烟气脱硫中亚硫酸钙铁锰复合催化氧化优化

蒋路漫; 周振; 俞杰; 胡大龙

doi:10.12030/j.cjee.201702031

环境工程学报

烟气脱硫中亚硫酸钙铁锰复合催化氧化优化

, , ,

蒋路漫, 周振, 俞杰, 胡大龙. 烟气脱硫中亚硫酸钙铁锰复合催化氧化优化[J]. 环境工程学报, 2017, 11(12): 6332-6338. doi: 10.12030/j.cjee.201702031

引用本文:

蒋路漫, 周振, 俞杰, 胡大龙. 烟气脱硫中亚硫酸钙铁锰复合催化氧化优化[J]. 环境工程学报, 2017, 11(12): 6332-6338. doi: 10.12030/j.cjee.201702031

JIANG Luman, ZHOU Zhen, YU Jie, HU Dalong. Optimization for Fe-Mn catalyzed sulfite oxidation in flue gas desulfurization[J]. Chinese Journal of Environmental Engineering, 2017, 11(12): 6332-6338. doi: 10.12030/j.cjee.201702031

Citation:

JIANG Luman, ZHOU Zhen, YU Jie, HU Dalong. Optimization for Fe-Mn catalyzed sulfite oxidation in flue gas desulfurization[J]. Chinese Journal of Environmental Engineering, 2017, 11(12): 6332-6338. doi: 10.12030/j.cjee.201702031

烟气脱硫中亚硫酸钙铁锰复合催化氧化优化

1.
上海电力学院环境与化学工程学院, 上海 200090
2.
西安热工研究院有限公司, 西安 710032
基金项目:
国家自然科学基金资助项目（51408352）
中图分类号: X521

Optimization for Fe-Mn catalyzed sulfite oxidation in flue gas desulfurization

1.
College of Environmental and Chemical Engineering, Shanghai University of Electric Power, Shanghai 200090, China
2.
Xi'an Thermal Power Research Institute Co. Ltd., Xi'an 710032, China
Fund Project:

摘要: 亚硫酸钙氧化是湿法石灰石/石膏法脱硫中十分重要的一个环节，优化亚硫酸钙氧化过程有助于降低湿法脱硫能耗和物耗。以CaSO3氧化速率（SOR）为研究对象，对比了Fe和Mn单独催化和复合催化的氧化效果，通过单因素和响应面法考察了pH、Fe/Mn比例和起始CaSO3浓度对SOR的单独和联合效应。结果表明，Fe和Mn复合催化的SOR明显高于单独催化。对SOR的影响大小依次为起始CaSO3浓度 > pH > Fe/Mn，Fe/Mn和起始CaSO3浓度的交互作用显著。CaSO3氧化的最佳条件为pH 4.5，Fe/Mn为0.37，起始浓度为17.83 mmol·L-1，优化的SOR为4.22 mmol·（L·min）-1。结构表征结果表明，亚硫酸钙氧化首先生成CaSO4·2H2O的（020）、（021）和（041）晶面，产物为CaSO4·2H2O。
- 烟气脱硫 /
- 亚硫酸钙氧化 /
- 响应面 /
- 结构表征
Abstract: Oxidation of calcium sulfite is a very important part of wet limestone/gypsum flue gas desulfurization (FGD) process. Optimization of the oxidation process will help reduce energy consumption and cost. We studied standard oxidation rate (SOR) of calcium sulfite by Fe catalyst, Mn catalyst and Fe/Mn combined catalyst. Single factor analysis and response surface methodology were employed to study separate and joint effects of pH, Fe/Mn ratio and initial CaSO3 concentration (ICS) on SOR. The results showed that combined catalyst resulted in a higher SOR than only Fe or Mn. ICS had the most impact on SOR, followed by pH and Fe/Mn ratio. Fe/Mn ratio and ICS had the most significant interaction. Optimum conditions for CaSO3 oxidation were:pH of 4.5, Fe/Mn ratio of 0.37 and ICS of 17.83 mmol·L-1. Under the optimum conditions, SOR reached 4.22 mmol·(L·min)-1. The results from structural analysis indicated that the (020), (021) and (041) faces of the product CaSO4·2H2O were first formed in the oxidation process.
- flue gas desulfurization /
- calcium sulfite oxidation /
- response surface /
- structural analysis

