齐一谨, 彭熙, 徐中慧, 徐亚红, 蒋灶, 罗日主. 机械力活化固硫灰固化处理生活垃圾焚烧飞灰[J]. 环境工程学报, 2017, 11(4): 2469-2474. doi: 10.12030/j.cjee.201601077
引用本文: 齐一谨, 彭熙, 徐中慧, 徐亚红, 蒋灶, 罗日主. 机械力活化固硫灰固化处理生活垃圾焚烧飞灰[J]. 环境工程学报, 2017, 11(4): 2469-2474. doi: 10.12030/j.cjee.201601077
shu
QI Yijin, PENG Xi, XU Zhonghui, XU Yahong, JIANG Zao, LUO Rizhu. Solidification/Stabilization of MSWI fly ash with CFBC fly ash activated by mechanochemical method[J]. Chinese Journal of Environmental Engineering, 2017, 11(4): 2469-2474. doi: 10.12030/j.cjee.201601077
Citation: QI Yijin, PENG Xi, XU Zhonghui, XU Yahong, JIANG Zao, LUO Rizhu. Solidification/Stabilization of MSWI fly ash with CFBC fly ash activated by mechanochemical method[J]. Chinese Journal of Environmental Engineering, 2017, 11(4): 2469-2474. doi: 10.12030/j.cjee.201601077
shu

机械力活化固硫灰固化处理生活垃圾焚烧飞灰

  • 1.

    西南科技大学固体废物处理与资源化教育部重点实验室, 绵阳 621010

  • 2.

    西南科技大学非煤矿山安全技术四川省高等学校重点实验室, 绵阳 621010

  • 基金项目:

    固体废物处理与资源化教育部重点实验室专职科研创新团队建设基金资助项目（14tdgk04）

    西南科技大学研究生创新基金资助项目（16ycx030）

  • 中图分类号: X705

Solidification/Stabilization of MSWI fly ash with CFBC fly ash activated by mechanochemical method

  • 1.

    Key Laboratory of Solid Waste Treatment and Resource Recycle, Ministry Education, Southwest University of Science and Technology, Mianyang 621010, China

  • 2.

    The Coal Mine Safety Technology Key Laboratory of Colleges and Universities in Sichuan Province, Southwest University of Science and Technology, Mianyang 621010, China

  • Fund Project:

