固定化硝化细菌去除生活污水中的氨氮

刘少敏; 储磊; 朱敬林

环境工程学报

固定化硝化细菌去除生活污水中的氨氮

, ,

刘少敏, 储磊, 朱敬林. 固定化硝化细菌去除生活污水中的氨氮[J]. 环境工程学报, 2014, 8(10): 4261-4266.

引用本文:

刘少敏, 储磊, 朱敬林. 固定化硝化细菌去除生活污水中的氨氮[J]. 环境工程学报, 2014, 8(10): 4261-4266.

Liu Shaomin, Chu Lei, Zhu Jinglin. Removal of ammonia nitrogen from sewage by immobilization nitrification bacteria[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4261-4266.

Citation:

Liu Shaomin, Chu Lei, Zhu Jinglin. Removal of ammonia nitrogen from sewage by immobilization nitrification bacteria[J]. Chinese Journal of Environmental Engineering, 2014, 8(10): 4261-4266.

固定化硝化细菌去除生活污水中的氨氮

1.
安徽理工大学地球与环境学院, 淮南 232001
基金项目:
安徽理工大学博士基金资助项目（2013bj1105）

安徽省国际合作项目（12030-603003）
中图分类号: X703

Removal of ammonia nitrogen from sewage by immobilization nitrification bacteria

1.
School of Earth Science and Environmental Engineering, Anhui University of Science and Technology, Huainan 232001, China
Fund Project:

摘要: 以聚乙烯醇-海藻酸钠作为包埋载体固定硝化细菌，制备固定小球，对生活污水中的氨氮去除效果进行研究。采用平行实验考察了载体不同包菌量、载体与污水量比、活化时间、温度、DO以及载体循环次数对氨氮去除率的影响。结果表明，用包埋载体处理污水的氨氮和COD去除率明显高于传统活性污泥，且得出最佳反应条件：包埋载体的最佳活化时间为20 h，最适温度为25℃，最佳DO为3~4 mg/L。投加包埋载体比传统活性污泥法对氨氮去除效果和COD去除能力具有强化作用，投加20%的包埋载体时，反应器出水氨氮去除率提高了20%，菌体与载体比值小于1：2.5时氨氮去除率超过90.12%，固定化包埋载体去除氨氮过程比较符合一级动力学模型。
- 固定化技术 /
- 硝化细菌 /
- 载体 /
- 氨氮去除率
Abstract: The immobilized microbial beads were prepared to treat ammonia-nitrogen in domestic sewage,which is made from entrapping nitrobacteria with the polyvinyl alcohol-sodium alginate as entrapment carriers.In order to study the removal rate of ammonia-nitrogen,some factors such as the amount of bacteria of immobilized imbedded carrier,the proportion between carrier and wastewater,activation time,temperature,DO and the recycling times of immobilized imbedded carrier were investigated by the parallel test.The result indicated that the removal rates of ammonia-nitrogen and COD using the immobilized nitrobacteria were higher than that of the traditional active sludge obviously,and it also showed that the optimum conditions were as follows: the embedding carrier activation time of 20 h,the temperature of 25 ℃ and the DO of 3~4 mg/L.Furthermore,we found that the removal rate of ammonia nitrogen and COD using immobilized nitrobacteria was superior to the conventional activated sludge process.The removal rate of ammonia nitrogen was about 20% with 20% immobilization embedding carriers,when the amount of nitrification bacteria to immobilized imbedded carrier was less than 1:2.5,the removal rate of ammonia nitrogen was above 90.12%,in addition,the removal of ammonia nitrogen with immobilization embedding carriers was expressed as the first order kinetic reaction model.
- immobilization technology /
- nitrification bacteria /
- carrier /
- ammonia nitrogen removal rate

