大连市PM2.5中重金属的污染特征、来源及健康风险评价
Characteristics, Sources and Health Risk Assessment of PM2.5-bound Metal Elements in Dalian
-
摘要: 为研究大连市大气PM2.5中重金属元素的污染特征和健康风险，于2021年6月3日至2022年5月29日进行样品采集，每3天采样1次，共采集有效样品120个。利用电感耦合等离子体质谱仪(ICP-MS)测定PM2.5中14种重金属元素包括钡(Ba)、镉(Cd)、锡(Sn)、钒(V)、铬(Cr)、锰(Mn)、钴(Co)、镍(Ni)、铜(Cu)、锌(Zn)、砷(As)、硒(Se)、铅(Pb)和锑(Sb)的浓度，运用正定矩阵因子分析法(PMF)解析了PM2.5中重金属元素的来源，并评估了重金属元素的健康风险。结果表明，采样期间大连市PM2.5质量浓度范围为4.2~159.3 μg·m-3，年平均质量浓度为(33.2±28.9) μg·m-3。PM2.5中共检出13种重金属元素(Sn未检出)，总质量浓度范围为0.004~0.586 μg·m-3，年均质量浓度为(0.139±0.116) μg·m-3。Zn是PM2.5中最主要的微量元素，平均占比(33.6±23.5)%。来源解析结果显示，大连市PM2.5中重金属元素主要来源按年平均占比由高到低依次为：工业过程源(41.9%)>交通排放源(32.3%)>燃煤源(14.4%)>钢铁冶炼源(11.4%)。污染时段工业过程源和燃煤排放源占比增大。健康风险评价结果显示，大连市PM2.5中12种重金属元素(Cr、Cd、Co、Ni、As、Pb、Ba、V、Mn、Zn、Cu和Sb)经呼吸暴露途径的非致癌风险较小(HI＜1)。重金属元素对儿童的非致癌风险高于成人。评价致癌风险的6种重金属中，Cd、Co、Ni和Pb对于儿童和成人基本不存在致癌风险(R＜10-6)；As和Cr对于儿童和成人都存在一定致癌风险(10-6＜R＜10-4)。6种重金属元素累计对成年男性致癌风险最高(ILCR=6.51×10-5)，成年女性次之(ILCR=5.54×10-5)，儿童最低(ILCR=1.42×10-5)。在PM2.5污染情况下，Pb和As对成人存在一定致癌风险，Cr元素存在较高致癌风险。Abstract: To study the pollution characteristics and health risks of heavy metals in PM2.5 in Dalian, a total of 120 effective samples were collected from June 3, 2021 to May 29, 2022, once every 3 days. The concentrations of 14 heavy metals (Ba, Cd, Sn, V, Cr, Mn, Co, Ni, Cu, Zn, As, Se, Pb and Sb) in PM2.5 were determined by inductively coupled plasma mass spectrometer (ICP-MS). The sources of heavy metal elements in PM2.5 were analyzed by positive matrix factorization (PMF), and the health risk of heavy metal elements was evaluated. The results showed that the concentrations of PM2.5 in Dalian ranged from 4.2 to 159.3 μg·m-3 during the sampling period, with the annual average of (33.2±28.9) μg·m-3. A total of 14 heavy metal elements except Sn were detected in PM2.5. The total mass concentrations were from 0.004 to 0.586 μg·m-3 with an average concentration of (0.139±0.116) μg·m-3. Among all metals, Zn was the most abundant element in PM2.5, with an average of (33.6±23.5)%. The source analysis results showed that the main sources of heavy metals in PM2.5 in Dalian were in order from high to low: industrial process source (41.9%) > traffic emission source (32.3%) > coal combustion source (14.4%) > iron and steel smelting source (11.4%). During the pollution period, the proportion of industrial process sources and coal combustion sources increased. The results of health risk assessment showed that the 12 heavy metals (Cr, Cd, Co, Ni, As, Pb, Ba, V, Mn, Zn, Cu and Sb) in PM2.5 in Dalian had a low non-carcinogenic risk (HI<1) through respiratory exposure. The non-carcinogenic risk of heavy metals to children was higher than that to adults. Among the 6 heavy metals evaluated for carcinogenic risk, Cd, Co, Ni and Pb basically had no carcinogenic risk for children and adults (R<10-6); As and Cr had a certain carcinogenic risk both for children and adults (10-6<R<10-4). The cumulative carcinogenic risk of the six heavy metals was the highest for adult males (ILCR=6.51×10-5), followed by adult females (ILCR=5.54×10-5), and the lowest for children (ILCR=1.42×10-5). Pb and As had a certain carcinogenic risk for adults, whereas Cr had a higher carcinogenic risk during periods of PM2.5 pollution.