  • 摘要: 为实现城市生活垃圾焚烧飞灰的安全处理，通过机械力化学法活化循环流化床燃煤固硫灰，探讨了球磨样品制备固化体的参数。并采用X射线衍射仪（XRD）和傅里叶变换红外光谱仪（FTIR）手段对垃圾焚烧飞灰中重金属的固化机制进行了研究。结果表明，当垃圾焚烧飞灰掺加比为60%，球磨转速为600 r·min-1，球磨时间为5 h，养护温度60 ℃时的固化体28 d和56 d抗压强度分别达到15.6 MPa和17.9 MPa，采用原子吸收光谱仪（AAS）测得固化体中Zn、Pb、Cu、Cd和Cr重金属浸出量均低于GB 5085.3-2007规定限值。XRD和FTIR表征结果表明，在水化过程中，该混合体系生成了水化硅酸钙（C—S—H）、斜方钙沸石和钙矾石（AFt）等水化产物，并且C—S—H凝胶可通过物理包裹的形式固化垃圾焚烧飞灰中重金属；斜方钙沸石和钙矾石以化学吸附的方式使垃圾焚烧飞灰中的重金属离子达到固化/稳定化效果，实现了垃圾焚烧飞灰中重金属的安全处理。
    Abstract: To safely dispose municipal solid waste incineration (MSWI) fly ash, circulating fluidized bed combustion (CFBC) fly ash was substantially activated by a mechanochemical method to immobilize the MSWI fly ash. The present research explored the effect on the performance of the solidified waste that immobilized the MSWI fly ash. Furthermore, the solidification mechanism of heavy metals from MSWI fly ash was investigated using X-ray diffraction (XRD) and Fourier transform infrared (FTIR) spectroscopy. The research showed, under these conditions that MSWI fly ash mixing ratio was 60%, velocity of milling was 600 r·min-1, milling time was 5 h, by curing after 28 d and 56 d at 60 ℃, the compressive strength of solidified wastes were 15.6 MPa and 17.9 MPa respectively. Meanwhile, the leaching amounts of Zn、Pb、Cu、Cd、and Cr metals, which were detected by atomic absorption spectroscopy (AAS) in the solidified waste, were much lower than the national standard value (GB 5085.3-2007). The XRD and FTIR analysis indicated that the hydration products of the solidified waste were calcium silicate hydrate (C—S—H), gismondine, ettringite (AFt), etc. Moreover, the heavy metals from the MSWI fly ash mainly were physically encapsulated in the C—S—H and chemically absorbed in the structures of the gismondine and AFt.
  • 加载中
  • [1] POLETTINI A, POMI R, TRINCI L, et al. Engineering and environmental properties of thermally treated mixtures containing MSWI fly ash and low-cost additives[J]. Chemosphere, 2004, 56(10): 901-910
    [2] 刘清才, 鹿存房, 黄本生, 等. 城市生活垃圾焚烧飞灰的熔融分离处理[J]. 环境工程学报, 2008,2(10): 1403-1406
    [3] WANG F H, ZHANG F, CHEN Y J, et al. A comparative study on the heavy metal solidification/stabilization performance of four chemical solidifying agents in municipal solid waste incineration fly ash[J]. Journal of Hazardous Materials, 2015, 300: 451-458
    [4] GUO X, SHI H, HU W, et al. Durability and microstructure of CSA cement-based materials from MSWI fly ash[J]. Cement and Concrete Composites, 2014, 46(2): 26-31
    [5] 马保国, 陈全滨, 李相国, 等. 活化方式对CFBC脱硫灰自硬化性能的影响[J]. 建筑材料学报, 2013, 16(1): 60-64
    [6] 陈德玉, 陈鑫林, 刘元正, 等. 固硫灰的膨胀及其控制[J]. 四川大学学报(工程科学版), 2015, 47(2): 198-204
    [7] 施惠生, 范付忠, 冯涛. 高钙粉煤灰的机械力化学改性[J]. 粉煤灰综合利用, 2000, 14(4): 1-5
    [8] YAN J H, PENG Z, LU S Y, et al. Degradation of PCDD/Fs by mechanochemical treatment of fly ash from medical waste incineration[J]. Journal of Hazardous Materials, 2007, 147(1/2):652-657
    [9] 国家环境保护总局. HJT 299-2007 固体废物浸出毒性浸出方法硫酸硝酸法[M]. 北京:中国环境科学出版社,2007:5
    [10] 陈世柱, 黎文献, 尹志民. 行星式高能球磨机工作原理研究[J]. 矿冶工程, 1997(4):64-67
    [11] 杨南如. 机械力化学过程及效应(Ⅰ)——机械力化学效应[J]. 建筑材料学报, 2000, 3(1): 26-33
    [12] WANG C Q, TAN K F, XU X X, et al. Effect of activators, admixtures and temperature on the early hydration performance of desulfurization ash[J]. Construction and Building Materials, 2014, 70(70): 322-331
    [13] CHEN C G, SUN C J, GAU S H, et al. The effects of the mechanical-chemical stabilization process for municipal solid waste incinerator fly ash on the chemical reactions in cement paste[J]. Waste Managment, 2013, 33(4): 858-865
    [14] 国家环境保护总局. GB 5085.3-2007 危险废物鉴别标准 浸出毒性鉴别[M]. 北京:中国环境科学出版社,2007
    [15] LI F, LI Q, ZHAI J P, et al. Effect of zeolitization of CFBC fly ash on immobilization of Cu2+, Pb2+, and Cr3+[J]. Industrial & Engineering Chemistry Research, 2007, 46(22): 7087-7095
    [16] DUNG N T, CHANG T P, CHEN C T. Hydration process and compressive strength of slag-CFBC fly ash materials without portland cement[J]. Journal of Materials in Civil Engineering, 2015, 27(7): 1-9
    [17] LEE T C, LI Z S. Conditioned MSWI ash-slag-mix as a replacement for cement in cement mortar[J], Construction and Building Materials, 2010, 24(6): 970-979
    [18] 王昕, 颜碧兰, 汪澜, 等. 不同钙硅比C—S—H对多种重金属离子的俘获及其稳定[J]. 硅酸盐通报, 2012, 17(6):1356-1362
    [19] 汪澜, 颜碧兰, 王昕, 等. 不同重金属离子对C—S—H凝胶影响及其固化稳定性[J]. 建筑材料学报, 2014, 17(5):790-796
    [20] 王昕, 崔素萍, 汪澜, 等. 钙矾石对不同价态Cr离子的固化稳定性[J]. 硅酸盐通报, 2015, 34(11):3308-3314
    [21] 陈灿, 谢伟强, 李小明, 等. 水泥、粉煤灰及生石灰固化/稳定处理铅锌废渣[J]. 环境化学, 2015, 34(8):1553-1560
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1524
  • HTML全文浏览数:  1247
  • PDF下载数:  398
  • 施引文献:  0
出版历程
  • 收稿日期:  2016-06-21
  • 刊出日期:  2017-04-22
齐一谨, 彭熙, 徐中慧, 徐亚红, 蒋灶, 罗日主. 机械力活化固硫灰固化处理生活垃圾焚烧飞灰[J]. 环境工程学报, 2017, 11(4): 2469-2474. doi: 10.12030/j.cjee.201601077
引用本文: 齐一谨, 彭熙, 徐中慧, 徐亚红, 蒋灶, 罗日主. 机械力活化固硫灰固化处理生活垃圾焚烧飞灰[J]. 环境工程学报, 2017, 11(4): 2469-2474. doi: 10.12030/j.cjee.201601077
shu
QI Yijin, PENG Xi, XU Zhonghui, XU Yahong, JIANG Zao, LUO Rizhu. Solidification/Stabilization of MSWI fly ash with CFBC fly ash activated by mechanochemical method[J]. Chinese Journal of Environmental Engineering, 2017, 11(4): 2469-2474. doi: 10.12030/j.cjee.201601077
Citation: QI Yijin, PENG Xi, XU Zhonghui, XU Yahong, JIANG Zao, LUO Rizhu. Solidification/Stabilization of MSWI fly ash with CFBC fly ash activated by mechanochemical method[J]. Chinese Journal of Environmental Engineering, 2017, 11(4): 2469-2474. doi: 10.12030/j.cjee.201601077
shu

