碳酸根对磷酸钙沉淀反应回收磷的影响

,  ,  ,  ,

downloadPDF

上一篇

下一篇

赵亚丽, 宋永会, 钱锋, 程建光, 梁慧. 碳酸根对磷酸钙沉淀反应回收磷的影响[J]. 环境工程学报, 2014, 8(1): 48-54.
引用本文: 赵亚丽, 宋永会, 钱锋, 程建光, 梁慧. 碳酸根对磷酸钙沉淀反应回收磷的影响[J]. 环境工程学报, 2014, 8(1): 48-54.
shu
Zhao Yali, Song Yonghui, Qian Feng, Cheng Jianguang, Liang Hui. Effect of carbonate on calcium phosphate precipitation for phosphorus recovery[J]. Chinese Journal of Environmental Engineering, 2014, 8(1): 48-54.
Citation: Zhao Yali, Song Yonghui, Qian Feng, Cheng Jianguang, Liang Hui. Effect of carbonate on calcium phosphate precipitation for phosphorus recovery[J]. Chinese Journal of Environmental Engineering, 2014, 8(1): 48-54.
shu

碳酸根对磷酸钙沉淀反应回收磷的影响

  • 1.

    中国环境科学研究院城市水环境科技创新基地, 北京 100012

  • 2.

    山东科技大学化学与环境工程学院, 青岛 266590

  • 基金项目:

    国家自然科学基金资助项目（51078339）

    “十一五”国家科技支撑计划项目（2009BADC2B）

  • 中图分类号: X703

Effect of carbonate on calcium phosphate precipitation for phosphorus recovery

  • 1.

    Scientific and Technological Innovation Base for Urban Water Environmental Research, Chinese Research Academy of Environmental Sciences, Beijing 100012, China

  • 2.

    College of Chemical and Environmental Engineering, Shandong University of Science and Technology, Qingdao 266510, China

  • Fund Project:

  • 摘要: 以模拟的厌氧消化液为处理对象，通过小试实验，考察不同初始磷浓度CP、Ca/P物质的量比、pH和温度下，碳酸根（CO32-）对磷酸钙沉淀反应回收磷的影响；利用扫描电镜（SEM）、X射线衍射仪（XRD）和傅里叶变换红外光谱（FTIR）对沉淀产物进行表征。结果表明，高浓度的CO32-对以磷酸钙沉淀反应去除和回收磷的效率影响较大；CP相同时，CO32-浓度（CCO32-）越大，P的去除率越低，低CP（20 mg/L）时尤为显著；当CCO32-相同时，随着CP的增大，反应速率加快，P的去除率逐渐升高，但升高幅度越来越小；增大Ca/P比和pH能提高P的去除率，降低CO32-对磷酸钙沉淀反应的抑制作用，综合考虑实际效果，应选择Ca/P比为3.33，pH为9.0作为适宜的反应条件；升高温度对降低CO32-对磷酸钙沉淀反应的抑制作用贡献不大。在CP为60 mg/L，Ca/P比为1.67，pH为9.0，温度为20℃的条件下，当C CO32-为0时，得到的沉淀产物主要为羟基磷灰石HAP；当C CO32-为30 mmol/L时，得到的沉淀产物为磷酸钙和碳酸合磷灰石的混合物。
    Abstract: The effect of carbonate (CO32-) on the reaction of calcium phosphate precipitation at different initial phosphorus (P) concentrations, Ca/P ratios,pH values and temperatures were investigated using synthetic anaerobic digestion supernatant as treatment target at bench-scale. The precipitates were characterized by scanning electron microscope (SEM), X-ray Diffraction (XRD) and Fourier transform infrared spectrometer (FTIR).The results showed that the high concentration CO32- had more effect on the efficiency of phosphorus removal and recovery in the precipitated reaction of calcium phosphate. The phosphorus removal efficiency was lower when the CO32- concentration was higher at the same P concentration, especially at the low P concentration (20 mg/L). The phosphorus removal efficiency was higher but increased slowly when the initial P concentration increased and the reaction rate accelerated. The removal efficiency of phosphate also increased with the increase of Ca/P ratio and pH value and decreased with the decrease of CO32- concentration. The optimized reaction conditions were Ca/P ratio of 3.33 and pH value of 9.0 when compared the whole experimental results. There was no obvious decrease of the inhibitory effect of CO32- on the reaction of calcium phosphate precipitation when the solution temperature increased. Moreover, most of the obtained precipitate was hydroxyapatite under the conditions of no CO32-, CP of 60 mg/L, Ca/P of 1.67,pH value of 9.0 and temperature of 20℃. However, most of the obtained precipitates were the mixture of calcium phosphate and carbonate-hydroxyapatite when the CO32- concentration was 30 mmol/L.
  • 加载中
  • [1] Steen I. Phosphorus availability in the 21st century: Management of a non-renewable resource. Phosphorus & Potassium, 1998, (217): 25-31
    [2] Biplob K. B., Katsutoshi I., Hiroyuki H., et al. Leaching of phosphorus from incinerated sewage sludge ash by means of acid extraction followed by adsorption on orange waste gel. Environmental Sciences, 2009, 21(12): 1753-1760
    [3] Chen X., Hainan K., Wu D., et al. Phosphate removal and recovery through crystallization of hydroxyapatite using xonotlite as seed crystal. Journal of Environment Sciences, 2009, 21(5): 575-580
    [4] Song Y. H., Yuan P., Zhen B. H., et al. Nutrients removal and recovery by crystallization of magnesium ammonium phosphate from synthetic swine wastewater. Chemosphere, 2007, 69(2): 319-324
    [5] Morse G.K., Brett S.W., Guy J.A., et al. Review: Phosphorus removal and recovery technologies. Sciences of the Total Environment,1998, 212(1):69-81
    [6] Driver J., Lijmbach D., Steen I. Why recover phosphorus for recycling, and how?Environmental Technology, 1999, 20(7): 651-662
    [7] Saidou H., Korchef A., Moussa S. B., et al. Struvite precipitation by the dissolved CO2 degasification technique: Impact of the airflow rate and pH. Chemosphere, 2009, 74(2): 338-343
    [8] 刘汝鹏, 曲莹, 王全勇等. 污水处理厂回收磷的方法及工艺探讨. 水处理技术, 2011, 37(2):9-12 Liu R. P., Qu Y., Wang Q. Y. Methods and processes of phosphorus recovery from wastewater treatment plants. Technology of Water Treatment, 2011, 37(2):9-12 ( in Chinese)
    [9] 汪慧贞, 王绍贵. 以磷酸钙盐形式从污水厂回收磷研究. 中国给水排水, 2006, 31(4):93-95 Wang H. Z., Wang S. G. Study on phosphorus recovery by calcium phosphate precipitation from wastewater treatment plant. China Water & Wastewater, 2006, 31(4):93-95 (in Chinese)
    [10] 郝晓地, 衣兰凯, 王崇臣, 等. 磷回收技术的研发现状及发展趋势. 环境科学学报, 2010,30(5): 897-907 Hao X. D., Yi L. K., Wang C. C., et al. Situation and prospects of phosphorus recovery techniques. Acta Scientiae Circumstantiae, 2010, 30(5): 897-907 (in Chinese)
    [11] Christan S., Jana v H., Felix T. Phosphorus recovery from wastewater-state-of-the-art and future potential. Proceedings of the Water Environment Federation, 2011, 2011(1): 299-316
    [12] Song Y. H., Donnert D., Berg U., et al. Seed selections for crystallization of calcium phosphate for phosphorus recovery. Journal of Environmental Sciences, 2007, 19(5): 591-595
    [13] Koutsoukos P., Amjad Z., Tomson M. B., et al. Crystallization of calcium phosphates: A constant composition study. Journal of the American Chemical Society, 1980, 102(5): 1553-1557
    [14] Song Y. H., Hahn H. H., Hoffmann E. The effect of carbonate on the precipitation of calcium phosphate. Environmental Technology, 2002, 23(2): 207-215
    [15] Cao X., Harris W. Carbonate and magnesium interactive effect on calcium phosphate precipitation. Environmental Science and Technology, 2008, 42(2): 436-442
    [16] 高英, 叶荣, 宋永会, 等. 溶液条件对磷酸钙沉淀法回收磷的影响. 安全与环境学报, 2007, 7(3): 58-62 Gao Y., Ye R., Song Y. H., et al.Effects of solution conditions on the precipitation of calcium phosphate for recovery. Journal of Safety and Environment, 2007, 7(3): 58-62 (in Chinese)
    [17] 张自杰,林荣忱,金儒霖.排水工程(下册)(第4版).北京:中国建筑工业出版社, 2000
    [18] 宋永会, 钱锋, 向连城. 磷酸钙沉淀法去除猪场废水中磷的实验研究. 环境科学, 2011, 32(6): 1679-1686 Song Y.H., Qian F., Xiang L.C. Research on phosphorus removal from swine wastewater by precipitation of calcium phosphate. Environmental Science, 2011, 32(6): 1679-1686 (in Chinese)
    [19] 国家环境保护总局.水和废水监测分析方法(第4版).北京: 中国环境科学出版社, 2002
    [20] 王磊, 梅翔, 王金梅, 等.污泥厌氧消化液中碳酸根对回收磷的影响. 环境工程学报, 2010,4(7): 1519-1524 Wang L., Mei X., Wang J. M., et al. Effect of carbonate on phosphorus recovery from anaerobic digestion supernatant of sewage sludge. Chinese Journal of Environmental Engineering, 2010, 4(7): 1519-1524 (in Chinese)
    [21] 刘玉鑫.波谱分析.成都:四川大学出版社, 2004
    [22] 常建华, 董绮功.波谱原理及解析(第3版). 北京:科学出版社, 2012
    [23] 斯塔姆编, 汤鸿霄译. 水化学(第2版). 北京:科学出版社,1984
