活化赤泥的除氟性能

,

downloadPDF

上一篇

下一篇

杨利锦, 郭华明. 活化赤泥的除氟性能[J]. 环境工程学报, 2012, 6(11): 3981-3988.
引用本文: 杨利锦, 郭华明. 活化赤泥的除氟性能[J]. 环境工程学报, 2012, 6(11): 3981-3988.
shu
Yang Lijin, Guo Huaming. Adsorption characteristics of activated red mud for fluoride removal[J]. Chinese Journal of Environmental Engineering, 2012, 6(11): 3981-3988.
Citation: Yang Lijin, Guo Huaming. Adsorption characteristics of activated red mud for fluoride removal[J]. Chinese Journal of Environmental Engineering, 2012, 6(11): 3981-3988.
shu

活化赤泥的除氟性能

  • 1.

    中国地质大学生物地质和环境地质国家重点实验室,北京 100083

  • 2.

    中国地质大学(北京)水资源与环境学院,北京 100083

  • 基金项目:

    国家自然科学基金资助项目(41172224)

    国家"973"重点基础研究发展规划项目(2010CB428804)

    国家"水体污染控制与治理"科技重大专项(2009ZX07425-006)

  • 中图分类号: X703.5

Adsorption characteristics of activated red mud for fluoride removal

  • 1.

    State Key Laboratory of Biogeology and Environmental Geology, China University of Geosciences, Beijing 100083, China

  • 2.

    School of Water Resources and Environment, China University of Geosciences, Beijing 100083, China

  • Fund Project:

  • 摘要: 以成本低的铝工业废矿渣(赤泥)为原材料,通过高温煅烧和酸化处理对赤泥进行活化,制备了除氟吸附剂。研究了反应时间、投加量、初始氟浓度、溶液温度、共存阴离子和pH 值对活化赤泥除氟效果的影响。结果表明,接触反应时间为18 h时,吸附接近平衡。活化赤泥对氟离子的吸附符合Lagergren 二级吸附动力学方程。另外,初始浓度越高,吸附容量越大。与Freundlich相比,Langmuir 吸附等温模型可以更好地描述氟离子的吸附特性,最大吸附量可达2.71 mg/g。SO42-、Cl-和NO3-存在时(3-、PO43-和氟离子共存时,会对氟吸附造成不利影响。活化赤泥在pH 值3.5~11.0时,具有较好的吸附稳定性。活化赤泥是一种吸附容量高、性能稳定的环境友好型除氟材料,具有应用潜力。
    Abstract: Red mud, a waste tailing from alumina production, was activated with calcination and acid treatment for fluoride removal from water solution. Factors affecting fluoride adsorption on activated red mud were investigated, including reaction time, dosage of adsorbent, initial fluoride concentration, temperature, coexisting anions, and pH. Results showed that fluoride adsorption onto activated red mud generally achieved equilibrium at about 18 h. The kinetic data revealed that adsorption kinetics agreed well with the expression of Lagergren second-order rate. The higher the initial fluoride concentration, the greater the adsorption capacity was. The adsorption isotherm can be better described by Langmuir isotherm model, in comparison with Freundich isotherm model. Its maximum adsorption capacity was up to 2.71 mg/g. In addition, the coexistence of SO42-, Cl-, and NO3-(- adsorption. However, HCO3- and PO43- showed negative effects on fluoride removal. It demonstrated that fluoride adsorption was relatively independent on pH between 3.5 and 11.0. In summary, the activated red mud is an environmental-friendly fluoride adsorbent with high and stable adsorption capacity, which is of great advantage in practical application.
  • 加载中
  • [1] Fan X., Parker D. J., Smith M. D. Adsorption kinetics of fluoride on low cost materials. Water Research,2003, 37(20): 4929-4937
    [2] Ghorai S., Pant K. K. Investigations on the column performance of fluoride adsorption by activated alumina in a fixed-bed. Chemical Engineering Journal,2004, 98(1): 165-173
    [3] 娄金生,刘金香,刘海波.化学混凝沉淀-吸附法处理含氟废水研究.南华大学学报(自然科学版),2009, 23(4): 102-106 Low J.S., Liu J.X., Liu H.B. Treatment of fluoride wastewater by chemical coagulation and precipitation-adsorption. Nanhua University (Natural Science), 2009, 23(4): 102-106 (in Chinese)
    [4] Sujana M.G., Thakur R.S., Das S.N., et al. Defluorination of waste waters. Asian Journal of Chemistry,1997, 9(4): 561-570
    [5] Cengeloglu Y., Kir E., Ersoz M. Removal of fluoride from aqueous solution by using red mud. Separation and Purification Technology,2002, 28(1): 81-86
    [6] Tor A. Removal of fluoride from an aqueous solution by using montmorillonite. Desalination,2006, 201(1-3): 267-276
    [7] Meenakshi S, Viswanathan N. Identification of selective ion-exchange resin for fluoride sorption. Journal of Colloid and Interface Science,2007, 308(2): 438-450
    [8] Sourirajan S., Matsurra T. Studies on reverse osmosis for water pollution control. Water Research, 1972, 6(9): 1073-1086
    [9] Simons R. Trace-element removal from ash dam waters by nanofiltration and diffusion dialysis. Desalination,1993, 89(3): 325-341
    [10] Guo L., Hunt B.J., Santsci P.H. Ultrafiltration behavior of major ions (Na, Ca, Mg, F, Cl, and SO4) in natural waters. Water Research,2001, 35(6): 1500-1508
    [11] 陈方明, 陆琦. 方解石水质净化剂的制备及其除氟研究. 环境工程学报,2007, 1(9): 30-34 Chen F.M., Lu Q. Preparation of water purifying agent from analcite rocks and study on its fluorine removal. Chinese Journal of Environmental Engineering,2007, 1(9): 30-34 (in Chinese)
    [12] 沈振华, 张玉先. 改性沸石用于饮用水除氟的试验研究. 工业安全与环保,2006, 32(3): 14-16 Shen Z.H., Zhang Y.X. A experimental study on fluoride removal of drinking water by modified zeolite. Industrial Safety and Environmental Protection,2006, 32(3): 14-16 (in Chinese)
    [13] 单悦, 郭华明, 刘琼. 不同铝盐改性人工合成菱铁矿除氟性能研究. 安全与环境工程,2011, 18(3): 22-27 Shan Y., Guo H.M., Liu Q. Fluoride removal by synthetic siderite modified by different aluminum chemicals. Safety and Environmental Engineering,2011, 18(3): 22-27 (in Chinese)
    [14] Tokumitsu T., Sato K., Toda K., et al. Removal of fluoride from aqueous solution by ettringite. Journal of the Ceramic Society of Japan,2006, 114(1332): 729-732
    [15] 姚万军, 方冰. 拜耳法赤泥综合利用研究现状. 无机盐工业,2010, 42(12): 32-34 Yao W.J., Fang B. Present research status of comprehensive utilization of red mud from Bayer process. Inorganic Chemicals Industry,2010, 42(12): 32-34 (in Chinese)
