宜宾市PM25中碳组分的污染特性及来源分析

,  ,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

尹寒梅, 陈军辉, 冯小琼, 徐雪梅, 姜涛, 钱骏, 叶宏. 宜宾市PM25中碳组分的污染特性及来源分析[J]. 环境化学, 2019, 38(4): 738-745. doi: 10.7524/j.issn.0254-6108.2018061504
引用本文: 尹寒梅, 陈军辉, 冯小琼, 徐雪梅, 姜涛, 钱骏, 叶宏. 宜宾市PM25中碳组分的污染特性及来源分析[J]. 环境化学, 2019, 38(4): 738-745. doi: 10.7524/j.issn.0254-6108.2018061504
shu
YIN Hanmei, CHEN Junhui, FENG Xiaoqiong, XU Xuemei, JIANG Tao, QIAN Jun, YE Hong. Pollution characteristics and source analysis of carbonaceous aerosol in PM2.5 in Yibin, China[J]. Environmental Chemistry, 2019, 38(4): 738-745. doi: 10.7524/j.issn.0254-6108.2018061504
Citation: YIN Hanmei, CHEN Junhui, FENG Xiaoqiong, XU Xuemei, JIANG Tao, QIAN Jun, YE Hong. Pollution characteristics and source analysis of carbonaceous aerosol in PM2.5 in Yibin, China[J]. Environmental Chemistry, 2019, 38(4): 738-745. doi: 10.7524/j.issn.0254-6108.2018061504
shu

宜宾市PM25中碳组分的污染特性及来源分析

  • 1.

    四川省环保科技工程有限责任公司, 成都, 610041;

  • 2.

    四川省环境保护科学研究院, 成都, 610041

Pollution characteristics and source analysis of carbonaceous aerosol in PM2.5 in Yibin, China

  • 1.

    Sichuan Province Environmental Protection Technology Engineering Co., Ltd., Chengdu, 610041, China;

  • 2.

    Sichuan Research Institute of Environmental Protection, Chengdu, 610041, China

  • 摘要: 2017年1月-12月期间在四川省宜宾市布置4个点位，共采集360个PM2.5样品膜，采用美国沙漠研究所DRI Model 2001型热光分析仪测定PM2.5样品中OC、EC的浓度值，应用OC/EC比值法对SOC进行了估算.结果表明，宜宾市PM2.5年均浓度为75.2 μg·m-3.OC、EC年均浓度分别为14.3 μg·m-3和4.30 μg·m-3，季节变化趋势为冬季>秋季>春季>夏季，OC占PM2.5比例为19.0%，为PM2.5重要组成部分.SOC年均浓度为4.70 μg·m-3，对OC贡献较大，在OC中占比为29.3%；SOC在OC中的占比春季>冬季≈秋季>夏季.进一步对OC1、OC2、OC3、OC4、EC1、EC2、EC3、和OPC进行主成分分析，结果表明机动车尾气、燃煤排放和生物质燃烧是宜宾市PM2.5中OC和EC的主要贡献源，可贡献PM2.5中碳组分的54.0%-69.0%.
    Abstract: Three hundred and sixty PM2.5 samples were collected in locations in Yibin,Sichuan Province, from January 2017 to December 2017. The concentrations of organic carbon (OC) and element carbon (EC) in PM2.5 samples were determined by DRI Model 2001 Thermo/Optical Carbon Analyzer. The secondary organic carbon(SOC)was then estimated by the OC/EC ratio. The results showed that the annual average concentration of PM2.5 in Yibin was 75.2 μg·m-3. The annual average concentrations of OC and EC were 14.3 μg·m-3 and 4.30 μg·m-3, respectively. Also, the OC and EC concentrations showed a seasonal variation in an order of winter > autumn > spring > summer. OC accounted for 19.0% of PM2.5, which was an important part of PM2.5. Annual average concentration of SOC was 4.70 μg·m-3, accounting for 29.3% of total OC. Note that the proportion of SOC in OC followed the order of spring > winter ≈ autumn > summer. Further principal component analysis (PCA) of OC1, OC2, OC3, OC4, EC1, EC2, EC3 and OPC showed that motor vehicle exhaust, coal-fired emissions and biomass burning were the main sources of OC and EC in PM2.5 in Yibin, contributing 54.0%-69.0% of the carbonaceous aerosol in PM2.5.
  • 加载中
  • [1] DOCKERY D W, POPE C A. Acute respiratory effects of particulate air pollution[J]. Annual Review of Public Health, 1994, 15(1):107-132.
    [2] JIMENEZ J L, CANAGARATNA M R, DONAHUE N M, et al. Evolution of organic aerosols in the atmosphere[J]. Science, 2009, 326(5959):1525-1529.
    [3] PANDIS S N, HARLEY R A, CASS G R, et al. Secondary organic aerosol formation and transport[J]. Atmospheric Environment. Part A. General Topics, 1992, 26(13):2269-2282.
    [4] TURPIN B J, HUNTZICKER J J. Identification of secondary organic aerosol episodes and quantitation of primary and secondary organic aerosol concentrations during SCAQS[J]. Atmospheric Environment, 1995, 29(23):3527-3544.
    [5] CHAN Y C, SIMPSON R W, MCTAINSH G H, et al. Source apportionment of visibility degradation problems in Brisbane (Australia) using the multiple linear regression techniques[J]. Atmospheric Environment, 1999, 33(19):3237-3250.
    [6] 段凤魁, 贺克斌, 刘咸德, 等. 含碳气溶胶研究进展:有机碳和元素碳[J]. 环境工程学报,2007,1(8):1-8.

