不同密度絮体的实际耗氧需求分析

,  ,  ,  ,

downloadPDF

上一篇

下一篇

李志华, 姚佩, 樊龙, 李汝佳, 韩杏. 不同密度絮体的实际耗氧需求分析[J]. 环境工程学报, 2016, 10(9): 4907-4911. doi: 10.12030/j.cjee.201504097
引用本文: 李志华, 姚佩, 樊龙, 李汝佳, 韩杏. 不同密度絮体的实际耗氧需求分析[J]. 环境工程学报, 2016, 10(9): 4907-4911. doi: 10.12030/j.cjee.201504097
shu
LI Zhihua, YAO Pei, FAN Long, LI Rujia, HAN Xing. Analysis of actual oxygen demand of flocs with different densities[J]. Chinese Journal of Environmental Engineering, 2016, 10(9): 4907-4911. doi: 10.12030/j.cjee.201504097
Citation: LI Zhihua, YAO Pei, FAN Long, LI Rujia, HAN Xing. Analysis of actual oxygen demand of flocs with different densities[J]. Chinese Journal of Environmental Engineering, 2016, 10(9): 4907-4911. doi: 10.12030/j.cjee.201504097
shu

不同密度絮体的实际耗氧需求分析

  • 1.

    西安建筑科技大学环境与市政工程学院, 西北水资源与环境生态教育部重点实验室, 西安 710055

  • 基金项目:

    陕西省科技计划国际合作项目（2013KW2201）

    2013年博士点基金联合项目（20136120110002）

  • 中图分类号: X703

Analysis of actual oxygen demand of flocs with different densities

  • 1.

    Key Laboratory of Northwest Water Resource, Environment and Ecology, Ministry of Education, School of Environmental and Municipal Engineering, Xi'an University of Architecture and Technology, Xi'an 710055, China

  • Fund Project:

