Fe掺杂PTFE-PbO2/TiO2-NTs/Ti电极的制备、表征及电催化性能

,  ,  ,  ,

downloadPDF

上一篇

下一篇

缪虹, 孙亚兵, 冯景伟, 王瑾瑜, 徐建华. Fe掺杂PTFE-PbO2/TiO2-NTs/Ti电极的制备、表征及电催化性能[J]. 环境化学, 2012, 31(6): 837-841.
引用本文: 缪虹, 孙亚兵, 冯景伟, 王瑾瑜, 徐建华. Fe掺杂PTFE-PbO2/TiO2-NTs/Ti电极的制备、表征及电催化性能[J]. 环境化学, 2012, 31(6): 837-841.
shu
MIAO Hong, SUN Yabing, FENG Jingwei, WANG Jinyu, XU Jianhua. Preparation, characterization and electro-catalytic properties of Fe doped PTFE-PbO2/TiO2-NTs/Ti[J]. Environmental Chemistry, 2012, 31(6): 837-841.
Citation: MIAO Hong, SUN Yabing, FENG Jingwei, WANG Jinyu, XU Jianhua. Preparation, characterization and electro-catalytic properties of Fe doped PTFE-PbO2/TiO2-NTs/Ti[J]. Environmental Chemistry, 2012, 31(6): 837-841.
shu

Fe掺杂PTFE-PbO2/TiO2-NTs/Ti电极的制备、表征及电催化性能

  • 1.

    污染控制与资源化研究国家重点实验室, 南京大学环境学院, 南京, 210046;

  • 2.

    合肥工业大学土木与水利工程学院, 合肥, 230009

  • 基金项目:

    污染控制与资源化研究国家重点实验室开放课题(PCRRF10016)

    合肥工业大学科学研究发展基金(GDBJ2009-027)

    中央高校基本科研业务费专项资金项目(2011HGQC1029)

    流域水污染防治技术辅助决策支持平台研究与建筑(2009ZX07529-007-006-003)资助.

Preparation, characterization and electro-catalytic properties of Fe doped PTFE-PbO2/TiO2-NTs/Ti

  • 1.

    State Key Laboratory of Pollution Control and Resource Reuse, School of the Environment, Nanjing University, Nanjing, 210046, China;

  • 2.

    School of Civil Engineering, Hefei University of Technology, Hefei, 230009, China

  • Fund Project:

