复配混凝剂理化特性及性能

,  ,  ,  ,

downloadPDF

上一篇

下一篇

蒋绍阶, 盛贵尚, 黄新丽, 向平, 冯欣蕊. 复配混凝剂理化特性及性能[J]. 环境工程学报, 2013, 7(12): 4683-4688.
引用本文: 蒋绍阶, 盛贵尚, 黄新丽, 向平, 冯欣蕊. 复配混凝剂理化特性及性能[J]. 环境工程学报, 2013, 7(12): 4683-4688.
shu
Jiang Shaojie, Sheng Guishang, Huang Xinli, Xiang Ping, Feng Xinrui. Physico-chemical properties and performance of composite coagulants[J]. Chinese Journal of Environmental Engineering, 2013, 7(12): 4683-4688.
Citation: Jiang Shaojie, Sheng Guishang, Huang Xinli, Xiang Ping, Feng Xinrui. Physico-chemical properties and performance of composite coagulants[J]. Chinese Journal of Environmental Engineering, 2013, 7(12): 4683-4688.
shu

复配混凝剂理化特性及性能

  • 1.

    重庆大学城市建设与环境工程学院, 重庆 400045

  • 2.

    重庆市规划设计研究院四川分院, 成都 610031

  • 基金项目:

    国家水体污染控制与治理重大专项（2009ZX07424-004）

    国家科技支撑计划项目（2012BAJ25B06-001）

  • 中图分类号: X703

Physico-chemical properties and performance of composite coagulants

  • 1.

    Faculty of Urban Construction & Environmental Engineering, Chongqing University, Chongqing 400045, China

  • 2.

    Chongqing Planning & Design Institute Sichuan Branch, Chengdu 610031, China

  • Fund Project:

  • 摘要: 用聚二甲基二烯丙基氯化铵（PDM）、聚合氯化铝（PAC）按照质量比1%制备了复配混凝剂，研究了其理化特性及原水污染物去除效果。利用Al-Ferron逐时络合比色法研究了复配混凝剂的铝（Ⅲ）形态分布，结果表明，Ala、Alb和Alc分别占12.62%、16.02%和71.36%。复配混凝剂Zeta电位平均值为41.6 mV。红外吸收光谱分析表明复配混凝剂的羟基缔合程度比PAC要高。扫描电镜结果表明，固体复配混凝剂表面较为粗糙、结构疏松。相同投加量时，复配混凝剂对江河水、水库水的浊度、CODMn、UV254的去除效率均优于PAC。实验利用针杆藻人工模拟高藻原水，当投加PDM：PAC质量比10%的复配混凝剂10 mg/L时，复配混凝剂对藻类的去除率为80.5%。
    Abstract: The composite coagulants were prepared by poly (dimethyldiallylammonium chloride) (PDM) and poly aluminum chloride (PAC) at mass ratio of 1% in this study. Research on physico-chemical properties of composite coagulants was done, and removal efficiency of pollutants in raw water with composite coagulants was also investigated. Aluminum species distribution of composite coagulants was investigated by Al-Ferron complexation timed spectrophotometry. The result shows that proportions of Ala, Alb and Alc were 12.62%, 16.02%, 71.36%, respectively. The average Zeta potential of composite coagulants was 41.6 mV. The level of hydroxyl radical association of composite coagulants was higher than PAC, when infrared absorption spectrograms of composite coagulants and PAC were compared. The result of scanning electron microscope test revealed that composite coagulants had coarse surface and loose microstructure. The removal rate of turbidity, CODMn and UV254 with composite coagulants was higher than with PAC, when coagulant dosage was same in treatment of river and lake water. Simulated algae-rich water was prepared by Synedra, composite coagulants were prepared by PDM and PAC at mass ratio of 10%, removal rate of algae was 80.5% when the dosage of composite coagulants was 10 mg/L.
  • 加载中
  • [1] 许艳秋, 唐薇, 黄玉明, 等. 嘉陵江重庆段水中的有机物污染研究. 西南大学学报(自然科学版), 2010, 32(1):89-93 Xu Yanqiu, Tang Wei, Huang Yuming, et al. Study of the organic pollutants in the Jialing River in Chongqing. Journal of Southwest University (Natural Science Edition), 2010, 32(1):89-93(in Chinese)
    [2] 蒋绍阶, 蒋晖, 向平, 等. 强化混凝去除尖针杆藻的优化研究. 土木建筑与环境工程, 2012, 34(6):120-125 Jiang Shaojie, Jiang Hui, Xiang Ping, et al. Optimization analysis on the removal of Synedra Acus by enhanced coagulation. Journal of Civil, Architectural & Environmental Engineering, 2012, 34(6):120-125(in Chinese)
    [3] 王萌萌, 高宝玉, 曹百川, 等. 等无机-有机复合混凝剂处理夏季引黄水库水的对比研究. 中国环境科学, 2012, 32(2):242-248 Wang Mengmeng, Gao Baoyu, Cao Baichuan, et al. Comparison of two inorganic-organic composite coagulants in treating reservoir raw water from the Yellow River. China Environmental Science, 2012, 32(2):242-248(in Chinese)
    [4] 刘丽娟, 汪琳, 李明玉, 等. 不同混凝剂强化除藻、除浊的研究. 中国给水排水, 2010, 26(5):80-83 Liu Lijuan, Wang Lin, Li Mingyu, et al. Removal of algae and turbidity from lake water by several coagulants. China Water & Wastewater, 2010, 26(5):80-83(in Chinese)
    [5] 柳姝, 黄培坤, 汪群慧, 等. 混凝-微气泡气浮法处理含藻废水的研究. 环境工程学报, 2008, 2(12):1639-1643 Liu Shu, Huang Peikun, Wang Qunhui, et al. Study on treatment of algae-laden wastewater using coagulation-micro bubble air flotation process. Chinese Journal of Environmental Engineering, 2008, 2(12):1639-1643(in Chinese)
    [6] 黄曼君, 李明玉, 任刚, 等. PFS-PDM 复合混凝剂对微污染河水的强化混凝处理. 中国环境科学, 2011, 31(3):384-389 Huang Manjun, Li Mingyu, Ren Gang, et al. Enhanced coagulation treatment of micro-polluted Liuxi River water with the composite coagulant of PFS-PDM. China Environmental Science, 2011, 31(3):384-389(in Chinese)
    [7] 姜瑞雪, 王龙, 张丽. 强化混凝在微污染水源水处理中的应用. 水资源保护, 2006, 22(5):68-70 Jiang Ruixue, Wang Long, Zhang Li. Application of enhanced coagulation to treatment of micro-polluted water. Water Resources Protection, 2006, 22(5):68-70(in Chinese)
    [8] 刘成, 高乃云, 蔡云龙. 强化混凝去除黄浦江原水中有机物研究. 中国给水排水, 2006, 22(1):84-87 Liu Cheng, Gao Naiyun, Cai Yunlong. Study on removal effect of organics from Huangpu River water by enhanced coagulation. China Water & Wastewater, 2006, 22(1):84-87(in Chinese)
    [9] 彭建雄, 薛安, 赵华章, 等. 以Al-Ferron逐时络合比色法研究有机硅铝复合絮凝剂中铝的形态分布. 环境科学, 2008, 29(9):2513-2517 Peng Jianxiong, Xue An, Zhao Huazhang, et al. Al species distribution of organic silicate aluminum hybrid flocculants by Al-Ferron complexation timed spectrophotometric method. Environmental Science, 2008, 29(9):2513-2517(in Chinese)
    [10] 曹福, 凌燕, 顾竟禹. 聚磷氯化铝铁溶液形态转化及电动特性. 环境科学与技术, 2011, 34(5):69-72 Cao Fu, Ling Yan, Gu Jingyu. Species transformation and electrokinetic properties of hydroxyl polymeric aluminum-ferric chloride solutions. Environmental Science & Technology, 2011, 34(5):69-72(in Chinese)
    [11] 余莉君, 赵虎, 李圭白, 等. 粉末活性炭-混凝-超滤联用处理含藻水的研究. 中国给水排水, 2008, 24(19):51-54 Yu Lijun, Zhao Hu, Li Guibai, et al. Study on treatment of water with algae by PAC/coagulation/ultrafiltration Process. China Water & Wastewater, 2008, 24(19):51-54
    [12] 曹福, 刘红, 吴克明. 聚合氯化铝铁的电动性能研究. 环境污染与防治, 2007, 29(9):674-677 Cao Fu, Liu Hong, Wu Keming. Research on the electrokinetic properties of polyaluminium ferric chloride. Environmental Pollution & Control, 2007, 29(9):674-677(in Chinese)
    [13] 徐小洁, 吴纯德, 叶健, 等. 基于Zeta电位的硅藻土复配混凝剂强化混凝研究. 环境科学与技术, 2010, 33(10):151-153 Xu Xiaojie, Wu Chunde, Ye Jian, et al. Enhanced coagulation by diatomite blends based on Zeta potential. Environmental Science & Technology, 2010, 33(10):151-153(in Chinese)
    [14] 石宝友, 汤鸿霄. 聚合氯化铝与有机高分子复合絮凝剂的形态分布研究:Al-Ferron和27Al-NMR相结合. 环境科学学报, 2000, 20(3):391-396 Shi Baoyou, Tang Hongxiao. Study on the speciation of polyaluminum-organic polymer composite flocculants:Combination of Al-Ferron and 27Al-NMR methods. Acta Scientiae Circumstantiae, 2000, 20(3):391-396(in Chinese)
    [15] 张跃军, 徐晶晶, 李潇潇. 复合混凝剂中PDM 对PAC 铝形态分布影响. 应用基础与工程科学学报, 2012, 20(3):367-376 Zhang Yuejun, Xu Jingjing, Li Xiaoxiao. Effect of PDM in composite coagulants on the aluminum species distribution in PAC. Journal of Basic Science and Engineering, 2012, 20(3):367-376(in Chinese)
    [16] 龚竹青, 刘立华, 郑雅杰. 聚二甲基二烯丙基氯化铵与聚合硫酸铁复合絮凝剂的制备及应用研究. 环境污染治理技术与设备, 2004, 5(10):35-39 Gong Zhuqing, Liu Lihua, Zheng Yajie. Study on preparation and application of poly (dimethyldiallylammonium chloride)-polyferric sulfate composite flocculant. Techniques and Equipment for Environmental Pollution Control, 2004, 5(10):35-39(in Chinese)
    [17] 赵晓蕾, 张跃军, 李潇潇, 等. PAC/PDM对夏季太湖预氯化高藻水的除藻效能. 南京理工大学学报(自然科学版), 2010, 34(4):570-574 Zhao Xiaolei, Zhang Yuejun, Li xiaoxiao, et al. Algae-removal effects of PAC/PDM on Taihu Lake prechlorination algae-rich water in summer. Journal of Nanjing University of Science and Technology (Natural Science), 2010, 34(4):570-574(in Chinese)
    [18] 李潇潇, 张跃军, 贾进洲. 聚合硫酸铁复合混凝剂处理秋季长江水研究. 工业水处理, 2011, 31(10):46-49 Li Xiaoxiao, Zhang Yuejun, Jia Jinzhou. Studies on the treatment of autumn Yangtze River raw water by polyferric sulfate composite coagulants. Industrial Water Treatment, 2011, 31(10):46-49(in Chinese)
    [19] 赵晓蕾, 张跃军, 李潇潇, 等. AS/PDM 复合混凝剂对冬季太湖原水除藻效果研究. 环境科学, 2009, 30(4):1023-1028 Zhao Xiaolei, Zhang Yuejun, Li Xiaoxiao, et al. Algae-removal effect of AS/PDM composite coagulants to winter Taihu Lake raw water. Environmental Science, 2009, 30(4):1023-1028(in Chinese)
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1636
  • HTML全文浏览数:  946
  • PDF下载数:  912
  • 施引文献:  0
出版历程
  • 收稿日期:  2013-02-23
  • 刊出日期:  2013-12-08
蒋绍阶, 盛贵尚, 黄新丽, 向平, 冯欣蕊. 复配混凝剂理化特性及性能[J]. 环境工程学报, 2013, 7(12): 4683-4688.
引用本文: 蒋绍阶, 盛贵尚, 黄新丽, 向平, 冯欣蕊. 复配混凝剂理化特性及性能[J]. 环境工程学报, 2013, 7(12): 4683-4688.
shu
Jiang Shaojie, Sheng Guishang, Huang Xinli, Xiang Ping, Feng Xinrui. Physico-chemical properties and performance of composite coagulants[J]. Chinese Journal of Environmental Engineering, 2013, 7(12): 4683-4688.
Citation: Jiang Shaojie, Sheng Guishang, Huang Xinli, Xiang Ping, Feng Xinrui. Physico-chemical properties and performance of composite coagulants[J]. Chinese Journal of Environmental Engineering, 2013, 7(12): 4683-4688.
shu

