有机蒸气-空气分子扩散系数测定的影响因素分析
Effect factors analysis of determination of molecular diffusion coefficient of organic vapor-air
-
摘要: 利用自行研发的气体扩散系数测试装置及测定方法，分别测定和分析了常温常压下，不同扩散管径、扩散距离、体系温度、气体进气方式及其流量、扩散时间等对气体扩散系数测定的影响情况。基于拟稳态扩散模型，得出气体扩散系数测定的合理条件：扩散距离为9~14 cm；吹气流量为0.22~0.33 m3·h-1；体系温度应低于液体沸点且不要太接近沸点；扩散时间根据液体挥发性情况，一般不小于12 h，具体以能够明显观测到测定前后液面高度差为基准；扩散管管径应在保证扩散管截面积较小、液面以上气体以单向自然扩散为主、液体蒸发速度相对较慢的范围内选取。研究结果确定了气体扩散系数测定的合理条件，对加深油气空间传质机理的认识以及确保扩散系数测定的准确度具有重要指导意义。Abstract: Effects of several factors such as diffusion tube diameter,diffusion distance,system temperature,gas inlet pathway,and flow and diffusion time on the determination of the gas diffusion coefficient under normal temperature and pressure were determined using a novel experimental device and determination method. Based on the quasi-steady-state diffusion model,reasonable conditions for determining the diffusion coefficient were obtained:a diffusion distance of 9 to 14 cm,air flow of 0.22 to 0.33 m3·h-1,and system temperature that is substantially less than the boiling point of the liquid. The diffusion time should generally be at least 12 h depending on the volatility of the liquid,and it should be benchmarked against the liquid surface height difference before and after the measurement. The diffusion tube diameter should be selected based on the observation that as the cross-sectional area decreases,the gas above the liquid surface becomes dominated by one-way natural diffusion,slowing the evaporation of the liquid. The results provide reasonable conditions for determining the diffusion coefficient and will play an important role in obtaining an in-depth understanding of the oil and gas mass transfer mechanism of space and ensuring the accuracy of diffusion coefficient measurements.
-
-
[1] 吴琦. 环境风险评价中危险气体扩散模式计算方法研究[D]. 哈尔滨:东北林业大学, 2008 [2] 刘泽常, 李娜, 侯鲁健, 等. 济南市环境空气VOCs的化学反应活性及关键活性组分研究[J]. 环境工程学报, 2015, 9(2):873-877 [3] 黄维秋. 油气回收基础理论及其应用[M]. 北京:中国石化出版社, 2011:33-34 [4] 时钧, 汪家鼎, 余国琮, 等. 化学工程手册[M]. 北京:化学工业出版社, 1996:145-150 [5] 王国香. 多孔介质有效扩散系统的测定研究[D]. 大连:大连交通大学, 2012 [6] 郭平, 涂汉敏, 汪周华, 等. 多组分气-气扩散系数的计算[J]. 天然气工业, 2015, 35(8):39-43 [7] 王瑞, 张宁生, 刘晓娟, 等. 页岩气扩散系数和视渗透率的计算与分析[J]. 西北大学学报(自然科学版), 2013, 43(1):75-80 [8] 晋宏营. 气体分子扩散的蒙特卡罗模拟[J]. 井冈山大学学报(自然科学版), 2012, 33(2):27-30 [9] ZHAO Yongliang, FENG Yanhui, ZHANG Xinxin. Molecular simulation of CO2/CH4 self-and transport diffusion coefficients in coal[J]. Fuel, 2016, 165:19-27 [10] 晋宏营. 计算机模拟估算气体的扩散系数[J]. 计算机与应用化学, 2012, 29(11):1294-1298 [11] 何茂刚, 郭盈, 钟秋, 等. 激光全息干涉法测量二元气体扩散系数[J]. 工程热物理学报, 2010, 31(3):369-372 [12] 王操. 高温高压下二元气体扩散系数的激光测试系统与仿真[D]. 武汉:华中科技大学, 2012 [13] KARAISKAKIS G, GAVRIL D. Determination of diffusion coefficients by gas chromatography[J]. Journal of Chromatography A, 2004, 1037(1/2):147-189 [14] VILLET M C, GAVALAS G R. Measurement of concentration-dependent gas diffusion coefficients in membranes from a psuedo-steady state permeation run[J]. Journal of Membrane Science, 2007, 297(1/2):199-205 [15] 陈振涛, 徐春明, 周浩, 等. 减压渣油超临界流体萃取馏分在多孔有机膜中的扩散规律[J]. 化工学报, 2009, 60(12):3042-3051 [16] 衡阳师范学院. 双流气准静态法测量气体扩散系数的方法:CN102621039A[P]. 2013-10-23 [17] 徐洪峰, 王国香, 史继诚, 等. 二元气体扩散系数的一种测定方法[J]. 大连交通大学学报, 2012, 33(5):90-92 [18] 常州大学. 一种气体扩散系数的测试装置及方法:CN104865164A[P]. 2015-08-26 [19] FULLER E N, SCHETTLER P D, GIDDINGS J C. New method for prediction of binary gas-phase diffusion coefficients[J]. Industrial & Engineering Chemistry, 1966, 58(5):18-27 [20] 胡伟, 李钦祖, 候镜德. 逆流气相色谱法测定扩散系数[J]. 分析测试技术与仪器, 1997, 3(1):49-52 [21] CUSSLER E L. 扩散:流体系统中的传质[M].2版. 王宇新, 姜忠义, 译. 北京:化学工业出版社, 2002:63-64 -