-
Key words:
- PM2.5 /
- heavy metals /
- health risk assessment
-
-
曹军骥. PM2.5与环境[M]. 北京: 科学出版社, 2014: 1-7 Klingmüller K, Karydis V A, Bacer S, et al. Weaker cooling by aerosols due to dust-pollution interactions [J]. Atmospheric Chemistry and Physics, 2020, 20(23): 15285-15295 Liu S H, Tian H Z, Luo L N, et al. Health impacts and spatiotemporal variations of fine particulate and its typical toxic constituents in five urban agglomerations of China [J]. The Science of the Total Environment, 2022, 806(Pt 4): 151459 Farahani V J, Soleimanian E, Pirhadi M, et al. Long-term trends in concentrations and sources of PM2.5-bound metals and elements in central Los Angeles [J]. Atmospheric Environment, 2021, 253: 118361 Chang Y H, Huang K, Xie M J, et al. First long-term and near real-time measurement of trace elements in China’s urban atmosphere: Temporal variability, source apportionment and precipitation effect [J]. Atmospheric Chemistry and Physics, 2018, 18(16): 11793-11812 陈耿, 常运华, 曹芳, 等. 上海城乡细颗粒物中碳质、无机和重金属的全组分特征及来源分析[J]. 科学技术与工程, 2020, 20(29): 12218-12225 Chen G, Chang Y H, Cao F, et al. Characteristics and source analysis of carbon, inorganic and heavy metals in fine particles in Shanghai [J]. Science Technology and Engineering, 2020, 20(29): 12218-12225 (in Chinese)
Liu L, Urch B, Szyszkowicz M, et al. Metals and oxidative potential in urban particulate matter influence systemic inflammatory and neural biomarkers: A controlled exposure study [J]. Environment International, 2018, 121(Pt 2): 1331-1340 Saffari A, Daher N, Shafer M M, et al. Global perspective on the oxidative potential of airborne particulate matter: A synthesis of research findings [J]. Environmental Science & Technology, 2014, 48(13): 7576-7583 Li X, Yan C Q, Wang C Y, et al. PM2.5-bound elements in Hebei Province, China: Pollution levels, source apportionment and health risks [J]. The Science of the Total Environment, 2022, 806(Pt 1): 150440 Zhao S, Tian H Z, Luo L N, et al. Temporal variation characteristics and source apportionment of metal elements in PM2.5 in urban Beijing during 2018-2019 [J]. Environmental Pollution, 2021, 268(Pt B): 115856 Li F, Yan J J, Wei Y C, et al. PM2.5-bound heavy metals from the major cities in China: Spatiotemporal distribution, fuzzy exposure assessment and health risk management [J]. Journal of Cleaner Production, 2021, 286: 124967 邹天森, 康文婷, 张金良, 等. 我国主要城市大气重金属的污染水平及分布特征[J]. 环境科学研究, 2015, 28(7): 1053-1061 Zou T S, Kang W T, Zhang J L, et al. Concentrations and distribution characteristics of atmospheric heavy metals in urban areas of China [J]. Research of Environmental Sciences, 2015, 28(7): 1053-1061 (in Chinese)
王欣睿, 叶剑军, 倪志鑫, 等. 珠江口海域大气中重金属季节变化特征及其与气象因子的关系[J]. 海洋通报, 2016, 35(6): 632-640 , 648 Wang X R, Ye J J, Ni Z X, et al. Seasonal variation characteristics of heavy metals in the atmosphere and its relationship with meteorological factors over the Pearl River Estuary [J]. Marine Science Bulletin, 2016, 35(6): 632-640, 648 (in Chinese)
