plateau[J]. Environmental Pollution, 2012, 161:154-161. [5] BECKER S, HALSALL C J, TYCH W, et al. Changing sources and environmental factors reduce the rates of decline of organochlorine pesticides in the Arctic atmosphere[J]. Atmospheric Chemistry and Physics, 2012, 12(9):4033-4044. [6] CASTRO-JIMENEZ J, BERROJALBIZ N, PIZARRO M, et al. Organophosphate ester (ope) flame retardants and plasticizers in the open mediterranean and black seas atmosphere[J]. Environmental Science & Technology, 2014, 48(6):3203-3209. [7] WEISS P, LORBEER G, SCHARF S. Persistent organic pollutants in remote austrian forests-altitude-related results[J]. Environmental Science and Pollution Research, 1998, 46-52. [8] SHENG J, WANG X, GONG P, et al. Monsoon-driven transport of organochlorine pesticides and polychlorinated biphenyls to the Tibetan Plateau:Three year atmospheric monitoring study[J]. Environmental Science & Technology, 2013, 47(7):3199-3208. [9] GONG P, WANG X P, XUE Y G, et al. Influence of atmospheric circulation on the long-range transport of organochlorine pesticides to the western Tibetan Plateau[J]. Atmospheric Research, 2015, 166:157-164. [10] CHENG H, ZHANG G, JIANG J X, et al. Organochlorine pesticides, polybrominated biphenyl ethers and lead isotopes during the spring time at the Waliguan Baseline Observatory, northwest China:Implication for long-range atmospheric transport[J]. Atmospheric Environment, 2007, 41(22):4734-4747. [11] BING H J, WU Y H, ZHOU J, et al. Atmospheric deposition of lead in remote high mountain of eastern Tibetan Plateau, China[J]. Atmospheric Environment, 2014, 99:425-435. [12] SALAMOVA A, HITES R A. Evaluation of tree bark as a passive atmospheric sampler for flame retardants, PCBs, and organochlorine pesticides[J]. Environmental Science & Technology, 2010, 44(16):6196-6201. [13] YANG R Q, ZHANG S J, LI A, et al. Altitudinal and spatial signature of persistent organic pollutants in soil, lichen, conifer needles, and bark of the southeast Tibetan Plateau:Implications for sources and environmental cycling[J]. Environmental Science & Technology, 2013, 47(22):12736-12743. [14] ZHU L Y, HITES R A. Brominated flame retardants in tree bark from North America[J]. Environmental Science & Technology, 2006, 40(12):3711-3716. [15] ORECCHIO S, GIANGUZZA A, CULOTTA L. Absorption of polycyclic aromatic hydrocarbons by Pinus bark:Analytical method and use for environmental pollution monitoring in the Palermo area (Sicily, Italy)[J]. Environmental Research, 2008, 107(3):371-379. [16] NIU L L, XU C, XU Y, et al. Hexachlorocyclohexanes in tree bark across chinese agricultural regions:Spatial distribution and enantiomeric signatures[J]. Environmental Science & Technology, 2014, 48(20):12031-12038. [17] HE C, JIN J, XIANG B L, et al. Upper Yellow River air concentrations of organochlorine pesticides estimated from tree bark, and their relationship with socioeconomic indices[J]. Journal of Environmental Sciences-China, 2014, 26(3):593-600. [18] TARCAU D, CUCU-MAN S, BORUVKOVA J, et al. Organochlorine pesticides in soil, moss and tree-bark from North-Eastern Romania[J]. Science of the Total Environment, 2013, 456:317-324. [19] CABRERIZO A, DACHS J, BARCELO D, et al. Influence of organic matter content and human activities on the occurrence of organic pollutants in antarctic soils, lichens, grass, and mosses[J]. Environmental Science & Technology, 2012, 46(3):1396-1405. [20] SICRE M A, MARTY J C, SALIOT A, et al. Aliphatic and aromatic-hydrocarbons in different sized aerosols over the mediterranean-sea-occurrence and origin[J]. Atmospheric Environment, 1987, 21(10):2247-2259. [21] GRIMMER G, JACOB J, NAUJACK K W. Profile of the polycyclic aromatic-compounds from crude oils.3. inventory by gcgc ms-PAH in environmental materials[J]. Fresenius Zeitschrift Fur Analytische Chemie, 1983, 314(1):29-36. [22] 谢婷,张淑娟,杨瑞强. 青藏高原湖泊流域土壤中与牧草中多环芳烃和有机氯农药的污染特征与来源解析[J]. 环境科学, 2014, 35(7):2680-2690. XIE, T, ZHANG S J, YANG R Q. Contamination levels and source analysis of polycyclic aromatic hydrocarbons and organochlorine pesticides in soils and grasses from lake catchments in the Tibetan Plateau[J]. Environmental Sciences, 2014, 35(7):2680-2690(in Chinese).
