硫酸铅在柠檬酸钠-乙酸体系中的浸出转化

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

刘玲静, 何雄, 朱新锋, 李磊, 杨丹妮, 杨家宽. 硫酸铅在柠檬酸钠-乙酸体系中的浸出转化[J]. 环境工程学报, 2013, 7(1): 143-148.
引用本文: 刘玲静, 何雄, 朱新锋, 李磊, 杨丹妮, 杨家宽. 硫酸铅在柠檬酸钠-乙酸体系中的浸出转化[J]. 环境工程学报, 2013, 7(1): 143-148.
shu
Liu Lingjing, He Xiong, Zhu Xinfeng, Li Lei, Yang Danni, Yang Jiakuan. Leaching and desulphurisation of PbSO4 in sodium citrate and acetic acid solution[J]. Chinese Journal of Environmental Engineering, 2013, 7(1): 143-148.
Citation: Liu Lingjing, He Xiong, Zhu Xinfeng, Li Lei, Yang Danni, Yang Jiakuan. Leaching and desulphurisation of PbSO4 in sodium citrate and acetic acid solution[J]. Chinese Journal of Environmental Engineering, 2013, 7(1): 143-148.
shu

硫酸铅在柠檬酸钠-乙酸体系中的浸出转化

  • 1.

    华中科技大学环境科学与工程学院,武汉 430074

  • 2.

    河南城建学院市政与环境工程学院,平顶山 467023

  • 基金项目:

    国家自然科学基金资助项目(50804017)

    国家大学生科技创新活动基金资助项目(2009056)

    武汉市科技攻关计划项目(20120321100)

    湖北省自然科学基金重点项目(杰出青年基金)(2011CDA083)

  • 中图分类号: TF812

Leaching and desulphurisation of PbSO4 in sodium citrate and acetic acid solution

  • 1.

    College of Environmental Science and Engineering, Huazhong University of Science and Technology, Wuhan 430074, China

  • 2.

    Department of Environment and Municipal Engineering, Henan University of Urban Construction, Pingdingshan 467023, China

  • Fund Project:

  • 摘要: 硫酸铅可以在柠檬酸钠-乙酸体系中脱硫转化生成柠檬酸铅。考察了柠檬酸钠投加量、反应时间、固液比以及反应温度对PbSO4浸出转化的影响。实验结果表明,PbSO4的转化率随着柠檬酸钠投加量和反应时间的增加而增大,固液比和反应温度对浸出过程影响不大。溶液中溶解的铅含量随着柠檬酸钠投加量的增大而增大,其他条件对其影响不明显。最佳浸出工艺条件是:柠檬酸钠与PbSO4的物质的量之比为2∶1,固液比为1/5~1/3,反应温度为25℃,反应时间为2 h,此时PbSO4的转化率可达到99%左右,溶液中的铅含量为总铅的3.8%左右。PbSO4浸出得到[Pb3(C6H5O7)2]·3H2O,它在350℃左右可完全分解,得到PbO/Pb粉末。
    Abstract: In this study, to achieve lead recovery simultaneously with desulphurization, PbSO4 were reacted with sodium citrate and acetic acid in aqueous media, and lead was recovered as lead citrate in this process. Optimal leaching conditions were determined by investigating the effect of concentration, reaction time, the initial PbSO4/water and temperature. The results show that the conversion rate of PbSO4 in the solution increases with the increase of the concentration of sodium citrate and reaction time, while other factors show no significant effects. The remaining lead content in the filtrate solution only increases with the increase of the concentration of sodium citrate. The optimal conditions for leaching 1 mol of PbSO4 at 25℃were found to be: 2 mol of sodium citrate solution; 2 h of reaction time and 1/3~1/5 as the starting PbSO4/water ratio. Under the experimental conditions, the conversion rate of PbSO4 was about 99%, and the remaining lead content in the filtrate solution was 3.8% of the total lead. Pure citrate product [Pb3(C6H5O7)2]·3H2O was crystallized from the solution, which could be decomposed to PbO/Pb powder at 350℃.
  • 加载中
  • [1] 周洪武. 废铅酸蓄电池铅料特点和冶炼技术选择.资源再生, 2007,(5): 19-22 Zhou Hongwu. Characters of the waste lead acid storage battery and its melting technology options. Resource Recycling, 2007, (5):19-22(in Chinese)
    [2] 周正华. 从废旧蓄电池中无污染火法冶炼再生铅及合金. 上海有色金属, 2002, 23(4): 157-163 Zhou Zhenghua. Pollution free pyrometallurgical regeneration of lead and its alloys from used and scrapped batteries. Shanghai Nonferrous Metals, 2002, 23(4):157-163 (in Chinese)
    [3] 齐美富, 郑园芳, 桂双林. 废铅酸蓄电池中铅膏氯盐体系浸取铅的动力学研究. 矿冶工程, 2010, 30(6): 61-64 Qi Meifu, Zheng Yuanfang, Gui Shuanglin. Kinetic study on leaching lead from waste lead-acid batteries for lead plaster chloride system. Mining and Metallurgical Engineering, 2010, 30(6): 61-64(in Chinese)
    [4] 胡红云,朱新锋,杨家宽.湿法回收废旧铅酸蓄电池中铅的研究进展. 化工进展, 2009, 28(9): 1662-1666 Hu Hongyun, Zhu Xinfeng, Yang Jiakuan. Progress in the hydrometallurgical process for recovering lead from scrap lead-acid batteries. Chemical Industry and Engineering Progress, 2009, 28(9): 1662-1666(in Chinese)
    [5] McDonald H. D.Method of recovering lead values from battery sludge: US, 4229271, 1980. 10-21
    [6] Prengaman R. D.Recovering lead from batteries. Journal of Metals,1995,47(1): 31-33
    [7] Cole Jr Ernest R., Lee A. Y., Paulson D. L.Update on recovering lead from scrap batteries. Journal of Metals, 1985, 37(2): 79-83
    [8] Olper M., Fracchia P.Hydrometallurgica1 process for an overall recovery of the components of exhausted lead-acid batteries US, 4769116, 1988-9-6
    [9] 陈维平, 龚建森, 黎七中. Fe2+还原废蓄电池泥渣中PbO2的试验研究. 湖南大学学报, 1995, 22(6): 53-58 Chen Weiping, Gong Jiansen, Li Qizhong. Research on process for reducing PbO2 contained in lead baffery scrap with Fe2+. Journal of Hunan University, 1995, 22(6): 53-58(in Chinese)
    [10] 陈维平. 一种湿法回收废铅蓄电池填料的新技术. 湖南大学学报, 1996, 23(6): 111-115 Chen Weiping. New technology of hydrometallurgical recovering lead from waste battery slurry. Journal of Hunan University, 1996, 23(6): 111-115(in Chinese)
    [11] 刘辉, 银星宇, 覃文庆,等. 铅膏碳酸盐转化过程的研究.湿法冶金, 2005, 24(3):146-148 Liu Hui, Yin Xingyu, Qin Wenqing, et al. Conversion of paste in exhausted lead storage batteries into lead carbonate in sodium carbonate solution. Hydrometallugy of China, 2005, 24(3): 146-148(in Chinese)
    [12] Kumar. R.V., Sonmez. M. S., Kotzeva. V. P. UK Patent Application No: 0622249.1, 2006; Patent PCT/GB2007/004222; WO2008/056125
    [13] Sonmez M. S., Kumar R. V. Leaching of waste battery paste components, Part1: Lead citrate synthesis from PbO and PbO2. Hydrometallurgy, 2009, 95(1-2): 53-60
    [14] Sonmez M. S.,Kumar R. V. Leaching of waste battery paste components, Part 2: Leaching and desulphurisation of PbSO4 by citric acid and sodium citrate solution, Hydrometallurgy, 2009, 95(1-2): 82-86
    [15] 朱新锋, 刘万超, 杨海玉, 等. 以废铅酸电池铅膏制备超细氧化铅粉末. 中国有色金属学报, 2010, 20(1): 132-136 Zhu Xinfeng, Liu Wanchao, Yang Haiyu, et al. Preparation of ultrafine PbO powders from lead paste in spent lead acid battery. The Chinese Journal of Nonferrous Metals, 2010, 20(1): 132-136(in Chinese)