周雪明, 郑乃嘉, 李英红, 等. 2011—2012北京大气PM2.5中重金属的污染特征与来源分析[J]. 环境科学, 2017, 38(10): 4054-4060 Zhou X M, Zheng N J, Li Y H, et al. Chemical characteristics and sources of heavy metals in fine particles in Beijing in 2011-2012 [J]. Environmental Science, 2017, 38(10): 4054-4060 (in Chinese)
Hao Y F, Luo B, Simayi M, et al. Spatiotemporal patterns of PM2.5 elemental composition over China and associated health risks [J]. Environmental Pollution, 2020, 265(Pt B): 114910 Mu L, Peng L, Cao J J, et al. Emissions of polycyclic aromatic hydrocarbons from coking industries in China [J].Particuology, 2013, 11(1): 86-93 任万辉, 李云丹, 苏枞枞, 等. 沈阳市大气PM2.5中重金属污染特征、来源解析及健康风险评价[J]. 环境化学, 2021, 40(4): 1029-1037 Ren W H, Li Y D, Su C C, et al. Pollution characteristics, source apportionment and health risk assessment of heavy metals in PM2.5 in Shenyang [J]. Environmental Chemistry, 2021, 40(4): 1029-1037 (in Chinese)
安欣欣, 曹阳, 王琴, 等. 北京城区PM2.5各组分污染特征及来源分析[J]. 环境科学, 2022, 43(5): 2251-2261 An X X, Cao Y, Wang Q, et al. Chemical characteristics and source apportionment of PM2.5 in urban area of Beijing [J]. Environmental Science, 2022, 43(5): 2251-2261 (in Chinese)
Zhang J Z, Zhou X H, Wang Z, et al. Trace elements inPM2.5 in Shandong Province: Source identification and health risk assessment [J]. The Science of the Total Environment, 2018, 621: 558-577 朱兆洲, 闫文蕊, 张紫静. 电感耦合等离子体质谱法研究烟花爆竹PM2.5中重金属的污染特征及生态健康风险[J]. 光谱学与光谱分析, 2023, 43(2): 644-650 Zhu Z Z, Yan W R, Zhang Z J. Research of pollution characteristics, ecological and health risks of heavy metals in PM2.5 from fireworks by inductively coupled plasma-mass spectroscopy [J]. Spectroscopy and Spectral Analysis, 2023, 43(2): 644-650 (in Chinese)
王橹玺. 大气颗粒物中重金属Cr(Ⅵ)的污染特征研究[D]. 北京: 中国环境科学研究院, 2021: 50-55 李宏艳, 赵志新, 何秋生, 等. 山西介休焦化区PM2.5重金属污染特征、关键毒性组分与来源[J]. 中国环境科学, 2023, 43(4): 1528-1538 Li H Y, Zhao Z X, He Q S, et al. Pollution characteristics, key toxic components and sources of PM2.5-bound heavy metals in coking polluted area of Jiexiu, Shanxi [J]. China Environmental Science, 2023, 43(4): 1528-1538 (in Chinese)
环境保护部. 中国人群暴露参数手册-成人卷[M]. 北京: 中国环境出版社, 2013: 12, 268, 746 Agarwal A, Mangal A, Satsangi A, et al. Characterization, sources and health risk analysis of PM2.5 bound metals during foggy and non-foggy days in sub-urban atmosphere of Agra [J]. Atmospheric Research, 2017, 197: 121-131 United States Environmental Protection Agency (US EPA). Exposure factors handbook 2011 edition (final report) [R]. Washington DC: United States Environmental Protection Agency, 2011 潘成珂, 黄韬, 高宏, 等. 张掖市城区大气细颗粒物PM2.5的化学组成及来源解析[J]. 环境科学, 2022, 43(12): 5367-5375 Pan C K, Huang T, Gao H, et al. Chemical composition and source apportionment of PM2.5 in Zhangye City [J]. Environmental Science, 2022, 43(12): 5367-5375 (in Chinese)
王丽霞, 刘海燕, 张晓明, 等. 威海市环翠区2021—2022年大气PM2.5化学组成季节变化特征[J]. 鲁东大学学报(自然科学版), 2022 , 38(4): 311-319 Wang L X, Liu H Y, Zhang X M, et al. Seasonal changes of chemical components of PM2.5 in Huancui District of Weihai City from 2021 to 2022 [J]. Journal of Ludong University (Natural Science Edition), 2022, 38(4): 311-319 (in Chinese)