机械力活化固硫灰固化处理生活垃圾焚烧飞灰

  • 1.  西南科技大学固体废物处理与资源化教育部重点实验室, 绵阳 621010
  • 2.  西南科技大学非煤矿山安全技术四川省高等学校重点实验室, 绵阳 621010
  • 收稿日期:  2016-06-21
基金项目:

固体废物处理与资源化教育部重点实验室专职科研创新团队建设基金资助项目（14tdgk04）

西南科技大学研究生创新基金资助项目（16ycx030）

摘要: 为实现城市生活垃圾焚烧飞灰的安全处理，通过机械力化学法活化循环流化床燃煤固硫灰，探讨了球磨样品制备固化体的参数。并采用X射线衍射仪（XRD）和傅里叶变换红外光谱仪（FTIR）手段对垃圾焚烧飞灰中重金属的固化机制进行了研究。结果表明，当垃圾焚烧飞灰掺加比为60%，球磨转速为600 r·min-1，球磨时间为5 h，养护温度60 ℃时的固化体28 d和56 d抗压强度分别达到15.6 MPa和17.9 MPa，采用原子吸收光谱仪（AAS）测得固化体中Zn、Pb、Cu、Cd和Cr重金属浸出量均低于GB 5085.3-2007规定限值。XRD和FTIR表征结果表明，在水化过程中，该混合体系生成了水化硅酸钙（C—S—H）、斜方钙沸石和钙矾石（AFt）等水化产物，并且C—S—H凝胶可通过物理包裹的形式固化垃圾焚烧飞灰中重金属；斜方钙沸石和钙矾石以化学吸附的方式使垃圾焚烧飞灰中的重金属离子达到固化/稳定化效果，实现了垃圾焚烧飞灰中重金属的安全处理。
