膜接触器从高浓度含氨废水中脱氨的试验研揪

,  ,  ,

downloadPDF

上一篇

下一篇

王建黎, 徐又一, 徐志康, 徐红. 膜接触器从高浓度含氨废水中脱氨的试验研揪[J]. 环境化学, 2001, 20(6): 595-599.
引用本文: 王建黎, 徐又一, 徐志康, 徐红. 膜接触器从高浓度含氨废水中脱氨的试验研揪[J]. 环境化学, 2001, 20(6): 595-599.
shu
Wang Jianli, Xu Youyik, Xu Zhikang, Xu Hong. PILOT TEST FOR AMMONIA REMOVAL FROM HIGH CONCENTRATION INDUSTRIAL WASTEWATER BY MEMBRANE CONTACTOR[J]. Environmental Chemistry, 2001, 20(6): 595-599.
Citation: Wang Jianli, Xu Youyik, Xu Zhikang, Xu Hong. PILOT TEST FOR AMMONIA REMOVAL FROM HIGH CONCENTRATION INDUSTRIAL WASTEWATER BY MEMBRANE CONTACTOR[J]. Environmental Chemistry, 2001, 20(6): 595-599.
shu

膜接触器从高浓度含氨废水中脱氨的试验研揪

  • 基金项目:

    国家自然科学基金资助项目(No.59833120).

  • 中图分类号: X7

PILOT TEST FOR AMMONIA REMOVAL FROM HIGH CONCENTRATION INDUSTRIAL WASTEWATER BY MEMBRANE CONTACTOR

  • 1.

    Institute of Polymer Science, Zhejiang University, Hangzhou, 3l0027

  • Fund Project:

  • 摘要: 利用微孔膜接触器进行了从高浓度含氨制药废水中脱氨的现场试验.当吸收液酸度大于20%时,浓度为22%的氨水处理量在2-6L·h-1,经面积为1.56m2的膜系统吸收后可使氨水出口浓度低于5%,脱除率大于80%,处理后的低浓度氨水可循环使用,避免了高浓度氨水的直接排放;膜组件进出口温度差小于7℃,出口温度最高不超过45℃;吸收过程母液体积会膨胀,膨胀率约为1/5,母液体积膨胀主要是由于母液吸收氨生成硫酸铵溶质质量增加造成的.
    Abstract: Membrane contactor is equipment good for mass transfer. In this paper, the elimination of ammonia from high-concentration wastewater was carried out with micropores contactor assembled with 1.56m2 polypropylene hollow fiber membrane (PP HFM) . The heat effectiveness was empha-sized . The wastewater came from one process in one vitamin factory. The ammonia concentration of wastewater was 22% . The results indicated that the elimination rate of ammonia was 80% as trea-ted amount was 6 liter per hour, as outlet and inlet ammonia concentration are 5 (wt%) and 22 (wt%) respectively when acid supply around the membrane fibers is sufficient. The temperature difference (△T) of the absorbent was controlled lower than 47℃by using a condenser. The highest temperature of the outlet liquid is 45℃ . The total purpose is that ammonia is immobilized into am-monium sulfate and water can be reused.
  • 加载中
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  611
  • HTML全文浏览数:  611
  • PDF下载数:  172
  • 施引文献:  0
出版历程
  • 收稿日期:  2000-12-30
王建黎, 徐又一, 徐志康, 徐红. 膜接触器从高浓度含氨废水中脱氨的试验研揪[J]. 环境化学, 2001, 20(6): 595-599.
引用本文: 王建黎, 徐又一, 徐志康, 徐红. 膜接触器从高浓度含氨废水中脱氨的试验研揪[J]. 环境化学, 2001, 20(6): 595-599.
shu
Wang Jianli, Xu Youyik, Xu Zhikang, Xu Hong. PILOT TEST FOR AMMONIA REMOVAL FROM HIGH CONCENTRATION INDUSTRIAL WASTEWATER BY MEMBRANE CONTACTOR[J]. Environmental Chemistry, 2001, 20(6): 595-599.
Citation: Wang Jianli, Xu Youyik, Xu Zhikang, Xu Hong. PILOT TEST FOR AMMONIA REMOVAL FROM HIGH CONCENTRATION INDUSTRIAL WASTEWATER BY MEMBRANE CONTACTOR[J]. Environmental Chemistry, 2001, 20(6): 595-599.
shu

膜接触器从高浓度含氨废水中脱氨的试验研揪

  • 收稿日期:  2000-12-30
基金项目:

国家自然科学基金资助项目(No.59833120).

摘要: 利用微孔膜接触器进行了从高浓度含氨制药废水中脱氨的现场试验.当吸收液酸度大于20%时,浓度为22%的氨水处理量在2-6L·h-1,经面积为1.56m2的膜系统吸收后可使氨水出口浓度低于5%,脱除率大于80%,处理后的低浓度氨水可循环使用,避免了高浓度氨水的直接排放;膜组件进出口温度差小于7℃,出口温度最高不超过45℃;吸收过程母液体积会膨胀,膨胀率约为1/5,母液体积膨胀主要是由于母液吸收氨生成硫酸铵溶质质量增加造成的.