复配混凝剂理化特性及性能

  • 1. 重庆大学城市建设与环境工程学院, 重庆 400045
  • 2. 重庆市规划设计研究院四川分院, 成都 610031
  • 收稿日期:  2013-02-23
基金项目:

国家水体污染控制与治理重大专项（2009ZX07424-004）

国家科技支撑计划项目（2012BAJ25B06-001）

摘要: 用聚二甲基二烯丙基氯化铵（PDM）、聚合氯化铝（PAC）按照质量比1%制备了复配混凝剂，研究了其理化特性及原水污染物去除效果。利用Al-Ferron逐时络合比色法研究了复配混凝剂的铝（Ⅲ）形态分布，结果表明，Ala、Alb和Alc分别占12.62%、16.02%和71.36%。复配混凝剂Zeta电位平均值为41.6 mV。红外吸收光谱分析表明复配混凝剂的羟基缔合程度比PAC要高。扫描电镜结果表明，固体复配混凝剂表面较为粗糙、结构疏松。相同投加量时，复配混凝剂对江河水、水库水的浊度、CODMn、UV254的去除效率均优于PAC。实验利用针杆藻人工模拟高藻原水，当投加PDM：PAC质量比10%的复配混凝剂10 mg/L时，复配混凝剂对藻类的去除率为80.5%。
