基于静电纺丝膜的Fenton法降解双氯芬酸钠

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

庄淑婷, 徐冰, 刘博, 康敉, 程荣, 李洁. 基于静电纺丝膜的Fenton法降解双氯芬酸钠[J]. 环境工程学报, 2016, 10(9): 4895-4901. doi: 10.12030/j.cjee.201504105
引用本文: 庄淑婷, 徐冰, 刘博, 康敉, 程荣, 李洁. 基于静电纺丝膜的Fenton法降解双氯芬酸钠[J]. 环境工程学报, 2016, 10(9): 4895-4901. doi: 10.12030/j.cjee.201504105
shu
ZHUANG Shuting, XU Bing, LIU Bo, KANG Mi, CHENG Rong, LI Jie. Degradation of diclofenac sodium by electrospinning fibers-based Fenton method[J]. Chinese Journal of Environmental Engineering, 2016, 10(9): 4895-4901. doi: 10.12030/j.cjee.201504105
Citation: ZHUANG Shuting, XU Bing, LIU Bo, KANG Mi, CHENG Rong, LI Jie. Degradation of diclofenac sodium by electrospinning fibers-based Fenton method[J]. Chinese Journal of Environmental Engineering, 2016, 10(9): 4895-4901. doi: 10.12030/j.cjee.201504105
shu

基于静电纺丝膜的Fenton法降解双氯芬酸钠

  • 1.

    中国人民大学环境学院, 北京 100872

  • 基金项目:

    国家自然科学基金资助项目（51108454）

    中国人民大学科学研究基金（中央高校基本科研业务费专项资金资助）（14XNLQ02）

  • 中图分类号: X703

Degradation of diclofenac sodium by electrospinning fibers-based Fenton method

  • 1.

    School of Environment and Natural Resources, Renmin University of China, Beijing 100872, China

  • Fund Project:

  • 摘要: 通过浸渍法将铁盐负载于静电纺丝纤维膜制备了类Fenton催化剂，并通过扫描电子显微镜（SEM）对静电纺丝膜进行了表征，研究了该催化剂降解双氯芬酸钠的特性及其重复利用率。结果表明，静电纺丝纤维膜反应前后膜结构良好，反应过程中铁离子几乎无溶出；膜对双氯芬酸钠有一定的吸附能力，去除率约为6.96%。当双氯芬酸钠初始浓度为20 mg·L-1，按0.310 g·（100 mL）-1比例加入催化剂时，H2O2最佳用量为340 mg·L-1。溶液的初始pH值对实验结果影响较大，酸性条件更利于双氯芬酸钠的降解，最佳pH值为3.14，但该催化剂所适用的pH值范围较之传统Fenton法有明显拓展。所制备的催化剂重复利用率高，循环使用4次后，催化活性无明显改变，4 h的去除率依然高达95%以上。反应中双氯芬酸钠主要生成乙酸等小分子化合物，最终可氧化为CO2和H2O。
    Abstract: A Fenton-like catalyst was synthesized by loading ferric salt onto electrospinning fibers, and characterized with a scanning electron microscope (SEM). The degradation of diclofenac sodium (DS) by the synthesized catalyst was studied, along with the catalyst recycle rate. The results indicated that the fibers were well-formed before and after the reaction, and that nearly no iron ion was released into the solution. The adsorption of DS by the catalyst was approximately 6.69%. When the initial concentration of DS was 20 mg·L-1, and the dosage of catalysts was 0.310 g·(100 mL)-1, the optimal dosage of H2O2 was 340 mg·L-1. The effect of the initial pH value was significant, and acidic conditions were beneficial for the degradation of DS. In this study, the optimal pH value was 3.14; however, the applicable range of pH of the synthesized catalyst was broader than that of the traditional Fenton catalyst. The recycle rate of the catalyst was high, and the removal rate exceeded 95% for a catalyst used four times after reacting for 4 h. DS was primarily transformed into small molecules, such as acetic acid, and could eventually be oxidized into CO2 and H2O.
  • 加载中
  • [1] VIENO N. M., HÄRKKI H., TUHKANEN T., et al. Occurrence of pharmaceuticals in river water and their elimination in a pilot-scale drinking water treatment plant. Environmental Science & Technology, 2007, 41(14):5077-5084
    [2] 王曦曦, 张继彪, 郑正, 等. 介质阻挡放电对水中双氯芬酸钠的降解. 环境化学, 2010, 29(4):675-679 WANG Xixi, ZHANG Jibiao, ZHENG Zheng, et al. Dielectric barrier discharge induced degradation of diclofenac sodium in aqueous solution. Environmental Chemistry, 2010, 29(4):675-679(in Chinese)
    [3] KASPRZYK-HORDERN B., DINSDALE R. M., GUWY A. J., et al. The occurrence of pharmaceuticals, personal care products, endocrine disruptors and illicit drugs in surface water in South Wales, UK. Water Research, 2008, 42(13):3498-3518
    [4] RABIET M., TOGOLA A., BRISSAUD F., et al. Consequences of treated water recycling as regards pharmaceuticals and drugs in surface and ground waters of a medium-sized Mediterranean catchment. Environmental Science & Technology, 2006, 40(17):5282-5288
    [5] WOLF J. C., RUEHL-FEHLERT C., SEGNER H. E., et al. Pathology working group review of histopathologic specimens from three laboratory studies of diclofenac in trout. Aquatic Toxicology, 2014, 146:127-136
    [6] SARAVANAN M., HUR J. H., ARUL N., et al. Toxicological effects of clofibric acid and diclofenac on plasma thyroid hormones of an Indian major carp, Cirrhinus mrigala during short and long-term exposures. Environmental Toxicology and Pharmacology, 2014, 38(3):948-958
    [7] WANG Yingling, LIU Haijin, LIU Guoguang, et al. Oxidation of diclofenac by aqueous chlorine dioxide:Identification of major disinfection byproducts and toxicity evaluation. Science of the Total Environment, 2014, 473-474:437-445
    [8] WANG Yingling, LIU Haijin, LIU Guopguang, et al. Oxidation of diclofenac by potassium ferrate (VI):Reaction kinetics and toxicity evaluation. Science of the Total Environment, 2015, 506-507:252-258
    [9] CHENG Hanyang, SONG Dean, LIU Huijuan, et al. Permanganate oxidation of diclofenac:The pH-dependent reaction kinetics and a ring-opening mechanism. Chemosphere, 2015, 136:297-304
    [10] NIE Er, YANG Mo, WANG Dong, et al. Degradation of diclofenac by ultrasonic irradiation:Kinetic studies and degradation pathways. Chemosphere, 2014, 113:165-170
    [11] 郑红涛. 修饰碳纳米管电极降解废水中PPCPs的研究. 北京:北京化工大学硕士学位论文, 2011 ZHENG Hongtao. Degradation of PPCPs in water by modified-MWCNTS electrode. Beijing:Master Dissertation of Beijing University of Chemical Technology, 2011(in Chinese)
    [12] 周慧慧. 紫外光降解水中典型羧酸类PPCPs的效能与机理. 杭州:浙江大学硕士学位论文, 2014 ZHOU Huihui. Photodegradation performance and mechanism of typical carboxylic PPCPs in water by UV irradiation. Hangzhou:Master Dissertation of Zhejiang University, 2014(in Chinese)
    [13] SHAKEEL F., HAQ N., AHMED M. A., et al. Removal of diclofenac sodium from aqueous solution using water/Transcutol/ethylene glycol/Capryol-90 green nanoemulsions. Journal of Molecular Liquids, 2014, 199:102-107
    [14] 李海涛, 李玉平, 张安洋, 等. 新型非均相电-Fenton技术深度处理焦化废水. 环境科学, 2011, 32(1):171-178 LI Haitao, LI Yuping, ZHANG Anyang, et al. Advanced treatment of coking wastewater with a novel heterogeneous electro Fenton technology. Environmental Science, 2011, 32(1):171-178(in Chinese)
