章斐, 陈秀荣, 江子建, 王璐, 何怡萱, 鲍征. 不同氮磷浓度下2种无毒微藻的生长特性和脱氮除磷效能[J]. 环境工程学报, 2015, 9(2): 559-566. doi: 10.12030/j.cjee.20150210
引用本文: 章斐, 陈秀荣, 江子建, 王璐, 何怡萱, 鲍征. 不同氮磷浓度下2种无毒微藻的生长特性和脱氮除磷效能[J]. 环境工程学报, 2015, 9(2): 559-566. doi: 10.12030/j.cjee.20150210
shu
Zhang Fei, Chen Xiurong, Jiang Zijian, Wang Lu, He Yixuan, Bao Zheng. Growth characteristics and removal efficiency of nitrogen and phosphorus of two kinds of non-toxic microalgae under different nitrogen and phosphorus concentrations[J]. Chinese Journal of Environmental Engineering, 2015, 9(2): 559-566. doi: 10.12030/j.cjee.20150210
Citation: Zhang Fei, Chen Xiurong, Jiang Zijian, Wang Lu, He Yixuan, Bao Zheng. Growth characteristics and removal efficiency of nitrogen and phosphorus of two kinds of non-toxic microalgae under different nitrogen and phosphorus concentrations[J]. Chinese Journal of Environmental Engineering, 2015, 9(2): 559-566. doi: 10.12030/j.cjee.20150210
shu

不同氮磷浓度下2种无毒微藻的生长特性和脱氮除磷效能

  • 1.

    华东理工大学资源与环境工程学院, 上海 200237

  • 基金项目:

    上海市浦江人才计划项目(13PJD009)

    国家自然科学基金资助项目(51378207)

    国家"水体污染控制与治理"科技重大专项(2014ZX07202-011-002)

  • 中图分类号: X703

Growth characteristics and removal efficiency of nitrogen and phosphorus of two kinds of non-toxic microalgae under different nitrogen and phosphorus concentrations

  • 1.

    College of Resources and Environmental Engineering, East China University of Science and Technology, Shanghai 200237, China

  • Fund Project:

  • 摘要: 根据城市二级出水水质特性,选择4 种不同氮磷水平的二级出水作为培养基,研究纯培养与共培养下,椭圆小球藻(Chlorella ellipsoidea)和斜生栅藻(Scenedesmus obliquus)在不同初始氮磷浓度下的生长状况及脱氮除磷的能力。结果表明,纯培养条件下,椭圆小球藻在2#(TN=15.00 mg/L,TP=1.00 mg/L)实验组中生物量最高,斜生栅藻在4#(TN=10.00 mg/L,TP=0.20 mg/L)实验组中收获最大生物量,椭圆小球藻与斜生栅藻对TP均具有70%以上去除率。共培养下,3#(TN=15.00 mg/L,TP=0.50 mg/L)实验组收获最高生物量,斜生栅藻生物量均高于椭圆小球藻,表明斜生栅藻在共培养条件下更具有生长优势,培养基中TN、TP含量分别降至5.00 mg/L和0.05 mg/L以下。2种培养模式均可达到对二级出水的深度脱氮除磷。
    Abstract: Chlorella ellipsoidea and Scenedesmus obliquus were cultured in different initial nitrogen and phosphorus concentrations based on second effluent to investigate the growth characteristics of the two kinds of microalgae and their abilities of nitrogen and phosphorus removal. The results showed that Chlorella ellipsoidea got the highest biomass under the test of 2#, Scenedesmus obliquus got the highest biomass under the test of 4# under pure culture. The total phosphorus(TP) removal rates of Chlorella ellipsoidea and Scenedesmus obliquus were both higher than 70%. The two kinds of microalgae got the highest biomass under the test of 3# under mixed culture. The biomass of Scenedesmus obliquus was higher than Chlorella ellipsoidea, indicated that Scenedesmus obliquus took the growth advantage under the mixed culture. the total nitrogen(TN) and TP contents in the medium were lower than 5.00 mg/L and 0.05 mg/L. This study implies that the two kinds of non-toxic microalgae both can make the deep denitrification and phosphorus removal under pure or mixed culture.
  • 加载中
  • [1] 吕素娟. 城市生活废水用于培养产油微藻. 青岛: 中国海洋大学硕士学位论文, 2011 Lü Sujuan. Cultivating of oleaginous microalgae with municipal wastewater. Qingdao: Master Dissertation of Chinese Marine University, 2011 (in Chinese)
    [2] 刘建强, 刘玉环, 阮榕生, 等. 利用市政污水培养Chlorella vulgaris生产生物柴油. 生物加工过程, 2011, 9(1): 10-14 Liu Jianqiang, Liu Yuhuan, Ruan Rongsheng, et al. Cultivating Chlorella vulgaris as biodiesel feedstock by municipal Wastewater. Chinese Journal of Bioprocess Engineering, 2011, 9(1): 10-14 (in Chinese)
    [3] Ruiz-Marin A., Mendoza-Espinosa L. G., Stephenson T. Growth and nutrient removal in free and immobilized green algae in batch and semi-continuous cultures treating real wastewater. Bioresource Technology, 2010, 101(1): 58-64
    [4] 胡洪营, 李鑫, 杨佳. 基于微藻细胞培养的水质深度净化与高价值生物质生产耦合技术. 生态环境学报, 2009, 18(3): 1122-1127 Hu Hongying, Li Xin, Yang Jia. Coupling of wastewater deep purification and high quality biomass production based on microalgae cultivation. Ecology and Environmental Sciences, 2009, 18(3): 1122-1127 (in Chinese)
    [5] 焦媛媛. 海洋微藻快速生长及油脂富集技术的初步研究. 青岛: 中国海洋大学硕士学位论文, 2010 Jiao Yuanyuan. Priliminary study on the rapid growth and oil accumulation of marine microalgae. Qingdao: Master Dissertation of Chinese Marine University, 2010 (in Chinese)
    [6] Abou-Shanab R. A. I., Hwang J. H., Cho Y., et al. Characterization of microalgal species isolated from fresh water bodies as a potential source for biodiesel production. Applied Energy, 2011, 88(10): 3300-3306
    [7] 孙鸿烈. 中国资源科学百科全书. 北京: 中国大百科全书出版社;东营: 石油大学出版社, 2000
    [8] 林忠洲, 徐善良, 邵波, 等. 不同氮磷质量浓度下青岛大扁藻和牟氏角毛藻的种间竞争关系. 宁波大学学报(理工版), 2013, 26(1): 12-17 Lin Zhongzhou, Xu Shanliang, Shao Bo, et al. The Competitive relationship of Platymonas helgolandica Var. Tsingtaoensis and Chaetoceros Muelleri Lemmerman in different mass concentrations of nitrogen and phosphorus. Journal of Ningbo University (NSEE), 2013, 26(1): 12-17 (in Chinese)
    [9] Dere S., Günes T., Sivaci R. Spectrophotometric determination of chlorophyll-A, B and total carotenoid contents of some algae species using different solvents. Turkish Journal of Botany, 1998, 22: 13-17
    [10] 魏复盛. 水和废水监测分析方法 (第4 版). 北京: 中国环境科学出版社, 2002
    [11] 陈春云, 庄源益, 方圣琼. 小球藻对养殖废水中N、P的去除研究. 海洋环境科学, 2009, 28(1): 9-11 Chen Chunyun, Zhuang Yuanyi, Fang Shengqiong. Study on N, P removed in culturing wastewater by Chlorella. Marine Environmental Science, 2009, 28(1): 9-11 (in Chinese)
