电极强化人工湿地处理污水脱氮的效果

,  ,

downloadPDF

上一篇

下一篇

何媛, 王宇晖, 宋新山. 电极强化人工湿地处理污水脱氮的效果[J]. 环境工程学报, 2016, 10(9): 4867-4872. doi: 10.12030/j.cjee.201504007
引用本文: 何媛, 王宇晖, 宋新山. 电极强化人工湿地处理污水脱氮的效果[J]. 环境工程学报, 2016, 10(9): 4867-4872. doi: 10.12030/j.cjee.201504007
shu
HE Yuan, WANG Yuhui, SONG Xinshan. Wastewater denitrification by construct wetlands with electrode intensification[J]. Chinese Journal of Environmental Engineering, 2016, 10(9): 4867-4872. doi: 10.12030/j.cjee.201504007
Citation: HE Yuan, WANG Yuhui, SONG Xinshan. Wastewater denitrification by construct wetlands with electrode intensification[J]. Chinese Journal of Environmental Engineering, 2016, 10(9): 4867-4872. doi: 10.12030/j.cjee.201504007
shu

电极强化人工湿地处理污水脱氮的效果

  • 1.

    东华大学环境科学与工程学院, 上海 201620

  • 基金项目:

    国家自然科学基金青年科学基金（51309053）

  • 中图分类号: X703

Wastewater denitrification by construct wetlands with electrode intensification

  • 1.

    School of Environmental Science and Engineering, Donghua University, Shanghai 201620, China

  • Fund Project:

  • 摘要: 将电极与人工湿地耦合，创新性地构建了复合电极人工湿地高效反硝化脱氮装置，提高对污水中总氮和COD的去除效果。为了确定复合电极人工湿地比普通人工湿地脱氮效果更优，研究了碳氮比、进水总氮浓度、水力停留时间、电流强度等因素对复合电极人工湿地和人工湿地脱氮效果的影响。研究结果表明：在室温20~25℃，pH=7.5条件下，引入电极的人工湿地有更好的去除效果，较普通人工湿地总氮脱除效率可高出5.41%。并且确定了复合电极人工湿地的最佳运行条件为碳氮比=0.75，水力停留时间=48 h，进水总氮浓度=75 mg·L-1，电流强度=10 mA。在此条件下，总氮去除率可达53.34%。
    Abstract: Electrode-biofilm was coupled innovatively with constructed wetlands (CWs) in this experiment to increase the removal efficiency of TN and COD. For this purpose, a highly effective denitrification reactor electrode-constructed wetlands (E-CWs) were installed. The effects of the C/N ratio, influent total nitrogen load, HRT, and electric current intensity on the denitrification rate were compared between the E-CWs and CWs to improve the determination of the removal efficiency of E-CWs. The results indicated that E-CWs have superior removal efficiency at air temperatures of 20 to 25℃ and pH of 7.5, with the TN removal efficiency being 5.41% higher than CWs. The optimal C/N ratio, HRT, influent total nitrogen load, and the electric current intensity were 0.75, 48 h, 75 mg·L-1, and 10 mA, respectively. In addition, the TN removal efficiency reached 53.34%.
  • 加载中
  • [1] 张玲, 崔理华. 人工湿地脱氮现状与研究进展. 中国农学通报, 2012, 28(5):268-272 ZHANG Ling, CUI Lihua. The denitrification status and its research progress of construction wetland. Chinese Agricultural Science Bulletin, 2012, 28(5):268-272(in Chinese)
    [2] 王允妹, 陈明. SBR法处理低C/N污水的工程应用:以某基地污水处理站改造工程为例. 环境保护与循环经济, 2014, 34(3):47-49 WANG Yunmei, CHEN Ming. SBR Engineering application of low C/N wastewater treatment:Example of certain base sewage treatment plant renovation project. Environmental Protection and Circular Economy, 2014, 34(3):47-49(in Chinese)
    [3] 杨群. 低C/N比污水EMBR脱氮工艺研究. 武汉:华中科技大学博士学位论文, 2011 YANG Qun. Research on EMBR process for denitrigenation of the wastewater of low C/N ratio. Wuhan:Doctor Dissertation of Huazhong University of Science and Technology, 2011(in Chinese)
    [4] 赵国智. 电极生物膜反硝化去除地下水中硝酸盐氮的实验研究. 杭州:浙江大学博士学位论文, 2011 ZHAO Guozhi. Research on the removal of nitrate from groundwater by biological electrode denitrification. Hangzhou:Doctor Dissertation of Zhejiang University, 2011(in Chinese)
    [5] MELLOR R. B., RONNENBERG J., CAMPBELL W. H., et al. Reduction of nitrate and nitrite in water by immobilized enzymes. Nature, 1992, 355(6362):717-719
    [6] FLORA J. R. V., SUIDAN M. T., ISLAM S., et al. Numerical modeling of a biofilm-electrode reactor used for enhanced denitrification. Water Science and Technology, 1994, 29(10/11):517-524
    [7] KURODA M., WATANABE T., UMEDU Y. Simultaneous oxidation and reduction treatments of polluted water by a bio-electro reactor. Water Science and Technology, 1996, 34(9):101-108
    [8] 曲久辉, 范彬, 刘锁祥, 等. 电解产氢自养反硝化去除地下水中硝酸盐氮的研究. 环境科学, 2001, 22(6):49-52 QU Jiuhui, FAN Bin, LIU Suoxiang, et al. Autotrophic denitrification of groundwater by electrochemical process. Environmental Science, 2001, 22(6):49-52(in Chinese)
    [9] 邱凌峰. 电极生物膜法反硝化作用初探. 福建环境, 1999, 16(6):21-23 QIU Lingfeng. Research on denitrification in treatment by bio-electrode method. Fujian Environment, 1999, 16(6):21-23(in Chinese)
    [10] 张鹏. 强化电极生物膜处理地下水硝酸盐及生物多样性的研究. 北京:中国地质大学硕士学位论文, 2011 ZHANG Peng. Study on nitrate removal from groundwater and biological diversity with a strengthening biofilm electrode reactor. Beijing:Master Dissertation of China University of Geosciences, 2011(in Chinese)
    [11] ZHAO Yingxin, FENG Chuanping, WANG Qinghong, et al. Nitrate removal from groundwater by cooperating heterotrophic with autotrophic denitrification in a biofilm-electrode reactor. Journal of Hazardous Materials, 2011, 192(3):1033-1039
    [12] ZHOU Minghua, FU Wenjing, GU Heyan, et al. Nitrate removal from groundwater by a novel three-dimensional electrode biofilm reactor. Electrochimica Acta, 2007, 52(19):6052-6059
    [13] MODIN O., FUKUSHI K., YAMAMOTO K. Denitrification with methane as external carbon source. Water Research, 2007, 41(12):2726-2738
    [14] 周欲飞. 电极生物膜组合工艺去除地下水硝酸盐的试验研究. 杭州:浙江大学硕士学位论文, 2010 ZHOU Yufei. An approach combined electrochemical with biological denitrification for nitrate removal from groundwater. Hangzhou:Master Dissertation of Zhejiang University, 2010(in Chinese)
    [15] 尹勇. 电极-膜生物反应器(EMBR)的构型设计及工艺过程影响因子研究. 武汉:华中科技大学硕士学位论文, 2009 YIN Yong. The study on EMBR desing and impact factors of the process. Wuhan:Master Dissertation of Huazhong University of Science and Technology, 2009(in Chinese)
    [16] SAKAKIBARA Y., FLORA J. R V., SUIDAN M. T., et al. Modeling of electrochemically-activated denitrifying biofilms. Water Research, 1994, 28(5):1077-1086
    [17] LI Miao, FENG Chuanping, ZHANG Zhenya, et al. Simultaneous reduction of nitrate and oxidation of by-products using electrochemical method. Journal of Hazardous Materials, 2009, 171(1/2/3):724-730
    [18] 马利民. 电极生物膜法处理饮用水的脱氮实验研究. 合肥:合肥工业大学硕士学位论文, 2004 MA Limin. Study on denitrification of drinking water with biofilm-electrode method. Hefei:Master Dissertation of Hefei University of Technology, 2004(in Chinese)
  • 加载中