    DUAN F K, HE K B, LIU X D, et al. Review of carbonaceous aerosol studies:Organic carbon and elemental carbon[J]. 2007, 1(8):1-8(in Chinese).

    [7] 迟旭光, 段凤魁, 董树屏, 等. 北京大气颗粒物中有机碳和元素碳的浓度水平和季节变化[J].中国环境监测,2000,16(3):35-38.

    CHI X G, DUAN F K, DONG S P, et al. Concentration level seasonal variation of organic carbon and elemental carbon in Beijing aerosol[J]. Environment Monitoring in China, 2000, 16(3):35-38(in Chinese).

    [8] DUAN J, TAN J, WANG S, et al. Roadside, Urban, and Rural comparison of size distribution characteristics of PAHs and carbonaceous components of Beijing, China[J]. Journal of Atmospheric Chemistry, 2012, 69(4):337-349.
    [9] LI W, BAI Z. Characteristics of organic and elemental carbon in atmospheric fine particles in Tianjin, China[J]. Particuology, 2009, 7(6):432-437.
    [10] 郭育红, 辛金元, 王跃思, 等. 唐山市大气颗粒物 OC/EC 浓度谱分布观测研究[J]. 环境科学, 2013, 34(7):2497-2504.

    GUO Y H, XIN J Y, WANG Y S, et al. Observation of size distribution of atmospheric OC/EC in Tangshan, China[J].Environmental Science, 2013, 34(7):2497-2504(in Chinese).

    [11] FENG Y, CHEN Y, GUO H, et al. Characteristics of organic and elemental carbon in PM2.5 samples in Shanghai, China[J]. Atmospheric Research, 2009, 92(4):434-442.
    [12] 王广华, 位楠楠, 刘卫, 等. 上海市大气颗粒物中有机碳 (OC) 与元素碳 (EC) 的粒径分布[J]. 环境科学, 2010, 31(9):1993-2001.

    WANG G H, WAI N N, LIU W, et al. Size distribution of organic carbon (OC) and elemental carbon (EC) in shanghai atmospheric particles[J]. Environmental Science, 2010, 31(9):1993-2001(in Chinese).