    [16] 何伯泉, 周国华, 薛玉兰. 赤泥在环境保护中的应用. 轻金属,2001, (2): 24-26 He B.Q., Zhou G.H., Xue Y.L. The applications of red mud in environmental protection. Light Metals,2001, (2): 24-26 (in Chinese)
    [17] 任冬梅, 毛亚南. 赤泥的综合利用. 有色金属工业,2002, (5): 58-59 Ren D.M., Mao Y.N. Comprehensive utilization of red mud. China Nonferrous Metals Industry,2002, (5): 58-59 (in Chinese)
    [18] 魏宁,栾兆坤,王军,等. 铝改性赤泥吸附剂的制备及其除氟效能的研究.无机化学学报,2009, 25(5): 849-854 Wei N., Luan Z.K., Wang J., et al. Preparation of modified red mud with aluminum and its adsorption characteristics on fluoride removal. Chinese Journal of Inorganic Chemistry,2009, 25(5): 849-854 (in Chinese)
    [19] Gupta V.K., Sharma S. Removal of cadmium and zinc from aqueous solutions using red mud. Environmental Science & Technology,2002, 36(16): 3612-3617
    [20] Zhu C.L., Luan Z.K., Wang Y.Q., et al. Removal of cadmium from aqueous solutions by adsorption on granular red mud (GRM). Separation and Purification Technology,2007, 57(1): 161-169
    [21] 李燕中,刘昌俊,栾兆坤,等. 活化赤泥吸附除磷及其机理的研究. 环境科学学报,2006,26(11): 1775-1779 Li Y.Z., Liu C.J., Luan Z.K., et al. Phosphate removal from aqueous solutions using activated red mud. Acta Scientiae Circumstantiae,2006, 26(11): 1775-1779 (in Chinese)
    [22] Pradhan J., Das J., Das S., et al. Adsorption of phosphate from aqueous solution using activated red mud. Journal of Colloid and Interface Science,1998, 204(1): 169-172
    [23] Genc-Fuhrman H., Bregnhoj H., McConchie D. Arsenate removal from water using sand-red mud columns. Water Research,2005, 39(13): 2944-2954
    [24] 郭华明,刘琼. 改性铁锰结核对水中氟离子的吸附作用研究.安全与环境学报,2008,8(2): 26-30 Guo H.M., Liu Q. Adsorption of fluoride ions in aqueous environment by the modified manganese-iron nodules. Journal of Safety and Environment,2008, 8(2): 26-30 (in Chinese)
    [25] Srimurali M., Pragathi A., Karthikeyan J. A study on removal of fluoride from drinking water by adsorption onto low cost materials. Environmental Pollution,1998, 99(2): 285-289
    [26] 王静. Mg/Al 复合氧化物对水中阴离子型染料吸附性能研究. 济南: 山东大学硕士学位论文, 2007 Wang J. Adsorption of anionic dye with magnesium-aluminum composite oxides. Jinan: Master Dissertation of Shangdong University, 2007 (in Chinese)
    [27] 杜建云, 庄源益, 谷文新. 含铜氧化铝对煤油中硫醇的吸附特性. 南开大学学报(自然科学版),2003, 36(3): 26-31 Du J.Y., Zhuang Y.Y., Gu W.X. Adsorption of mercaptan in kerosene on copper contaiming alumina. Acta Scientiarum Naturalium Universitatis Nakaiensis (Natural Science),2003, 36(3): 26-31 (in Chinese)
    [28] 王学松, 胡海琼, 王静, 等. 钠型丝光沸石吸附水溶液中铜离子平衡及动力学研究. 科技导报,2006, 24 (11): 31-36 Wang X.S., Hu H.Q., Wang J., et al. Adsorption of copper ions from aqueous solution by Na-mordenite: equilibrium and kinetic studies. Science & Technology Review,2006, 24(11): 31-36 (in Chinese)
    [29] 刘琼,郭华明. 活化铁锰结核的除氟性能研究.环境科学,2009, 30(8): 2263-2270 Liu Q., Guo H.M. Characteristics of fluoride removal by activated iron-manganese nodules. Environmental Science,2009, 30(8): 2263-2270(in Chinese)
    [30] Guo H.M., Stuben D., Berner Z. Removal of arsenic from aqueous solution by natural siderite and hematite. Applied Geochemistry,2007, 22(5): 1039-1051
    [31] Altundogan H.S., Altundogan S., Tumen F., et al. Arsenic removal from aqueous solutions by adsorption on red mud. Waste Manage,2000, 20(8): 761-767
    [32] 周少丽, 贺燕. 铬在黄腐酸上吸附行为及机理的研究. 有色矿冶,2007, 23(6): 46-48 Zhou S.L., He Y. Study the adsorption behavior and mechanism of chromium on fulvic acid. Non-Ferrous Mining and Metallurgy,2007, 23(6): 46-48 (in Chinese)
    [33] Genc-Fuhrman H., Tjell J.C., McConchie D. Adsorption of arsenic from water using activated neutralized red mud. Environmental Science & Technology,2004, 38(8): 2428-2434
    [34] Gupta V.K., Ali I., Saino V.K. Defluoridation of wastewaters using waste carbon slurry. Water Research,2007, 41(15): 3307-3316
    [35] Kamble S.P., Jagtap S., Labhsetwar N.K., et al. Defluoridation of drinking water using chitin, chitosan and lanthanum modified chitosan. Chemical Engineering Journal,2007, 129(1-3): 173-180
    [36] Calace N., Nardi E., Petronio B.M., et al. Adsorption of phenols by papermill sludges. Environmental Pollution,2002, 118 (3): 315-319
    [37] 赵振国. 吸附作用应用原理. 北京: 化学工业出版社, 2005
