响应面法优化光催化/臭氧氧化深度处理炼油废水

,  ,  ,

downloadPDF

上一篇

下一篇

倪可, 王利平, 肖春宝, 李新颖. 响应面法优化光催化/臭氧氧化深度处理炼油废水[J]. 环境工程学报, 2014, 8(12): 5349-5355.
引用本文: 倪可, 王利平, 肖春宝, 李新颖. 响应面法优化光催化/臭氧氧化深度处理炼油废水[J]. 环境工程学报, 2014, 8(12): 5349-5355.
shu
Ni Ke, Wang Liping, Xiao Chunbao, Li Xinying. Optimization of photocatalytic/ozonation treatment process for oil-refinery wastewater with response surface methodology[J]. Chinese Journal of Environmental Engineering, 2014, 8(12): 5349-5355.
Citation: Ni Ke, Wang Liping, Xiao Chunbao, Li Xinying. Optimization of photocatalytic/ozonation treatment process for oil-refinery wastewater with response surface methodology[J]. Chinese Journal of Environmental Engineering, 2014, 8(12): 5349-5355.
shu

响应面法优化光催化/臭氧氧化深度处理炼油废水

  • 1.

    常州大学环境与安全工程学院, 常州 213164

  • 2.

    中国石化安庆分公司安全环保部, 安庆 246001

  • 基金项目:

    常州市社会发展科技计划项目(CS20090008)

    常州科教城科研基金(K2012307)

    常州市产学研合作项目(CF20140011)

  • 中图分类号: X703

Optimization of photocatalytic/ozonation treatment process for oil-refinery wastewater with response surface methodology

  • 1.

    College of Environmental and Safety Engineering, Changzhou University, Changzhou 213164, China

  • 2.

    Safety and Environmental Protection Department, Sinopec Anqing Corporation, Anqing 246001, China

  • Fund Project:

  • 摘要: 利用响应面方法(RSM)对光催化/臭氧氧化深度处理炼油废水工艺进行优化,考察了臭氧通量、光催化剂投加量、初始pH和反应时间对于处理效果的影响,提出采用该工艺的数学模型及优化后的工艺参数。结果表明,各影响因子对COD去除率影响顺序为反应时间>光催化剂投加量>初始pH>臭氧通量,方程的F值为11.54,相关系数为0.9537,调整相关系数为0.915,说明数学模型可以较好地模拟真实的反应曲面。优化得到最佳的工艺参数:臭氧通量1.05 L/min、光催化剂投加量0.33 g/L、初始pH 7.51、反应时间96.95 min,在该条件下,对COD去除率为97.88%,与预测值99.49%接近。采用95%处理水和5%新鲜水混合,水质达到了循环冷凝水的补充水水质指标要求。
    Abstract: Response surface methodology was employed to optimize the photocatalytic/ozonation treatment process for oil-refinery wastewater. The effects of O3 flux, catalyst dosing quantity, initial pH and reaction time on COD removal were investigated. What's more, the mathematical model and optimized parameters of process were also achieved. The results showed that the effects of different factors on COD removal were as follows: reaction time > catalyst dosing quantity > initial pH > reaction time. The mathematical model could greatly response the practical process with the equation F-value of 11.54, correlation coefficient of 0.9537 and adjusted correlation coefficient of 0.915. The optimum process parameters of oil-refinery wastewater treatment were O3 flux of 1.05 L/min, catalyst dosing quantity of 0.33 g/L, initial pH of 7.51, reaction time of 96.95 min. Under the optimum conditions, the actual COD removal rate was 97.88% which closed to the predicted value of 99.49%. The mixed water with the ratio of treated water and fresh water of 95:5 reached the circulation condensate make-up water quality standards.
  • 加载中
  • [1] 苟钰娴,杨凤林,石利军.一体式A/O摇动床工艺处理石化废水.环境工程学报,2007,1(2):34-38 Ge Y. X., Yang F. L., Shi L. J.Treatment of petroch-emical wastewater using integrative A/O swimbed process. Chinese Journal of Environmental Engineering,2007,1(2):34-38(in Chinese)
    [2] Zhu X. B.,Tian J. P., Liu R.,et al. Optimization of F-enton and electro-Fenton oxidation of biologically treated coking wastewater using response surface methodology. Separation and Purification Technology,2011,81(3):444-450
    [3] 张冬梅,刘蕾,褚衍洋.电-Fenton氧化降解2,4-二氯酚.环境科学研究,2012,25(9):1041-1046 Zhang D. M., Liu L., Zhu Y. Y. Degradation of 2,4-dichlorophenol by electro-Fenton oxidation process. Research of Environmental Sciences,2012,25(9):1041-1046(in Chinese)
    [4] Arnan I., Dona R. J. M., Rendon E.T., et al. TiO2 a-ctivation by using activated carbon as a support:Part Ⅱ. Applied Catalysis B:Environmental,2003,44(2):153-160
    [5] 钱伯章,朱建芳.炼油废水处理技术新进展.化工环保,2009,29(2):99-104 Qian B. Z., Zhu J. F. Development of technologies for petrochemical wastewater treatment. Environmental Protection of Chemical Industry,2009,29(2):99-104(in Chinese)
    [6] 蔡少卿,戴启洲,王佳裕.非均相催化臭氧处理高浓度制药废水的研究.环境科学学报, 2011,31(7):1440-1449 Cai S. Q., Dai Q. Z., Wang J. Y. Heterogeneous catal-ytic ozone oxidation for pharmaceutical wastewater treatment. Acta Scientiae Circumstantiae,2011,31(7):1440-1449(in Chinese)
    [7] Alaton I. A., Tureli G., Hanci T. O. Treatment of az-odye production wastewaters using photo-Fenton-like a-dvanced oxidation processes: Optimization by response surface methodology. Journal of Photochemistry and Photobiology A: Chemistry,2009,202(2-3):142-153
    [8] Zhong K., Wang Q. Optimization of ultrasonic extraction of polysaccharides from dried longan pulp using response surface methodology. Carbohydrate Polymers,2010,80(1):19-25
    [9] Jain M., Garg V. K., Kadirvelu K. Investigation of Cr(VI) adsorption onto chemically treated Helianthus annuus: Optimization using response surface methodology.Bioresource Technology,2011,102(2):600-605
    [10] 崔旭峰,杜尔登.响应面方法优化光催化降解抗生素类污染物过程研究.环境科学与管理,2010,35(7):70-74,99 Cui X. F., Du E. D. Optimization of photocatalytic degradation of antibiotic pollutant by response surface method. Environmental Science and Management,2010,102(2):600-605(in Chinese)
    [11] Wang J. P., Chen Y. Z., Wang Y., et al. Optimization of the coagulation flocculation process for pulp mill wastewater treatment using a combination of uniform design and response surface methodology. Water Research,2011, 45(17):5633-5640
    [12] Hasa H. A., Abdullah S. R., Kamarudin S. K, et al.Response surface methodology for optimization of simultaneous COD, NH4+-N and Mn2+ removal from drinking water by biological aerated filter.Desalination,2011,275(1-3):50-61
    [13] Bhatti M. S., Reddy A. S., Thukral A. K. Electroco-agulation removal of Cr(VI) from simulated wastewater using response surface methodology. Journal of Hazardous Materials,2009,172(2-3):839-846
    [14] 胡中华,王晓静.一种活性炭负载二氧化钛光催化剂的制备方法:中国,CN101244383A,2008-08-20
    [15] 刘守新,陈曦.TiO2/活性炭负载型光催化剂的溶胶-凝胶法合成及表征.催化学报,2008,29(1):19-24 Liu S.X., Chen X. Sol-gel preparation and characteri-zation of activated carbon supported TiO2 photocatalyst.Chinese Journal of Catalysis,2008,29(1):19-24(in Chinese)
    [16] Neseli S., Yaldiz S., Turkes E. Optimization of tool geometry parameters for turning operations based on the response surface methodology. Measurement, 2011,44(3):580-587
    [17] Bezerra M. A., Santelli R. E., Oliverra E. P.,et al. Re-sponse surface methodology (RSM) as a tool for opti-mization in analytical chemistry.Talanta,2008,76(5):965-977
    [18] Zhang Z. M., Zheng H. L. Optimization for decolori-zation of azo dye acid green 20 by ultrasound and H2O2 using response surface methodology. Journal of Hazardous Materials,2009,172(2-3):1388-1393
    [19] Singh P., Shera S. S., Banik J.,et al. Optimization ofcultural conditions using response surface methodology versus artificial neural network and modeling of L-glutaminase production by Bacillus cereus MTCC 1305.Bioresource Technology,2013,137(4):261-269
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1599
  • HTML全文浏览数:  1065
  • PDF下载数:  765
  • 施引文献:  0
出版历程
  • 收稿日期:  2013-12-18
  • 刊出日期:  2014-12-03
倪可, 王利平, 肖春宝, 李新颖. 响应面法优化光催化/臭氧氧化深度处理炼油废水[J]. 环境工程学报, 2014, 8(12): 5349-5355.
引用本文: 倪可, 王利平, 肖春宝, 李新颖. 响应面法优化光催化/臭氧氧化深度处理炼油废水[J]. 环境工程学报, 2014, 8(12): 5349-5355.
shu
Ni Ke, Wang Liping, Xiao Chunbao, Li Xinying. Optimization of photocatalytic/ozonation treatment process for oil-refinery wastewater with response surface methodology[J]. Chinese Journal of Environmental Engineering, 2014, 8(12): 5349-5355.
Citation: Ni Ke, Wang Liping, Xiao Chunbao, Li Xinying. Optimization of photocatalytic/ozonation treatment process for oil-refinery wastewater with response surface methodology[J]. Chinese Journal of Environmental Engineering, 2014, 8(12): 5349-5355.
shu

响应面法优化光催化/臭氧氧化深度处理炼油废水

  • 1. 常州大学环境与安全工程学院, 常州 213164
  • 2. 中国石化安庆分公司安全环保部, 安庆 246001
  • 收稿日期:  2013-12-18
基金项目:

常州市社会发展科技计划项目(CS20090008)

常州科教城科研基金(K2012307)

常州市产学研合作项目(CF20140011)

摘要: 利用响应面方法(RSM)对光催化/臭氧氧化深度处理炼油废水工艺进行优化,考察了臭氧通量、光催化剂投加量、初始pH和反应时间对于处理效果的影响,提出采用该工艺的数学模型及优化后的工艺参数。结果表明,各影响因子对COD去除率影响顺序为反应时间>光催化剂投加量>初始pH>臭氧通量,方程的F值为11.54,相关系数为0.9537,调整相关系数为0.915,说明数学模型可以较好地模拟真实的反应曲面。优化得到最佳的工艺参数:臭氧通量1.05 L/min、光催化剂投加量0.33 g/L、初始pH 7.51、反应时间96.95 min,在该条件下,对COD去除率为97.88%,与预测值99.49%接近。采用95%处理水和5%新鲜水混合,水质达到了循环冷凝水的补充水水质指标要求。
