改性污泥活性炭对水中镉离子的吸附性能

,  ,  ,  ,

downloadPDF

上一篇

下一篇

何慧军, 杨春平, 罗胜联, 郑颖, 刘莉华. 改性污泥活性炭对水中镉离子的吸附性能[J]. 环境工程学报, 2012, 6(11): 4034-4040.
引用本文: 何慧军, 杨春平, 罗胜联, 郑颖, 刘莉华. 改性污泥活性炭对水中镉离子的吸附性能[J]. 环境工程学报, 2012, 6(11): 4034-4040.
shu
He Huijun, Yang Chunping, Luo Shenglian, Zheng Ying, Liu Lihua. Adsorption of Cd(Ⅱ) from aqueous solution by modified activated carbon made from activated sludge[J]. Chinese Journal of Environmental Engineering, 2012, 6(11): 4034-4040.
Citation: He Huijun, Yang Chunping, Luo Shenglian, Zheng Ying, Liu Lihua. Adsorption of Cd(Ⅱ) from aqueous solution by modified activated carbon made from activated sludge[J]. Chinese Journal of Environmental Engineering, 2012, 6(11): 4034-4040.
shu

改性污泥活性炭对水中镉离子的吸附性能

  • 1.

    南昌航空大学化学与环境工程学院, 南昌 330063

  • 2.

    浙江省固体废物处理与资源化重点实验室, 浙江工商大学环境科学与工程学院, 杭州 310018

  • 3.

    湖南大学环境科学与工程学院, 长沙 410082

  • 基金项目:

    国家自然科学基金资助项目(51278464)

  • 中图分类号: X703

Adsorption of Cd(Ⅱ) from aqueous solution by modified activated carbon made from activated sludge

  • 1.

    School of Environmental and Chemical Engineering, Nanchang Hangkong University, Nanchang 330063, China

  • 2.

    Zhejiang Provincial Key Laboratory of Solid Waste Treatment and Recycling, College of Environmental Science and Engineering, Zhejiang Gongshang University, Hangzhou 310018, China

  • 3.

    College of Environmental Science and Engineering, Hunan University, Changsha 410082, China

  • Fund Project:

  • 摘要: 以城市污水处理厂的剩余污泥为原料,氯化锌为活化剂制备污泥活性炭,对一部分污泥活性炭用6.0 mol/L的硝酸进行改性,并研究了未改性和改性的污泥活性炭对Cd2+的吸附行为的影响。结果表明,在pH为5.0、Cd2+初始浓度为100 mg/L、吸附剂投加量为2.0 g/L、反应温度为25℃时,未改性的污泥活性炭吸附容量为8.45 mg/g,硝酸改性的污泥活性炭吸附容量达到了23.35 mg/g。改性和未改性的污泥活性炭对Cd2+都有较好的吸附容量,硝酸改性大幅度提高了污泥活性炭对Cd2+的吸附性能。常温下改性污泥活性炭对Cd2+的吸附符合Langmuir吸附等温式。
    Abstract: Activated carbon was prepared from excessive sludge from municipal wastewater treatment plant, and zinc chloride was used as the activation reagent. The activated carbon from sludge was also treated using 6.0 mol/L nitric acid to prepare modified activated carbon. The performances of the two types of activated carbon for Cd2+ adsorption were compared. Results show that the adsorption capacity of the unmodified activated carbon and modified activated carbon was 8.45 and 23.35 mg of Cd2+ per g of activated carbon, respectively at a pH of 5.0, an initial concentration of Cd2+ of 100 mg/L, and a dosage of activated carbon of 2.0 g/L. Therefore, these two types of activated carbon had good adsorption capacities, and the modification by nitric acid greatly improved the adsorption performance for Cd2+. At room temperature, the adsorption of Cd2+ by the modified sludge activated carbon accords with the Langmuir equation pretty well.
  • 加载中
  • [1] 王远红, 张红波, 罗世田,等. 胞外聚合物对水中Cd(Ⅱ)的吸附性能研究. 环境工程学报,2010,4(10):2185-2189 Wang Y. H., Zhang H. B., Luo S.T., et al. Study on adsorption performances of Cd(Ⅱ) by extracellular biopolymer substabces.Chinese Journal of Environmental Engineering, 2010,4(10):2185-2189(in Chinese)
    [2] 于京华, 葛慎光, 戴平,等. 琉基葡聚糖分离富集催化动力学荧光猝灭法测定痕量镉.分析化学,2008,36(4):549-554 Yu J. H., Ge S. G., Dai P., et al. Determination of trace cadmium by catalytic kinetic fluorescent quenching method after preconcentration and separation by sulfhydryl dextrane gel. Chinese Journal Analytical Chemistry, 2008,36(4):549-554(in Chinese)
    [3] 谭浩强, 吴维, 刘志滨,等. 化学沉淀法去除水中镉的特性研究. 供水技术,2010,4(4):9-11 Tan H. Q., Wu W., Liu Z. B., et al. Features of removal cadmium by chemical precipitation method. Water Technology, 2010,4(4):9-11(in Chinese)
    [4] 游俏, 袁兴中, 曾光明,等. 腐熟污泥对废水中Cd(Ⅱ)与Zn(Ⅱ)的吸附性能研究. 环境工程学报,2011,5(1):1-6 You Q., Yuan X. Z., Zeng G. M., et al. Study on absorption of Cd(Ⅱ) and Zn(Ⅱ) from aqueous solution using composted sludge as absorbent. Chinese Journal of Environmental Engineering, 2011,5(1):1-6(in Chinese)
    [5] 代淑娟, 魏德洲, 白丽梅,等. 生物吸附-沉降法去除电镀废水中镉.中国有色金属学报,2008,18(10):1945-1950 Dai S. J., Wei D. Z., Bai L. M., et al. Removing cadmuim from cadmuim-containing electroplating wastewater by biosorption-sedimentation. The Chinese Journal of Nonferrous Metals, 2008,18(10):1945-1950(in Chinese)
    [6] 何义超, 刘云国, 樊霆,等. 棘孢曲霉(Aspergillus aculeatus)对Pb2+和Cd2+的吸附特征.环境工程学报,2010,4(1):137-141 He Y. C., Liu Y. G., Fan T., et al. Characters of Pb2+ and Cd2+ biosorption by Aspergillus aculeatus. Chinese Journal of Environmental Engineering, 2010,4(1):137-141(in Chinese)
    [7] Klimmek S., Stan H. J. Comparative analysis of the biosorption of cadmium,lead,nickel and zinc by algae. Environmental Science & Technology,2001,35(21):4283-4288
    [8] Wang J. L., Chen C. Biosorption of heavy metals removal and their future. Biotechnology Advances,2006,27(2):195-226
    [9] Yang C. P., Wang J. Q., Lei M., et al. Biosorption of zinc (Ⅱ) from aqueous solution by dried activated sludge. Journal of Environmental Sciences,2010,22(5):675-680
    [10] Calvo L. F., Otero M., Morán A., et al. Upgrading sewage sludges for adsorbent preparation by different treatments. Bioresource Technology,2001,80(2):143-148