[1]	马双忱, 熊远南, 吴国栋, 等. 湿式石灰石烟气脱硫循环系统减阻剂配方研究[J]. 中国电机工程学报,2014,34(2):240-246
[2]	张军, 张涌新, 郑成航, 等. 复合脱硫添加剂在湿法烟气脱硫系统中的工程应用[J]. 中国环境科学,2014,34(9):2186-2191
[3]	罗捷, 吴国防, 朱宗莉, 等. 湿法烟气脱硫过程亚硫酸钙的氧化[J]. 重庆大学学报:自然科学版,2007,30(4):49-51
[4]	郭斌, 卞京凤, 任爱玲. 半干法烧结烟气脱硫灰中亚硫酸钙氧化研究[J]. 环境污染与防治,2009,31(7):1-4
[5]	赵毅, 汪黎东, 王小明, 等. 烟气脱硫产物-亚硫酸钙非催化氧化的宏观反应动力学研究[J]. 中国电机工程学报,2005,25(8):116-120
[6]	韩长民, 张轶, 商克峰, 等. 沿面放电活化空气用于亚硫酸铵氧化[J]. 环境工程学报,2015,9(8):3965-3969
[7]	JIA Y, YIN L, XU Y, et al. A model for performance of sulfite oxidation of ammonia-based flue gas desulfurization system[J]. Atmospheric Pollution Research,2015,6(6):997-1003
[8]	JIA Y, ZHONG Q, FAN X, et al. Kinetics of oxidation of total sulfite in the ammonia-based wet flue gas desulfurization process[J]. Chemical Engineering Journal,2010,164(1):132-138
[9]	KARATZA D, PRISCIANDARO M, LANCIA A, et al. Sulfite oxidation catalyzed by cobalt ions in flue gas desulfurization processes[J]. Journal of the Air & Waste Management Association,2010,60(6):675-680
[10]	武汉大学. 分析化学实验[M]. 北京:高等教育出版社,2001
[11]	于洁, 官宝红, 刘文霞, 等. 抑制双碱法烟气脱硫浆液中SO₃^2-的重金属催化氧化[J]. 环境科学,2010,31(3):591-597
[12]	杨剑, 文娟, 董凌燕, 等. 烟气脱硫过程锰催化氧化亚硫酸钙的研究[J]. 环境工程学报,2007,1(9):109-112
[13]	张艳华, 宋光武, 罗志云, 等. 铁离子液相催化氧化协同脱硫脱硝[J]. 环境工程学报,2016,10(6):3135-3140
[14]	宏哲, 梁丽丽, 武海俊. 湿法烟气脱硫中亚硫酸钙氧化技术的研究进展[J]. 电力科技与环保,2010,26(2):26-28
[15]	杜谦, 吴少华, 朱群益, 等. 湿法烟气脱硫环境下亚硫酸钙的非催化氧化[J]. 哈尔滨工业大学学报,2004,36(3):391-394
[16]	刘盛余, 高瑾, 肖文德, 等. 柠檬酸强化烟气脱硫体系中亚硫酸钙的氧化过程[J]. 煤炭学报,2009,34(11):1531-1534
[17]	吴晓琴, 吴忠标, 汪大翚. 均相/非均相体系中亚硫酸钙非催化氧化过程[J]. 环境科学学报,2004,24(3):534-538
[18]	ZHOU Z, QIAO W, LIN Y, et al. Phosphonate removal from discharged circulating cooling water using iron-carbon micro-electrolysis[J]. Water Science and Technology,2014,70(3):524-532
[19]	周振, 胡大龙, 乔卫敏, 等. 聚合氯化铝去除污泥水中磷的工艺优化[J]. 环境科学,2014,35(6):2249-2255
[20]	GUAN B, FU H, YU J, et al. Direct transformation of calcium sulfite to α-calcium sulfate hemihydrate in a concentrated Ca-Mg-Mn chloride solution under atmospheric pressure[J]. Fuel,2011,90(1):36-41
[21]	SETOYAMA K, TAKAHASHI S. Solid solution of calcium sulfite hemihydrate and calcium sulfate[J]. Journal of the Ceramic Association Japan,1978,86:244-250
[22]	GADALLA AM, GUPTA A. Characterization of the product of the thiosulfate process for desulfurization of flue gases[J]. Industrial & Engineering Chemistry Research,1994,33(5):1145-1149