  • 摘要: 通过选取不同污水处理厂及实验室改进A2/O反应器曝气池内的活性污泥进行实验，研究了不同密度污泥的耗氧需求以及其节能特性。研究发现，实验所用污泥密度分别为1.004 1、1.003 3、1.001 7、1.001 3和1.000 6 g·mL-1时，其实际耗氧量与理论需氧量比值（Cresp/Craw）分别为0.42、0.61、1.38、1.44和1.69，即当污泥密度越大，则污泥在去除污染物质的过程耗氧量越小，节能性能越好，且其节能程度与微生物用于自身基础代谢的内源呼吸速率比例有关，内源呼吸速率比例越小，污泥越节能。另外通过对不同密度活性污泥进行短期冲击实验，研究发现在非稳态环境中，密度小的污泥用于基础代谢的能量多，而用于生长代谢的少，其稳定性能较好。
    Abstract: The actual oxygen consumption demand and energy-saving characteristics were investigated by using samples from different WWTPs and a laboratory-scale modified A2/O process. The results showed that when the densities of the sludge were 1.004 1, 1.003 3, 1.001 7, 1.001 3, and 1.000 6 g·mL-1, the ratios between the actual oxygen consumption and the theoretical oxygen demand (Cresp/Craw) were 0.42, 0.61, 1.38, 1.44, and 1.69, respectively. This implies that the denser the sludge, the less the energy required for contaminant removal, i.e., indicating energy saving. In addition, the level of energy saving was related to the endogenous respiration rate ratio for the basic metabolism of microorganisms, i.e., the smaller the endogenous respiration ratio, the more the energy saving. In addition, a short-term shock was carried out on activated sludge with different densities. The results showed that with an unsteady status, more basic metabolic energy and less growth-related energy were used for smaller density sludge, resulting in a more stable status.
  • 加载中
  • [1] 黄浩华,张杰,文湘华,等.城市污水处理厂A2/O工艺的节能降耗途径研究.环境工程学报, 2009, 3(1):35-38 HUANG Haohua, ZHANG Jie, WEN Xianghua, et al. Study on energy saving methods for A2/O process in waste water treatment plants. Chinese Journal of Environmental Engineering, 2009, 3(1):35-38(in Chinese)
    [2] LIU Changqing, LI Shuai, ZHANG Feng. The oxygen transfer efficiency and economic cost analysis of aeration system in municipal wastewater treatment plant. Energy Procedia, 2011, 5:2437-2443
    [3] 王硕, 阮智宇, 王燕, 等. 低温好氧颗粒污泥反应器的启动特性研究. 中国给水排水, 2014, 30(23):1-5 WANG Shuo,RUAN Zhiyu,WANG Yan,et al.Start-up characteristics of aerobic granular sludge bioreactor at low temperature.China Water & Wastewater, 2014, 30(23):1-5(in Chinese)
    [4] 丁立斌, 马俊杰, 李军, 等. 好氧颗粒污泥SBR中试运行效能评价. 中国给水排水, 2014, 30(21):87-90 DING Libin, MA Junjie, LI Jun, et al. Evaluation of operation efficiency of pilot-scale SBR with aerobic granular sludge. China Water & Wastewater, 2014, 30(21):87-90(in Chinese)
    [5] SWEITY A., WANG Ying, ALI-SHTAYEH M. S., et al. Relation between EPS adherence, viscoelastic properties, and MBR operation:Biofouling study with QCM-D. Water Research, 2011, 45(19):6430-6440
    [6] FRIEDRICH M., TAKáCS I. A new interpretation of endogenous respiration profiles for the evaluation of the endogenous decay rate of heterotrophic biomass in activated sludge. Water Research, 2013, 47(15):5639-5646
    [7] 邹联沛, 赵洪涛, 刘知人, 等. 水质条件对氧传质影响的研究. 中北大学学报(自然科学版), 2010, 31(1):45-49 ZOU Lianpei, ZHAO Hongtao, LIU Zhiren, et al. Research on impact of water quality on oxygen transition. Journal of North University of China (Natural Science Edition), 2010, 31(1):45-49(in Chinese)
    [8] 李若谷,孙艳,张雁秋,等.差压仪测定活性污泥中异养菌产率系数的研究.中国给水排水,2012, 28(21):113-116 LI Ruogu, SUN Yan, ZHANG Yanqiu, et al. Determination of heterotrophic bacteria yield coefficient in activated sludge with manometric respirometer. China Water & Wastewater, 2012, 28(21):113-116(in Chinese)
    [9] 任宏洋, 张代钧, 丛丽影, 等. 呼吸法测定硝化菌产率系数实验研究. 环境工程学报, 2010, 4(8):1726-1728 REN Hongyang, ZHANG Daijun, CONG Liying, et al. Experimental study on determination of nitrifying bacteria yield coefficients using respirometry. Chinese Journal of Environmental Engineering, 2010, 4(8):1726-1728(in Chinese)
    [10] ETTERER T., WILDERER P. A. Generation and properties of aerobic granular sludge. Water Science and Technology, 2001, 43(3):19-26
    [11] BARKER P. S., DOLD P. L. COD and nitrogen mass balances in activated sludge systems. Water Research, 1995, 29(2):633-643
    [12] 李志华,白旭丽,张芹,等.基于呼吸图谱的自养菌与异养菌内源呼吸过程分析.环境科学,2014,35(9):3492-3497 LI Zhihua, BAI Xuli, ZHANG Qin, et al. Endogenous respiration process analysis of heterotrophic biomass and autotrophic biomass based on respiration map. Environmental Science, 2014, 35(9):3492-3497(in Chinese)
    [13] 王惠, 刘研萍, 陶莹, 等. 厌氧氨氧化菌脱氮机理及其在污水处理中的应用. 生态学报, 2011, 31(7):2019-2028 WANG Hui, LIU Yanping, TAO Ying, et al. The biochemical mechanism and application of anammox in the wastewater treatment process. Acta Ecologica Sinica, 2011, 31(7):2019-2028(in Chinese)
    [14] 杨鹏,张朝升,荣宏伟,等.双污泥BCR反硝化同步脱氮除磷的试验研究.环境科学与技术,2014, 37(3):74-77 YANG Peng, ZHANG Chaosheng, RONG Hongwei, et al. Denitrifying denitrification and phosphorus removal process in two-sludge BCR. Environmental Science & Technology, 2014, 37(3):74-77(in Chinese)
    [15] 赵丽君,方芳,郭劲松,等.溶解氧对SBR脱氮性能与脱氮方式的影响.环境工程学报,2015, 9(3):1148-1154 ZHAO Lijun,FANG Fang,GUO Jinsong,et al.Impacts of dissolved oxygen level on nitrogen remval efficiencies and pathways in a sequential batch reactor.Chinese Journal of Environmental Engineering, 2015, 9(3):1148-1154(in Chinese)
    [16] POCHANA K., KELLER J. Study of factors affecting simultaneous nitrification and denitrification (SND). Water Science and Technology, 1999, 39(6):61-68
    [17] 李志华,吴军,贺春博,等.水力旋流条件对好氧颗粒污泥稳定性影响.环境科学学报, 2013, 33(3):671-675 LI Zhihua, WU Jun, HE Chunbo, et al. Effect of hydrocyclone on stability of aerobic granule sludge. Acta Scientiae Circumstantiae, 2013, 33(3):671-675(in Chinese)
    [18] 李志华, 吴军, 李胜, 等. 采用非生长能量代谢参数表征颗粒污泥稳定性. 环境科学, 2012, 33(6):1913-1917 LI Zhihua, WU Jun, LI Sheng, et al. Description of the stability of granules using nongrowth-related parameters. Environmental Science, 2012, 33(6):1913-1917(in Chinese)