  • 摘要: 采用电沉积法制备了Fe掺杂PTFE-PbO2/TiO2-NTs/Ti、PbO2/TiO2-NTs/Ti、PbO2/Ti 3种电极,运用扫描电镜、X射线衍射仪观察表面形貌与形态,通过线性扫描伏安法在0.1 mol·L-1的H2SO4中测定电极的析氧极化曲线.以对硝基酚(p-NP)为目标污染物,考察了电极的电催化活性,在20 mA·cm-2电流密度下降解100 mg·L-1 p-NP,120 min时表观速率常数分别为0.0370 min-1、0.0265 min-1和0.0180 min-1,COD去除率分别为77.38%、74.07%、66.18%,研究发现在相同的条件下Fe掺杂PTFE-PbO2/TiO2-NTs/Ti性能更佳,矿化更完全.
    Abstract: Fe-doped PTFE-PbO2/TiO2-NTs/Ti,PbO2/TiO2-NTs/Ti and PbO2/Ti were prepared by anodic electrodeposition technique. The microstructure and morphology were analyzed by scanning electron microscope (SEM) and X-ray diffraction(XRD). Polarization curves of oxygen evolution of the three electrodes were studied by linear sweep voltammetry in 0.1 mol稬-1 H2SO4 aqueous solution. The electro-catalysis of the fabricated electrodes was also investigated using p-nitrophenol (p-NP) as a model pollutant. p-Nitrophenol with 100 mg稬-1 concentration was treated under the current density of 20 mA穋m-2 for 120 min. The apparent rate constant was 0.0370 min-1,0.0265 min-1and 0.0180 min-1, COD removal efficiency was 77.38%,74.07% and 66.18%, respectively. Compared with the other two electrodes, the Fe-doped PTFE-PbO2/TiO2-NTs/Ti had a better performance and the mineralization was greater.
  • 加载中
  • [1] 娄红波,王建中,张萍,等.电化学法处理苯酚模拟废水的研究 [J].环境科学与管理,2008,33(2):72-77
    [2] 徐亮,赵芳,农佳莹,等.二氧化铅电极的制备、表征及其电催化性能研究 [J].环境工程学报,2008,2(7):959-963
    [3] 徐丽丽,施汉昌,陈金銮.Ti/RuO2-TiO2-IrO2-SnO2电极电解氧化含氨氮废水 [J].环境科学,2007,28(9):2009-2013
    [4] 王勋华, 周琦, 张蓉,等.Ti/CeO2 -F-PbO2电极制备及其在有机物降解中的应用 [J].电化学,2010,16(2):172-176
    [5] 胡锋平,王晓淼,刘占孟.PbO2/Ti改性电极电催化氧化酸性品红的试验研究[J].环境科学与技术,2010,33(5):51-54
    [6] 杨岩,张建民.PbO2和掺杂的Fe -PbO2电极的制备及电催化性能研究[J].环境工程学报,2009,3(10):1893-1896
    [7] 王雅琼,童宏扬,许文林.SnO2+Sb2O3中间层的制备条件对Ti/SnO2+Sb2O3/PbO2阳极性能的影响[J].应用化学,2004,21(5):437-441
    [8] 陈步明,郭忠诚,杨显万,等.电沉积掺杂二氧化铅表面的研究进展[J].中国有色金属学报,2008,18(9):1711-1720
    [9] 温青,张宝宏,李旭辉.铁掺杂PbO2/Ti阳极电催化氧化对硝基苯酚研究[J].中国给水排水,2006,22(13):85-89
    [10] Leonardo S A,Luís Augusto M R,Romeu C R, et al,On the performance of Fe and Fe,F doped Ti-Pt/PbO2 electrodes in the electrooxidation of the Blue Reactive 19 dye in simulated textile wastewater [J]. Chemosphere,2007,66:2035-2043
    [11] Wang Y,Shen Z Y,Li Y, et al.Electrochemical properties of the erbium-chitosan -fluorine-modified PbO2 electrode for the degradation of 2,4-dichlorophenol in aqueous solution [J]. Chemosphere,2010,79:987-996
    [12] Tan C,Xiang B,Li Y J, et al. Preparation and characteristics of a nano-PbO2 anode for organic wastewater treatment [J], Chemical Engineering Journal, 2011,166:15-21
    [13] 肖宁.钛基纳米管的制备工艺及光催化性能研究.哈尔滨: 哈尔滨工业大学理学院硕士论文,2009
    [14]
    [15] Zhao G H,Zhang Y G,Lei Y Z. Fabrication and electrochemical treatment application of a novel lead dioxide anode with superhydrophobic surfaces,high oxygen evolution potential and oxidation capability [J]. Environmental Science and Technology,2010, 44:1754-1759
    [16] 赵海燕,曹江林,张鉴清.掺杂F-对PbO2 阳极性能和电催化活性的影响[J].无机化学学报,2007,23(12):2079-2084
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1180
  • HTML全文浏览数:  1105
  • PDF下载数:  413
  • 施引文献:  0
出版历程
  • 收稿日期:  2011-08-03
缪虹, 孙亚兵, 冯景伟, 王瑾瑜, 徐建华. Fe掺杂PTFE-PbO2/TiO2-NTs/Ti电极的制备、表征及电催化性能[J]. 环境化学, 2012, 31(6): 837-841.
引用本文: 缪虹, 孙亚兵, 冯景伟, 王瑾瑜, 徐建华. Fe掺杂PTFE-PbO2/TiO2-NTs/Ti电极的制备、表征及电催化性能[J]. 环境化学, 2012, 31(6): 837-841.
shu
MIAO Hong, SUN Yabing, FENG Jingwei, WANG Jinyu, XU Jianhua. Preparation, characterization and electro-catalytic properties of Fe doped PTFE-PbO2/TiO2-NTs/Ti[J]. Environmental Chemistry, 2012, 31(6): 837-841.
Citation: MIAO Hong, SUN Yabing, FENG Jingwei, WANG Jinyu, XU Jianhua. Preparation, characterization and electro-catalytic properties of Fe doped PTFE-PbO2/TiO2-NTs/Ti[J]. Environmental Chemistry, 2012, 31(6): 837-841.
shu

Fe掺杂PTFE-PbO2/TiO2-NTs/Ti电极的制备、表征及电催化性能

  • 1.  污染控制与资源化研究国家重点实验室, 南京大学环境学院, 南京, 210046;
  • 2.  合肥工业大学土木与水利工程学院, 合肥, 230009
  • 收稿日期:  2011-08-03
基金项目:

污染控制与资源化研究国家重点实验室开放课题(PCRRF10016)

合肥工业大学科学研究发展基金(GDBJ2009-027)

中央高校基本科研业务费专项资金项目(2011HGQC1029)

流域水污染防治技术辅助决策支持平台研究与建筑(2009ZX07529-007-006-003)资助.

摘要: 采用电沉积法制备了Fe掺杂PTFE-PbO2/TiO2-NTs/Ti、PbO2/TiO2-NTs/Ti、PbO2/Ti 3种电极,运用扫描电镜、X射线衍射仪观察表面形貌与形态,通过线性扫描伏安法在0.1 mol·L-1的H2SO4中测定电极的析氧极化曲线.以对硝基酚(p-NP)为目标污染物,考察了电极的电催化活性,在20 mA·cm-2电流密度下降解100 mg·L-1 p-NP,120 min时表观速率常数分别为0.0370 min-1、0.0265 min-1和0.0180 min-1,COD去除率分别为77.38%、74.07%、66.18%,研究发现在相同的条件下Fe掺杂PTFE-PbO2/TiO2-NTs/Ti性能更佳,矿化更完全.
