不同流量分配比对多级A/O工艺去除有机物及脱氮的影响

,  ,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

王敏, 张智, 陈杰云, 范功端, 金可, 梁鹏, 胡玲. 不同流量分配比对多级A/O工艺去除有机物及脱氮的影响[J]. 环境工程学报, 2013, 7(4): 1430-1434.
引用本文: 王敏, 张智, 陈杰云, 范功端, 金可, 梁鹏, 胡玲. 不同流量分配比对多级A/O工艺去除有机物及脱氮的影响[J]. 环境工程学报, 2013, 7(4): 1430-1434.
shu
Wang Min, Zhang Zhi, Chen Jieyun, Fan Gongduan, Jin Ke, Liang Peng, Hu Ling. Influence of different influent flow distribution ratios on biological nitrogen and carbon removal by multi-stages A/O process[J]. Chinese Journal of Environmental Engineering, 2013, 7(4): 1430-1434.
Citation: Wang Min, Zhang Zhi, Chen Jieyun, Fan Gongduan, Jin Ke, Liang Peng, Hu Ling. Influence of different influent flow distribution ratios on biological nitrogen and carbon removal by multi-stages A/O process[J]. Chinese Journal of Environmental Engineering, 2013, 7(4): 1430-1434.
shu

不同流量分配比对多级A/O工艺去除有机物及脱氮的影响

  • 1.

    重庆大学三峡库区生态环境教育部重点实验室,重庆 400045

  • 2.

    中国人民解放军总后勤部建筑设计研究院,北京 100036

  • 3.

    中国医药集团重庆医药设计院,重庆 400042

  • 基金项目:

  • 中图分类号: X703

Influence of different influent flow distribution ratios on biological nitrogen and carbon removal by multi-stages A/O process

  • 1.

    Key Laboratory of Three Reservior Region’s Eco-Enviroment,Ministry of Education,Chongqing University, Chongqing 400045, China

  • 2.

    Building Design and Research Institute of the General Logistics Department of the Chinese People’s Liberation Army, Beijing 100036, China

  • 3.

    Sinopharm Chongqing Pharmaceutical and Medical Industry Design Institute, Chongqing 400022, China

  • Fund Project:

  • 摘要: 采用三级A/O工艺分段进水工艺处理低碳源生活污水,考察了进水流量分配比对系统去除有机物、硝化反硝化能力以及去除TN的影响。通过对水质指标沿程监测结果表明,不同流量分配比(4∶3∶3,5∶3∶2,6∶3∶1)对系统去除有机物及硝化效率影响不大,出水COD、氨氮分别均在30 mg/L、1 mg/L以下。但反硝化效果受流量分配比的影响较大,在流量比为5∶3∶2时,有效利用原水中碳源进行反硝化,反硝化效果最好。在流量比为5∶3∶2的情况下,TN出水为5.7 mg/L去除率为82.9%,优于流量分配比为6∶3∶1和4∶3∶3时的脱氮效果。总体而言,分段进水工艺在对碳源的有效利用及能耗节省方面优于单点进水。
    Abstract: Three-stage step-feed A/O system was applied to treat sewage with low carbon source,experiments were carried out to investigate the effect of different influent flow distribution ratios on organic matter,nitrification and denitrification removal efficiency. It was showed that different flow distribution ratios (4∶3∶3, 5∶3∶2, 6∶3∶1) had a little effect on organic matter removal and nitrification efficiency, the effluent of COD,NH3-N were below 30 mg/L and 1 mg/L, respectively. But denitrification efficiency was considerably affected by the different flow distribution ratios. When flow distribution ratio was 5∶3∶2, carbon source of sewage was effective used, and the system achieved the optimum efficiency of denitrification. When flow distribution ratio was 5∶3∶2, the effluent TN was 5.7 mg/L with 82.9% removal efficiency,which was better than the flow distribution ratios of 6∶3∶1 and 4∶3∶3. In summary, the step-feed system is superior to single point feed system in the aspect of effective usage of carbon sources and energy saving.
  • 加载中
  • [1] Nadja Hvala,Mario Zec,Milenko Ros, et al. Design of a sequencing batch reactor sequence with an input load partition in an environment.Water Environment Research, 2001,73(3/4):146-154
    [2] Shigeo Fujii. The cretical analysis on nitrogen removal of the step-feed anoxic-oxic activated sludge process and its application for the optimal operation. Water Science and Technology, 1996,34(1/2):459-466
    [3] 邱慎初, 丁堂堂. 分段进水生物除磷脱氮工艺. 中国给水排水, 2003,19(4):32-36 Qiu Shenchu, Ding Tangtang. Step feed biological nutrient removal processes.China Water & Wastewater,2003,19(4):32-36(in Chinese)
    [4] 张胜, 竺建荣. 基于不同基质的强化生物除磷系统中生化反应机理研究进展. 环境污染与防治, 2007,29(7):533-536 Zhang Sheng, Zhu Jianrong. Based on different matrix enhanced biological phosphorus removal system of biochemical reaction mechanism. Environmental Pollution & Control, 2007,29(7):533-536(in Chinese)
    [5] 王荣斌,李军.污水生物除磷技术研究进展.环境工程,2007,25(1):84-88 Wang Rongbin, Li Jun. Progress of biological phosphorus removal technology.Environmental Engineering, 2007,25(1):84-88(in Chinese)
    [6] Olsson G., Nielsen M., Yuan Z., et al. Instrumentation, Control and Automation in Wastewater Systems. London:IWA Publishing, 2005
    [7] Zhu G. B.,Peng Y. Z.,Ma B., et al.Optimization of anoxic/oxic step feeding activated sludge process with fuzzy control model for improving nitrogen removal. Chemical Engineering Journal, 2009,151(1/3):195-201
    [8] Frigon J. C., Breton J., Bruneau T., et al. The treatment of cheese whey wastewater by sequential anaerobic and aerobic steps in a single digester at pilot scale. Bioresource Technology, 2009,100(18):4156-4163
    [9] 周健,张欣宇,干丽莎,等. 分段进水多级生物膜反应器脱氮效能影响因素研究. 环境工程学报, 2012,6(1):120-124 Zhou Jian, Zhang Xinyu, Gan Lisha,et al.Study on influencing factors of nitrogen removal by a step-feed multi-stage biofilm reactor. Chinese Journal of Environmental Engineering, 2012,6(1):120-124(in Chinese)
    [10] Johnson B. R., Goodwin S., Daigger G. T., et al. A comparison between the theory and reality of full-scale step-feed nutrient removal systems. Water Science and Technology, 2005,52(10-11):587-596
    [11] Gorgun E., Artan E.,Orhon D., et al. Evaluation of nitrogen removal by step feeding in large treatment plants. Water Science and Technology, 1996,34(1-2):253-260
    [12] 石凤,刘胜军,马炳勇,等.多段多级AO工艺在污水处理厂升级改造中的应用. 给水排水,2011,37(6):34-37 Shi Feng, Liu Shengjun,Ma Bingyong, et al. Application of multilevel A/O process in wastewater treatment plant upgrading and transformation. Water ＆ Wastewater Engineering, 2011,37(6):34-37(in Chinese)
    [13] Henze M., Harremoёs P. Characterisation of the wastewater: The effect of chemical precipetation on the wastewater composition and its consequences for biological denitrification. Chemical Water and Wastewater Treatment II, 1992.299-311
    [14] Third K. A., Burnett N., Cord Ruwisch C. Simultaneous nitrification and denitrification using stored substrate (PHB) as the electron donor in an SBR. Biotechnol. Bioeng., 2003,83(6):706-720
    [15] Pochana K., Keller J. Study of factors affecting simultaneous nitrification and denitrification (SND). Water Science and Technology, 1999,39(6):61-68
    [16] 王社平. 西安市第四污水厂水质分析及分段进水A/ O 生物脱氮工艺研究. 西安: 西安建筑科技大学博士学位论文, 2006 Wang Sheping. Xi’an fourth sewage plant influent water quality analysis and sub-A/O biological nitrogen removal process. Xi’an: Doctoral Dissertation of Xi’an University of Architecture and Technology, 2006(in Chinese)
    [17] Zhu G. B., Peng Y. Z., Wang S. Y., et al. Simultaneous nitrification and denitrification in step-feed biological nitrogen removal process. Chemical Engineering Journal, 2007,19(9):1043-1048
    [18] Puznava N., Payraudeau M., Thornberg D. Simultaneous nitrification and denitrification in biofilterswith real-time aeration control. Water Science and Technology, 2000,43(1):269-276
    [19] Tonkovic Z. Energetics of enhanced biological phosphorus and nitrogen removal processes. Water Science and Technology, 1998,38(1):177-184
    [20] Littleton H. X., Daigger G. T., Strom P. F., et al. Evaluation of autotrophic denitrification, heterotrophic nitrification,and PAOs in full scale simultaneous biological nutrient removal systems. Water Science and Technology, 2002,46(1/2):305-312
    [21] Kugleman I. J., Spector M., Harvilla A., et al. Aerobic denitrification in activated sludge//The 1991 Specialty Conference on Environmental Engineering, Reno, NV, USA, 1991.312-318
  • 加载中