沈建东, 周玉强, 王蕴赟, 等. 杭州西湖景区PM2.5中重金属来源及健康风险评价[J]. 环境污染与防治, 2020, 42(2): 199-203 Shen J D, Zhou Y Q, Wang Y Y, et al. Sources and health risk assessment of heavy metals in PM2.5 of West Lake scenic area in Hangzhou [J]. Environmental Pollution & Control, 2020, 42(2): 199-203 (in Chinese)
林孜, 姬亚芹, 国纪良, 等. 锦州市春季大气PM2.5中元素特征及来源解析[J]. 环境化学, 2021, 40(11): 3474-3481 Lin Z, Ji Y Q, Guo J L, et al. Characteristics and sources of elements in PM2.5 during spring in Jinzhou [J]. Environmental Chemistry, 2021, 40(11): 3474-3481 (in Chinese)
赵明升, 任丽红, 李刚, 等. 2018—2019年冬季天津和青岛PM2.5中重金属污染特征与健康风险评价[J]. 环境科学, 2022, 43(12): 5376-5386 Zhao M S, Ren L H, Li G, et al. Pollution characteristics and health risk assessment of PM2.5 heavy metals in Tianjin and Qingdao in winter of 2018- 2019 [J]. Environmental Science, 2022, 43(12): 5376-5386 (in Chinese)
Zheng Y, Chen S L, Chen Y Y, et al. Association between PM2.5-bound metals and pediatric respiratory health in Guangzhou: An ecological study investigating source, health risk, and effect [J]. Frontiers in Public Health, 2023, 11: 1137933 Lin Z Y, Fan X L, Chen G J, et al. Sources appointment and health risks of PM2.5-bound trace elements in a coastal city of southeastern China [J]. Journal of Environmental Sciences (China), 2024, 138: 561-571 曲红拥, 张谦栋, 刘乔芳, 等. 烟台市夏季大气PM2.5中重金属污染特征研究及来源分析[C]// 中国环境科学学会. 第十一届重金属污染防治技术及风险评价研讨会论文集. 海口: 中国环境科学学会, 2021: 12-18 Chen Y N, Ye X N, Yao Y H, et al. Characteristics and sources of PM2.5-bound elements in Shanghai during autumn and winter of 2019: Insight into the development of pollution episodes [J]. The Science of the Total Environment, 2023, 881: 163432 张瑰, 吴雨蔓, 职佳音, 等. 珠海市2020—2023年大气PM2.5的元素特征及健康风险评价[J]. 现代预防医学, 2024, 51(2): 226-232 Zhang G, Wu Y M, Zhi J Y, et al. Element characteristics and health risk assessment of atmospheric PM2.5 in Zhuhai, 2020-2023 [J]. Modern Preventive Medicine, 2024, 51(2): 226-232 (in Chinese)
李曾曾, 王平, 丁文慈, 等. 2019年三亚市PM2.5微量元素的源解析和健康评价[J]. 环境化学, 2023, 42(7): 2282-2291 Li Z Z, Wang P, Ding W C, et al. Source analysis and health assessment of PM2.5 trace elements in Sanya City in 2019 [J]. Environmental Chemistry, 2023, 42(7): 2282-2291 (in Chinese)
Sun X Z, Wang K, Ma L X, et al. Source-specific health risks induced by PM2.5-bound metallic species under different pollution scenarios in a cold megacity of Northeast China [J]. Urban Climate, 2022, 44: 101205 Dong D M, Qiu T, Du S S, et al. The chemical characterization and source apportionment of PM2.5 and PM10 in a typical city of Northeast China [J]. Urban Climate, 2023, 47: 101373 任慧清, 鲁建江, 宁建英, 等. 石河子市PM2.5中重金属污染及健康风险评价[J]. 环境化学, 2020, 39(6): 1716-1725 Ren H Q, Lu J J, Ning J Y, et al. Pollution and health risk assessment of heavy metals in PM2.5 of Shihezi City [J]. Environmental Chemistry, 2020, 39(6): 1716-1725 (in Chinese)