    [11] Graham N., Chen X. G., Jayaseelan S. The potential application of activated carbon from sewage sludge to organic dyes removal. Water Science and Technology, 2001,43(2):245-252
    [12] Zhang F. S., Nriagua J. O., Itoh H. Mercury removal from water using activated carbons derived from organic sewage sludge. Water Research, 2005,39(2-3):389-395
    [13] 尹炳奎,朱石清,朱南文. 生物质活性炭的制备及其染料废水中的应用. 环境污染与防治,2006,28(8):608-611 Yin B. K., Zhu S. Q., Zhu N. W. Preparation of activated carbon from activated sludge and its application in treating dye wastewater. Environmental Pollution & Control, 2006,28(8):608-611(in Chinese)
    [14] Graham N., Chen X. G., Jayaseelan S. The potential application of activated carbon from sewage sludge to organic dyes removal. Water Science and Technology. 2001, 43(2): 245-252
    [15] 余兰兰, 钟 秦, 冯兰兰. 城市污水厂剩余污泥制备烟气脱硫吸附剂.化工进展, 2006,25(2):205-208 Yu L. L., Zhong Q., Feng L. L. Preparation of adsorbent of flue gas desulfurization from urban sewage surplus sludge. Chemical Industry and Engineering Progress, 2006,25(2):205-208(in Chinese)
    [16] 文青波, 李彩亭, 蔡志红,等. 污泥基活性炭吸附空气中甲醛的研究.中国环境科学, 2010,30(6):727-732 Wen Q. B., Li C. T., Cai Z. H., et al. Application of sewage sludge based activated carbon in formaldehyde adsorption. China Environmental Science, 2010,30(6):727-732(in Chinese)
    [17] 陈红燕, 羊依金, 谭显东,等. 软锰矿-污泥活性炭的制备及其对废水中铅离子的吸附. 环境工程学报,2010,4(11):2473-2478 Chen H. Y., Yang Y. J., Tan X. D., et al. Preparation of activated charcoal from pyrolusite-added sewage sludge and adsorption of lead ion in wastewater. Chinese Journal of Environmental Engineering, 2010,4(11):2473-2478(in Chinese)
    [18] 张德见,魏先勋,曾光明,等. 基于非线性拟合的污泥衍生吸附剂对铅离子等温吸附特性研究.离子交换与吸附,2004,20(1):1-6 Zhang D. J., Wei X. X., Zeng G. M., et al. The sorption isotherms of lead ion by sludge ramification adsorbent on the basis of non-linear fit. Ion Exchange and Adsorption, 2004,20(1):1-6(in Chinese)
    [19] Orozco A.M.F., Contreras E. M., Zaritzky N. E. Modelling Cr(Ⅵ) removal by a combined carbon-activated sludge system. Journal of Hazardous Materials, 2008,150(1):46-52
    [20] 刘守新,陈孝云,陈曦,等.表面酸碱2步改性对活性炭吸附Cr(Ⅵ)的影响.环境科学,2005,26(6):89-93 Liu S. X., Chen X. Y., Chen X., et al. Effect of acid-base two steps surface modification on the adsorption of Cr(Ⅵ) onto activated carbon. Environmental Science, 2005,26(6):89-93(in Chinese)
    [21] 范延臻, 王宝贞, 王琳,等. 改性活性炭的表面特性及其对金属离子的吸附性能.环境化学,2001,20(5):437-442 Fan Y. Z., Wang B. Z., Wang L., et al. Surface characteristics of modified activated carbons and its adsorption performance of heavy metal ions.Environmental Chemistry, 2001,20(5):437-442(in Chinese)
    [22] 余兰兰, 钟 秦. 活性炭污泥吸附剂的制备研究.环境化学, 2005,24(4):401-403 Yu L. L., Zhong Q. The research of preparation of activated carbon adsorbent made from sewage sludge. Environmental Chemistry, 2005,24(4):401-403(in Chinese)
    [23] King P., Rakesh N., Lahari B.S., et al. Biosorption of zinc onto Syzygium cumini L.: Equilibrium and kinetic studies. Chemical Engineering Journal,2008,144(2):181-187
    [24] Utkiger V., Bor-Yann C., Tabak H., et al. Treatment of acid mine drainage: I.Equilibrium biosorption of zinc and copper on non-viable activated sludge. International Biodeterioration and Biodegradation,2000,46(1):19-28
    [25] Mata Y. N., Blázquez M. L., Ballester A., et al. Biosorption of cadmium, lead and copper with calcium alginate xerogels and immobilized Fucus vesiculosus. Journal of Hazardous Materials, 2009,163(2-3):555-562