    [12] 邓祥元, 丁婉婉, 樊玲波, 等. 2种微藻去除氮、磷能力的比较. 吉林农业大学学报, 2013, (6): 694-698, 726 Deng Xiangyuan, Ding Wanwan, Fan Lingbo, et al. Comparative study on N and P removal ability of Chlorella pyrenoidosa and Scenedesmus obliquus. Journal of Jilin Agricultural University, 2013, (6): 694-698, 726 (in Chinese)
    [13] 宋丽娜, 郑晓宇, 顾詠洁, 等. 磷浓度对海洋小球藻叶绿素荧光及生长的影响. 环境污染与防治, 2010, 32(8): 20-24, 50 Song Lina, Zheng Xiaoyu, Gu Yongjie, et al. Effect of P concentrations on chlorophyll fluorescence and growth of Chlorella sp. Environmental Pollution & Control, 2010, 32(8): 20-24, 50 (in Chinese)
    [14] 胡鸿钧. 中国淡水藻类. 上海: 上海科学技术出版社, 1980
    [15] 傅晓娜, 姚刚. 微藻污水处理与生物质能耦合技术综述. 绿色科技, 2011, (11): 100-104 Fu Xiaona, Yao Gang. The review of microalgae coupling technology of waste water treatment with biomass energy. Journal of Green Science and Technology, 2011, (11): 100-104 (in Chinese)
    [16] 王海英, 牟晓庆. 城市污水培养富油蛋白小球藻的研究. 中南民族大学学报(自然科学版), 2011, 30(3): 38-41 Wang Haiying, Mou Xiaoqing. Cultivation of high oil content Chlorella pyrenoidosa on urban sewage. Journal of South-Central University for Nationalities(Natural Science), 2011, 30(3): 38-41 (in Chinese)
    [17] 张福萍. 不同条件下小球藻和斜生栅藻生长的对比研究. 北京: 北京工业大学硕士学位论文, 2010 Zhang Fuping. The growth comparision of Chlorella vulgaris and Scenedesmus obliques in different environmental conditions. Beijing: Master Dissertation of Beijing University of Technology, 2010 (in Chinese)
    [18] 朱树峰, 于茵, 胡洪营. 混合培养对城市污水厂二级出水培养能源微藻的生长促进作用. 生态环境学报, 2014, (4): 642-648 Zhu Shufeng, Yu Yin, Hu Hongying. Effects on the growth characteristic by mixed culture of three energy microalgae species using domestic secondary effluent. Ecology and Environmental Sciences, 2014, (4): 642-648 (in Chinese)
    [19] 汪芳, 葛蔚, 柴超, 等. 不同营养条件对东海原甲藻和中肋骨条藻竞争参数的影响. 应用生态学报, 2012, 23(5): 1393-1399 Wang Fang, Ge Wei, Chai Chao, et al. Effects of nutritional condition on the competitive parameters of Prorocentrum donghaiense and Skeletonema costatum. Chinese Journal of Applied Ecology, 2012, 23(5): 1393-1399 (in Chinese)
    [20] 王少沛, 李卓佳, 曹煜成, 等. 微绿球藻、隐藻、颤藻的种间竞争关系. 中国水产科学, 2009, 16(5): 765-772 Wang Shaopei, Li Zhuojia, Cao Yucheng, et al. Interspecific competition among Nannochloropsis sp., Cryptomonas erosa and Oscillatoria sp. Journal of Fishery Sciences of China, 2009, 16(5): 765-772 (in Chinese)
    [21] 李飞, 邢丽贞, 闫春玲, 等. 环境因素对微藻去除氮磷的影响. 山东建筑工程学院学报, 2006, 21(3): 268-272 Li Fei, Xing Lizhen, Yan Chunling, et al. Influence of environmental factors on removal of nitrogen and phosphorus by microalgae. Journal of Shandong University of Architecture and Engineering, 2006, 21(3): 268-272 (in Chinese)
    [22] 晁建颖, 颜润润, 张毅敏. 不同温度下铜绿微囊藻和斜生栅藻的最佳生长率及竞争作用. 生态与农村环境学报, 2011, 27(2): 53-57 Chao Jianying, Yan Runrun, Zhang Yimin. Optimal growth of and competition between microcystis aeruginosa and Scenedesmus obliquus related to temperature. Journal of Ecology and Rural Environment, 2011, 27(2): 53-57 (in Chinese)
    [23] Travieso L., Benítez F., Sánchez E., et al. Batch mixed culture of Chlorella vulgaris using settled and diluted piggery waste. Ecological Engineering, 2006, 28(2): 158-165
    [24] Martínez M. E., Sánchez S., Jiménez J. M., et al. Nitrogen and phosphorus removal from urban wastewater by the microalga Scenedesmus obliquus. Bioresource Technology, 2000, 73(3): 263-272
    [25] Aslan S., Kapdan I. K. Batch kinetics of nitrogen and phosphorus removal from synthetic wastewater by algae. Ecological Engineering, 2006, 28(1): 64-70
    [26] Yang Jia, Li Xin, Hu Hongying, et al. Growth and lipid accumulation properties of a freshwater microalga, Chlorella ellipsoidea YJ1, in domestic secondary effluents. Applied Energy, 2011, 88(10): 3295-3299
    [27] 周律, 刘晶晶, 甘一萍, 等. 再生水回用中氮磷对两种典型水华藻类生长影响研究. 给水排水, 2009, 35(6): 39-42 Zhou Lü, Liu Jingjing, Gan Yiping, et al. Experimental study on the influences of nitrogen and phosphorus concentrations in reclaimed water on the growth of two typical kinds of algae. Water & Wastewater Engineering, 2009, 35(6): 39-42 (in Chinese)
    [28] Wang Bo, Zhou Lianning. Study on the removing nitrogen and phosphorus from wastewater by Chlorella. Agricultural Science & Technology, 2014, 15(4): 631-634