    [13] 张予燕, 俞美香, 任兰, 等. 南京大气细颗粒中有机碳与元素碳污染特征[J]. 环境监测管理与技术, 2012,24(4):30-32.

    ZHANG Y Y, YU M X, REN L, et al. Organic and element carbon pollution characteristics of atmospheric fine particles in Nanjing[J].The Administration and Technique of Environmental Monitoring, 2012,24(4):30-32(in Chinese).

    [14] 刘刚, 张旭贤, 滕卫林, 等. 杭州市大气PM2.5中有机碳元素碳的同位素组成[J]. 科学通报, 2007, 52(16):1935-1937.

    LIU G, ZHANG X X, TENG W L, et al. The isotopic composition of organic carbon in PM2.5 in Hangzhou[J].Chinese Science Bulletin, 2007, 52(16):1935-1937(in Chinese).

    [15] CAO J J, LEE S C, Chow J C, et al. Spatial and seasonal distributions of carbonaceous aerosols over China[J]. Journal of Geophysical Research:Atmospheres, 2007, 112(D22):1-9.
    [16] YU J, CHEN T, BENJAMIN G, et al. Characteristics of carbonaceous particles in Beijing during winter and summer 2003[J]. Advances in Atmospheric Sciences, 2006, 23(3):468-473.
    [17] 史国良, 陈刚, 田瑛泽, 等. 天津大气PM2. 5中碳组分特征和来源分析[J]. 环境污染与防治, 2016, 38(1):1-7.

    SHI G L, CHEN G, TIAN Y Z, et al. Characteristic and sources of carbon fractions in PM2.5 in Tianjin urban area[J]. Environmental Pollution and Control, 2016,38(1):1-7(in Chinese).

    [18] 黄虹, 李顺诚, 曹军骥, 等. 广州市夏季室内外PM2.5中有机碳, 元素碳的分布特征[J].环境科学学报, 2005,25(9):1242-1249

    HUANG H, LI S C, CAO J Y, et al. Characterization of indoor/outdoor organic and elemental carbon in PM2.5 during summer in Guangzhou city[J]. Acta Scientiae Circumstantiae, 2005, 25(9):1242-1249(in Chinese).

    [19] YU S, DENNIS R L, BHAVE P V, et al. Primary and secondary organic aerosols over the United States:Estimates on the basis of observed organic carbon (OC) and elemental carbon (EC), and air quality modeled primary OC/EC ratios[J]. Atmospheric Environment, 2004, 38(31):5257-5268.
    [20] CHOW J C, WATSON J G, LU Z, et al. Descriptive analysis of PM2.5 and PM10 at regionally representative locations during SJVAQS/AUSPEX[J]. Atmospheric Environment, 1996, 30(12):2079-2112.
    [21] MICHAEL J K, SARAH G R, MICHAEL A R, et al. Lubricating oil and fuel contributions to particulate matter emissions from light-duty gasoline and heavy-duty diesel vehicles[J]. Environmental Science and Technology, 2008, 42(1):235-242.
    [22] SAYLOR R D, EDGERTON E S, HARTSELL B E. Linear regression techniques for use in the EC tracer method of secondary organic aerosol estimation[J]. Atmospheric Environment, 2006, 40(39):7546-7556.
    [23] HO J L, URPIN B J, RUSSELL L M, et al. Organic and elemental carbon measurements during ACE-Asia suggest a longer atmospheric lifetime for elemental carbon[J]. Environmental Science and Technology, 2003, 37(14):3055-3061.
    [24] HO J L, TURPIN B J. Origins of primary and secondary organic aerosol in Atlanta:results of time resolved measurements during the Atlanta duper site experiment[J]. Environmental Science and Technology, 2002, 36(21):4489-4496.
    [25] CAO J J, CHOW J C, LEE S C, et al. Characterization and source apportionment of atmospheric organic and elemental carbon during fall and winter of 2003 in Xi an, China[J]. Atmos Chem Phys, 2005 (5):3561-3593.