    [15] 赵庆良, 卜琳, 杨俊晨, 等. 腐蚀电池-Fenton处理渗滤液溶解性有机物光谱特征. 环境科学, 2011, 32(8):2378-2384 ZHAO Qingliang, BU Lin, YANG Junchen, et al. Spectroscopy properties of dissolved organic matter in landfill leachate during corrosion cell-Fenton post-treatment. Environmental Science, 2011, 32(8):2378-2384(in Chinese)
    [16] 陶长元, 刘作华, 李晓红, 等. 超声波促进Fenton法脱色甲基橙溶液的研究. 环境科学, 2005, 26(5):111-114 TAO Changyuan, LIU Zuohua, LI Xiaohong, et al. Study on ultrasound-assisted decolorization of methyl orange with Fenton reagent. Environmental Science, 2005, 26(5):111-114(in Chinese)
    [17] 张钰, 顾彦, 杨慧, 等. 赤铁矿光助类Fenton降解有毒有机污染物. 环境科学, 2012, 33(4):1247-1251 ZHANG Yu, GU Yan, YANG Hui, et al. Degradation of organic pollutants by photo-Fenton-like system with hematite. Environmental Science, 2012, 33(4):1247-1251(in Chinese)
    [18] 陈传好, 谢波, 任源, 等. Fenton试剂处理废水中各影响因子的作用机制. 环境科学, 2000, 21(3):93-96 CHEN Chuanhao, XIE Bo, REN Yuan, et al. The mechanisms of affecting factors in treating wastewater by Fenton reagent. Environmental Science, 2000, 21(3):93-96(in Chinese)
    [19] PAPOUTSAKIS S., MIRALLES-CUEVAS S., GONDREXON N., et al. Coupling between high-frequency ultrasound and solar photo-Fenton at pilot scale for the treatment of organic contaminants:An initial approach. Ultrasonics Sonochemistry, 2015, 22:527-534
    [20] 于万禄, 熊振湖, 马华继. Photo-Fenton法降解水中新型污染物双氯芬酸及降解产物的毒性评价. 环境科学学报, 2009, 29(10):2070-2075 YU Wanlu, XIONG Zhenhu, MA Huaji. Degradation of the emergent pollutant diclofenac in water by photo-Fenton and toxicity evaluation of its degradation products. Acta Scientiae Circumstantiae, 2009, 29(10):2070-2075(in Chinese)
    [21] LI Mo, ZENG Zequan, LI Yingwen, et al. Treatment of amoxicillin by O3/Fenton process in a rotating packed bed. Journal of Environmental Management, 2015, 150:404-411
    [22] SOUZA B. M., DEZOTTI M. W. C., BOAVENTURA R. A. R., et al. Intensification of a solar photo-Fenton reaction at near neutral pH with ferrioxalate complexes:A case study on diclofenac removal from aqueous solutions. Chemical Engineering Journal, 2014, 256:448-457
    [23] LI Renchao, JIN Xiaoying, MEGHARAj M., et al. Heterogeneous Fenton oxidation of 2, 4-dichlorophenol using iron-based nanoparticles and persulfate system. Chemical Engineering Journal, 2015, 264:587-594
    [24] 史向阳, 肖仕丽, 王善元. MWCNTs增强的零价纳米铁/静电纺纳米纤维毡的制备:中国, CN 101624757. 2010-01-13
    [25] RIZZO L., MERIC S., KASSINOS D., et al. Degradation of diclofenac by TiO2 photocatalysis:UV absorbance kinetics and process evaluation through a set of toxicity bioassays. Water Research, 2009, 43(4):979-988
    [26] 中华人民共和国国家环境保护总局. HJ/T 345-2007水质铁的测定邻菲啰啉分光光度法(试行). 北京:中国环境科学出版社, 2007
    [27] 程丽华, 黄君礼, 高会旺. Fenton试剂对水中酚类物质的去除效果研究. 环境科学与技术, 2004, 27(4):3-4 CHENG Lihua, HUANG Junli, GAO Huiwang. Study on treatment efficiency of phenolic compounds by Fenton reagent. Environmental Science & Technology, 2004, 27(4):3-4(in Chinese)
    [28] 徐祺琪, 陈维芳, 沈晓慧, 等. Fenton高级氧化技术去除水中有机污染物2-MIB的影响因素研究. 水资源与水工程学报, 2014, 25(2):158-161 XU Qiqi, CHEN Weifang, SHEN Xiaohui, et al. Study on factors affecting removal of organic pollutant 2-MIB in water by using Fenton advanced oxidation process. Journal of Water Resources & Water Engineering, 2014, 25(2):158-161(in Chinese)
    [29] 王艳, 王曙光, 宋祖德, 等. 煤渣在改良Fenton法处理结晶紫废水中的应用. 山东科技大学学报(自然科学版), 2014, 33(1):64-67 WANG Yan, WANG Shuguang, SONG Zude, et al. Application of Cinder in treatment of crystal violet wastewater in the improved Fenton method. Journal of Shandong University of Science and Technology (Natural Science), 2014, 33(1):64-67(in Chinese)
    [30] GULKAYA I., SURUCU G. A., DILEK F. B., et al. Importance of H2O2/Fe2+ ratio in Fenton's treatment of a carpet dyeing wastewater. Journal of Hazardous Materials, 2006, 136(3):763-769
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2341
  • HTML全文浏览数:  1877
  • PDF下载数:  527
  • 施引文献:  0
出版历程
  • 收稿日期:  2015-05-13
  • 刊出日期:  2016-09-10
庄淑婷, 徐冰, 刘博, 康敉, 程荣, 李洁. 基于静电纺丝膜的Fenton法降解双氯芬酸钠[J]. 环境工程学报, 2016, 10(9): 4895-4901. doi: 10.12030/j.cjee.201504105
引用本文: 庄淑婷, 徐冰, 刘博, 康敉, 程荣, 李洁. 基于静电纺丝膜的Fenton法降解双氯芬酸钠[J]. 环境工程学报, 2016, 10(9): 4895-4901. doi: 10.12030/j.cjee.201504105
shu
ZHUANG Shuting, XU Bing, LIU Bo, KANG Mi, CHENG Rong, LI Jie. Degradation of diclofenac sodium by electrospinning fibers-based Fenton method[J]. Chinese Journal of Environmental Engineering, 2016, 10(9): 4895-4901. doi: 10.12030/j.cjee.201504105
Citation: ZHUANG Shuting, XU Bing, LIU Bo, KANG Mi, CHENG Rong, LI Jie. Degradation of diclofenac sodium by electrospinning fibers-based Fenton method[J]. Chinese Journal of Environmental Engineering, 2016, 10(9): 4895-4901. doi: 10.12030/j.cjee.201504105
shu