Li Y Q, Zhao B W, Duan K X, et al. Contamination characteristics, mass concentration, and source analysis of metal elements in PM2.5 in Lanzhou, China [J]. Elementa: Science of the Anthropocene, 2021, 9(1): 00125 王鑫, 肖舜, 董治宝, 等. 西安重度以上污染天气PM2.5重金属污染特征与健康风险[J]. 中国沙漠, 2020, 40(5): 10-19 Wang X, Xiao S, Dong Z B, et al. Pollution characteristics and health risk of heavy metals in PM2.5 in severely polluted weather in Xi’an, China [J]. Journal of Desert Research, 2020, 40(5): 10-19 (in Chinese)
He Q Y, Zhao W D, Luo P R, et al. Contamination profiles and potential health risks of environmentally persistent free radicals in PM2.5 over typical central Chinese megacity [J]. Ecotoxicology and Environmental Safety, 2023, 264: 115437 Han Y, Wang Z C, Zhou J W, et al. PM2.5-bound heavy metals in southwestern China: Characterization, sources, and health risks [J]. Atmosphere, 2021, 12(7): 929 王显钦, 费学海, 杨员, 等. 贵阳市花溪城区PM2.5中重金属元素的污染特征、来源及健康风险评价[J]. 环境科学学报, 2023, 43(6): 110-118 Wang X Q, Fei X H, Yang Y, et al. Pollution characteristics, source apportionment and health risk assessment of heavy metal elements in PM2.5 collected in Huaxi urban areas, Guiyang [J]. Acta Scientiae Circumstantiae, 2023, 43(6): 110-118 (in Chinese)
Lin Y C, Zhang Y L, Song W H, et al. Specific sources of health risks caused by size-resolved PM-bound metals in a typical coal-burning city of Northern China during the winter haze event [J]. The Science of the Total Environment, 2020, 734: 138651 韩林洁, 黄俊, 韩新宇, 等. 昆明市典型干季大气PM2.5中重金属污染特征与来源研究[J]. 昆明理工大学学报(自然科学版), 2019, 44(2): 99-110 Han L J, Huang J, Han X Y, et al. Characteristics and sources of heavy metals in atmospheric PM2.5 research during the dry season in Kunming [J]. Journal of Kunming University of Science and Technology (Natural Science), 2019, 44(2): 99-110 (in Chinese) Liu J W, Chen Y J, Chao S H, et al. Emission control priority of PM2.5-bound heavy metals in different seasons: A comprehensive analysis from health risk perspective [J]. The Science of the Total Environment, 2018, 644: 20-30 Huang H, Jiang Y, Xu X Y, et al.In vitro bioaccessibility and health risk assessment of heavy metals in atmospheric particulate matters from three different functional areas of Shanghai, China [J]. The Science of the Total Environment, 2018, 610/611: 546-554 肖凯, 任学昌, 陈仁华, 等. 典型西北钢铁城市冬季大气颗粒物重金属来源解析及健康风险评价: 以嘉峪关为例[J]. 环境化学, 2022, 41(5): 1649-1660 Xiao K, Ren X C, Chen R H, et al. Source analysis and health risk assessment of heavy metals in air particulates of typical northwest steel cities in winter: A case study inJiayuguan [J]. Environmental Chemistry, 2022, 41(5): 1649-1660 (in Chinese)
董婷, 李天昕, 赵秀阁, 等. 某焦化厂周边大气PM10重金属来源及健康风险评价[J]. 环境科学, 2014, 35(4): 1238-1244 Dong T, Li T X, Zhao X G, et al. Source and health risk assessment of heavy metals in ambient air PM10 from one coking plant [J]. Environmental Science, 2014, 35(4): 1238-1244 (in Chinese)
罗燃燃, 戴海夏, 张蕴晖, 等. 上海郊区家庭妇女PM2.5重金属组分暴露水平、来源与健康风险[J]. 环境科学, 2019, 40(12): 5224-5233 Luo R R, Dai H X, Zhang Y H, et al. Exposure levels, sources, and health risks of heavy metal components of PM2.5 in housewives in rural Shanghai [J]. Environmental Science, 2019, 40(12): 5224-5233 (in Chinese)
-