[1]	杨麒,李小明,曾光明,等.固定化微生物脱氮技术.环境污染治理技术与设备,2002,3 (10):58-60 Yang Q.,Li X.M.,Zeng G.M.,et al.Biodenitrification technology using immobilized microorganisms.Technigues and Equipment for Environmental Pollution Control,2002,3(10):58-60(in Chinese)
[2]	刘蕾,姜灵彦.包埋固定化微生物的特性研究.环境科学与管理,2008,33(6):56-58 Liu L.,Jiang L.Y.Research of the character of bio-Immobilized.Environmental Science and Management,2008,33(6):56-58(in Chinese)
[3]	张文东,刘鹏,陈龙.包埋固定化微生物在废水处理中的应用.重庆工商大学学报(自然科学版),2011,28(1):63-65 Zhang W.D.,Liu P.,Chen L.Application of entrapped immobilized-microbe to wastewater treatment.Journal of Chongqing Technology and Business University(Natural Science Edition),2011,28(1):63-65(in Chinese)
[4]	谢冰,徐璍,徐亚同.硝化细菌的固定化研究.上海环境科学,2003,22(11):19-23 Xie B.,Xu H.,Xu Y.T.Study on immobilization technique of nitrifying bacteria.Shanghai Environmental Sciences,2003,22(11):19-23(in Chinese)
[5]	Pranee L.,Duangcheewan B.,Wiboonluk P.Immobilization of nitrite oxidizing bacteria using biopolymeric chitosan media.Journal of Environmental Sciences,2013,25(2):262-267
[6]	李晔,李凌,张发有,等.生物固定化技术在含氮废水处理中的研究.工业安全与环保,2004,30(6):18-20 Li Y.,Li L.,Zhang F.Y.,et al.Research on biological Immobilization technology in the treatment of nitrogen-contained wastewater.Industrial Safety and Dust Control,2004,30(6):18-20(in Chinese)
[7]	冯雅男,李军,王力军,等.包埋固定化技术去除水体中氨氮的研究进展.辽宁化工,2010,39(2):164-168 Feng Y.N.,Li J.,Wang L.J.,et al.Research progress of ammonia nitrogen removal from wastewater with entrapped immobilized bacteria.Liaoning Chemical Industry,2010,39(2):164-168(in Chinese)
[8]	蔡昌凤,梁磊.混合固定化硝化菌和好氧反硝化菌处理焦化废水.环境工程学报,2009,3(8):1391-1394 Cai C.F.,Liang L.Research of coking wastewater treatment using mixed immobilized nitrobacteria and aerobic denitrifying bacteria.Chinese Journal of Environmental Engineering,2009,3(8):1391-1394(in Chinese)
[9]	Buyukkamaci N.Biological sluge conditioning by Fenton’s reagent.Process Biochemistry,2004,39(11):1503-1506
[10]	Li X.A.,Chu H.P.Membrane bioreactor for the drinking water treatment of polluted surface water supplies.Water Research,2003,37(19):4781-4791
[11]	Kim J.H.,Rene E.R.,Park H.S.Performance of an immobilized cell biofilter for ammonia removal from contaminated air stream.Chemosphere,2007,68(2):274-280
[12]	Moussavi G.,Khavanin A.,Sharifi A.Ammonia removal from a waste air stream using a biotrickling filter packed with polyurethane foam through the SND process.Bioresource Technology,2011,102(3):2517-2522
[13]	Dong Y.,Zhang Z.,Jin Y.Nitrification performance of nitrifying bacteria immobilized in waterborne polyurethane at low ammonia nitrogen concentrations.Journal of Environmental Sciences,2011,23(3):366-371
[14]	Qiao X.,Zhang Z.,Chen Q.Nitrification characteristics of PEG immobilized activated sludge at high ammonia and COD loading rates.Desalination,2008,222(1-3):340-347
[15]	赵雪莲,刘金泉,李宗慧,等.固定化硝化菌包埋载体去除氨氮的效果研究.水处理技术,2012,38(增刊):53-55 Zhao X.L.,Liu J.Q.,Li Z.H.,et al.Research on removing ammonia nitrogen by entrapped carrier of immobilized nitrobacteria.Technology of Water Treatment,2012,38 (supplement):53-55(in Chinese)
[16]	Guo J.,Zhang L.,Chen W.,et al.The regulation and control strategies of a sequencing batch reactor for simultaneous nitrification and denitrification at different temperatures.Bioresource Technology,2013,133(4):59-67