[23] SHEN L, WANIA F, LEI Y D, et al. Hexachlorocyclohexanes in the north American atmosphere[J]. Environmental Science & Technology, 2004, 38(4):965-975. [24] LAVIN K S, HAGEMAN K J. Contributions of long-range and regional atmospheric transport on pesticide concentrations along a transect crossing a mountain divide[J]. Environmental Science & Technology, 2013, 47(3):1390-1398. [25] SHUNTHIRASINGHAM C, WANIA F, MACLEOD M, et al. Mountain cold-trapping increases transfer of persistent organic pollutants from atmosphere to cows' milk[J]. Environmental Science & Technology, 2013, 47(16):9175-9181. [26] GRIMALT J O, FERNANDEZ P, BERDIE L, et al. Selective trapping of organochlorine compounds in mountain lakes of temperate areas[J]. Environmental Science & Technology, 2001, 35(13):2690-2697. [27] GONG P, WANG X P, LI S H, et al. Atmospheric transport and accumulation of organochlorine compounds on the southern slopes of the Himalayas, Nepal[J]. Environmental Pollution, 2014, 192:44-51. [28] ASTON L S, SEIBER J N. Fate of summertime airborne organophosphate pesticide residues in the Sierra Nevada mountains[J]. Journal of Environmental Quality, 1997, 26(6):1483-1492. [29] VILLA S, VIGHI M, MAGGI V, et al. Historical trends of organochlorine pesticides in an Alpine glacier[J]. Journal of Atmospheric Chemistry, 2003, 46(3):295-311. [30] SHEN H, TAO S, WANG R, et al. Global time trends in PAH emissions from motor vehicles[J]. Atmospheric Environment, 2011, 45(12):2067-2073. [31] ZHU Y D, YANG Y Y, LIU M X, et al. Concentration, distribution, source, and risk assessment of PAHs and heavy metals in surface water from the three gorges reservoir, China[J]. Human and Ecological Risk Assessment, 2015, 21(6):1593-1607. [32] MA W L, QI H, BAIDRON S, et al. Implications for long-range atmospheric transport of polycyclic aromatic hydrocarbons in Lhasa, China[J]. Environmental Science and Pollution Research, 2013, 20(8):5525-5533. [33] BUDZINSKI H, JONES I, BELLOCQ J, et al. Evaluation of sediment contamination by polycyclic aromatic hydrocarbons in the Gironde estuary[J]. Marine Chemistry, 1997, 58(1-2):85-97. [34] MA X, RAN Y, GONG J, et al. Concentrations and inventories of polycyclic aromatic hydrocarbons and organochlorine pesticides in watershed soils in the Pearl River Delta, China[J]. Environmental Monitoring and Assessment, 2008, 145(1-3):453-464. [35] YUNKER M B, MACDONALD R W, VINGARZAN R, et al. PAHs in the Fraser River basin:a critical appraisal of PAH ratios as indicators of PAH source and composition[J]. Organic Geochemistry, 2002, 33(4):489-515. [36] IWATA H, TANABE S, UEDA K, et al. Persistent organochlorine residues in air, water, sediments, and soils from the lake baikal region, Russia[J]. Environmental Science & Technology, 1995, 29(3):792-801. [37] XING X L, QI S H, ZHANG Y, et al. Organochlorine pesticides (OCPs) in soils along the eastern slope of the Tibetan Plateau[J]. Pedosphere, 2010, 20(5):607-615. [38] XU Y, ZHANG G, LI J, et al. Long-range atmospheric transport of persistent organochlorinated compounds from south and mainland south-eastern Asia to a remote mountain site in south-western China[J]. Journal of Environmental Monitoring, 2011, 13(11):3119-3127. [39] ZHENG X, LIU X, LIU W, et al. Concentrations and source identification of organochlorine pesticides (OCPs) in soils from Wolong Natural Reserve[J]. Chinese Science Bulletin, 2009, 54(5):743-751. [40] JAWARD F M, ZHANG G, NAM J J, et al. Passive air sampling of polychlorinated biphenyls, organochlorine compounds, and polybrominated diphenyl ethers across Asia[J]. Environmental science & technology, 2005, 39(22):8638-8645. [41] WURL O, OBBARD J P. Organochlorine compounds in the marine atmosphere of Singapore[J]. Atmospheric Environment, 2005, 39(38):7207-7216. [42] DACHS J, BAYONA J M, ITTEKKOT V, et al. Monsoon-driven vertical fluxes of organic pollutants in the western Arabian Sea[J]. Environmental Science & Technology, 1999, 33(22):3949-3956. -