基于静电纺丝膜的Fenton法降解双氯芬酸钠

  • 1. 中国人民大学环境学院, 北京 100872
  • 收稿日期:  2015-05-13
基金项目:

国家自然科学基金资助项目（51108454）

中国人民大学科学研究基金（中央高校基本科研业务费专项资金资助）（14XNLQ02）

摘要: 通过浸渍法将铁盐负载于静电纺丝纤维膜制备了类Fenton催化剂，并通过扫描电子显微镜（SEM）对静电纺丝膜进行了表征，研究了该催化剂降解双氯芬酸钠的特性及其重复利用率。结果表明，静电纺丝纤维膜反应前后膜结构良好，反应过程中铁离子几乎无溶出；膜对双氯芬酸钠有一定的吸附能力，去除率约为6.96%。当双氯芬酸钠初始浓度为20 mg·L-1，按0.310 g·（100 mL）-1比例加入催化剂时，H2O2最佳用量为340 mg·L-1。溶液的初始pH值对实验结果影响较大，酸性条件更利于双氯芬酸钠的降解，最佳pH值为3.14，但该催化剂所适用的pH值范围较之传统Fenton法有明显拓展。所制备的催化剂重复利用率高，循环使用4次后，催化活性无明显改变，4 h的去除率依然高达95%以上。反应中双氯芬酸钠主要生成乙酸等小分子化合物，最终可氧化为CO2和H2O。
