Fenton氧化破解污水处理厂污泥

,  ,  ,  ,

downloadPDF

上一篇

下一篇

李小平, 张健, 冼萍, 车锐媚, 刘丽芳. Fenton氧化破解污水处理厂污泥[J]. 环境工程学报, 2013, 7(12): 4709-4713.
引用本文: 李小平, 张健, 冼萍, 车锐媚, 刘丽芳. Fenton氧化破解污水处理厂污泥[J]. 环境工程学报, 2013, 7(12): 4709-4713.
shu
Li Xiaoping, Zhang Jian, Xian Ping, Che Ruimei, Liu Lifang. Sludge disintegration by Fenton reagent oxidation[J]. Chinese Journal of Environmental Engineering, 2013, 7(12): 4709-4713.
Citation: Li Xiaoping, Zhang Jian, Xian Ping, Che Ruimei, Liu Lifang. Sludge disintegration by Fenton reagent oxidation[J]. Chinese Journal of Environmental Engineering, 2013, 7(12): 4709-4713.
shu

Fenton氧化破解污水处理厂污泥

  • 1.

    广西大学环境学院, 南宁 530004

  • 2.

    广西大学食品与轻工学院, 南宁 530004

  • 基金项目:

    国家自然科学基金资助项目（21167003）

    广西研究生创新计划项目（桂学位[2010]44 号）

  • 中图分类号: X705

Sludge disintegration by Fenton reagent oxidation

  • 1.

    School of Environmental, Guangxi University, Nanning 530004, China

  • 2.

    Institute of Light and Food Engineering, Guangxi University, Nanning 530004, China

  • Fund Project:

  • 摘要: 研究了Fenton氧化反应的影响因素pH值、H2O2/Fe2+投加比、反应温度和反应时间对污泥破解效果的影响，并以污泥上清液中蛋白质、糖类、SCOD及污泥TSS、VSS的变化来表征污泥破解的程度。结果表明，最佳破解条件为：pH=5，最佳H2O2/Fe2+投加比为24：1，反应温度为70℃，反应时间为90 min，在该条件下，SCOD、溶解性蛋白质和多糖分别由88.76、19.70和14.95 mg/L增加到3 714.64、2 039.90和289.70 mg/L；TSS及VSS分别由34.60 g/L、19.76 g/L降为26.60 g/L、14.22 g/L，去除率分别为23.12%和 28.14%。Fenton氧化破解污泥，能够有效促进污泥絮体分解，有利于进行后续的厌氧消化处理。
    Abstract: The influences of Fenton oxidation parameters, such as pH value, dosage ratio of H2O2/Fe2+, reaction temperature and reaction time, on the effect of sludge disintegration were investigated, with the content of protein, carbohydrate, soluble chemical oxygen demand (SCOD) in sludge supernatant, and total suspended solids(TSS), volatile suspended solids(VSS) of sludge as characterization parameters of disintegration effect. Results showed that the optimal operational conditions were pH of 5.0, H2O2/Fe2+ (weight dosage ratio) of 24:1, reaction temperature of 70℃ and reaction time of 90 min, respectively. Under these conditions, SCOD, soluble protein and polysaccharide content increased from 88.76, 19.70 and 14.95 mg/L to 3 714.64, 2 039.90 and 289.70 mg/L, respectively. Additionally, TSS and VSS value decreased from 34.60 g/L, 19.76 g/L to 26.60 g/L, 14.22 g/L, respectively, with the removal efficiency of TSS and VSS of 23.12% and 28.14%. As a result, Fenton oxidation is an effective method for sludge reduction, which can effectively promote decomposition of the sludge flocs, and be beneficial to follow-up anaerobic digestion treatment.
  • 加载中
  • [1] 李晓晨, 赵丽, 印华斌. 城市污水处理过程中污泥的理化特性研究. 中国给水排水, 2008, 24(9):78-82 Li X. C., Zhao L., Yin H. B. Study on physicochemical properties of sludge during municipal wastewater treatment process. China Water and Wastewater, 2008, 24(9):78-82(in Chinese)
    [2] 张少辉, 华玉妹. 污泥厌氧消化的强化处理技术. 环境保护科学, 2004, 30(5):13-15 Zhang S. H., Hua Y. M. Enhancement for anaerobic digestion technology of sewage sludge. Environental Protection Science, 2004, 30(5): 13-15(in Chinese)
    [3] 霍真, 王芬, 季民. 污泥破解技术的研究与进展.工业水处理, 2005, 25(9):16-19 Huo Z., Wang F., Ji M. The current research on the technology of sludge disruption. Industrial Water Treatment, 2005, 25(9):16-19(in Chinese)
    [4] 牟艳艳, 于鑫, 郑正, 等. 污泥厌氧消化预处理方法研究进展, 中国给水排水, 2004, 20(7):31-33 Mou Y. Y., Yu X., Zheng Z, et al. Research progress on pretreatment method of anaerobic sludge digestion. China Water and Wastewater, 2004, 20(7):31-33(in Chinese)
    [5] 王治军, 王伟. 热水解预处理改善污泥的厌氧消化性能. 环境科学, 2005, 26(1):68-71 Wang Z. J., Wang W. Enhancement of sewage sludge anaerobic digestibil ity by thermal hydrolysis pretreatment. Environmental Science, 2005, 26(1):68-71(in Chinese)
    [6] Tokumura M., Sekine M., Yoshinari M., et al. Photo-Fenton process for excess sludge disintegration. Process Biochem., 2007, 42(3):627-633
    [7] Tokumura M., Katoh H., Katoh T., et al. Solubilization of excess sludge in activated sludge process using the solar photo-Fenton reaction. Journal of Hazardous Materials, 2009, 162(2-3): 1390-1396
    [8] Neyens E., Baeyens J., WeemaesM., et al. Pilot-scale peroxidation (H2O2) of sewage sludge. Journal Hazardous Materials, 2003, 98(1-3)B: 91-106
    [9] 钟恒文, 二宫加奈. 生污泥的Fenton氧化处理. 中国给水排水, 2003, 19(8):46-47 Zhong H., W., Ninomiya Kana, Fenton oxidation treatment of sludge. China Water and Wastewater, 2003, 19(8):46-47(in Chinese)
    [10] 李娟, 张盼月, 曾光明, 等. Fenton 氧化破解剩余污泥中的外聚合物. 环境科学, 2009, 30(2): 475-479 Li J., Zhang P. Y., Zeng G. M., et al. Extracellular polymeric substances disintegration by fenton oxidation of excess sludge. Environmental Science, 2009, 30(2): 475-479(in Chinese)
    [11] 陈英文, 刘明庆, 惠祖刚, 等. Fenton氧化破解剩余污泥的实验研究. 环境工程学报, 2011, 5(2):409-413 Chen Y. W., Liu M. Q., Hui Z. G., et al. Experimental study on excess sludge disintegration by Fenton oxidation. Chinese Journal of Environmental Engineering, 2011, 5(2):409-413(in Chinese)
    [12] Lu M., Lin C., Liao C., et al. Influence of pH on the dewatering of activated sludge by Fenton's reagent. Water Sci. Technol., 2011, 44(10):327-332
    [13] Neyens E., Baeyens J. A review of classic Fenton's peroxidation as an advanced oxidation technique. Journal of Hazardous Materials, 2003, 98(1-3)B:33-50
    [14] 赵启文, 刘岩. 芬顿(Fenton) 试剂的历史与应用. 化学世界, 2005, 46(5):319-320 Zhao Q. W., Liu Y. Fenton reagent history and application. Chemistry World, 2005, 46(5):319-320(in Chinese)
    [15] German H. Rossetti, Enrique D. Albizzati, Orlando M. Alfano. Decomposition of formic acid in a water solution employing the photo-Fenton reaction. Ind. Eng.Chem. Res., 2002, 41(6):1436-1444
