投加ABS颗粒对MBR膜过滤特性的影响

,  ,  ,  ,

downloadPDF

上一篇

下一篇

尤朝阳, 刘汤勋, 刘志寅, 张丹, 肖晓强. 投加ABS颗粒对MBR膜过滤特性的影响[J]. 环境工程学报, 2012, 6(10): 3383-3387.
引用本文: 尤朝阳, 刘汤勋, 刘志寅, 张丹, 肖晓强. 投加ABS颗粒对MBR膜过滤特性的影响[J]. 环境工程学报, 2012, 6(10): 3383-3387.
shu
You Zhaoyang, Liu Tangxun, Liu Zhiyin, Zhang Dan, Xiao Xiaoqiang. Effect of feeding ABS particles into membrane bioreactor on membrane filtration performance[J]. Chinese Journal of Environmental Engineering, 2012, 6(10): 3383-3387.
Citation: You Zhaoyang, Liu Tangxun, Liu Zhiyin, Zhang Dan, Xiao Xiaoqiang. Effect of feeding ABS particles into membrane bioreactor on membrane filtration performance[J]. Chinese Journal of Environmental Engineering, 2012, 6(10): 3383-3387.
shu

投加ABS颗粒对MBR膜过滤特性的影响

  • 1.

    南京工业大学环境学院, 江苏省工业节水减排重点实验室, 南京 210009

  • 基金项目:

    江苏省基础研究计划(自然科学基金)资助项目(BK2008380)

  • 中图分类号: X703

Effect of feeding ABS particles into membrane bioreactor on membrane filtration performance

  • Fund Project:

  • 摘要: 向膜生物反应器(MBR)中投加ABS颗粒,以干扰膜表面泥饼层的形成和减轻膜污染的发生。结果表明,向MBR中投加粒径为1 mm的ABS颗粒,发现颗粒的最佳投加量为1.5 kg/m3,投加颗粒的膜运行时间是对照实验运行时间的3倍。颗粒对膜表面泥饼沉积层抑制明显,与对照实验泥饼层重量最大相差290 g,颗粒使膜上泥饼层的分布也不同。颗粒的投加也改变了污泥EPS含量,相比对照实验,多糖、蛋白质含量分别提高了17.2%和8%,污泥粘度提高了17.6%。细格栅与颗粒使MBR对TN、TP去除效果分别提高了8.5%和9.7%,对COD的影响不大。
    Abstract: ABS was fed into MBR to disturb the formation of cake layers on membrane surfaces and to reduce membranes fouling effect.The result indicated that the optimized feed rate is 1.5 kg/m3,when using 1 mm diameter ABS particles.The MBR operating time achieves three times of the contrast test.Feeding ABS particles could effectively suppress the sludge cake layer formation rate on membrane surfaces,whose largest weight difference between the ABS feeding test and contrast test is 290 g,with a different content distribution between these two results.As ABS particles fed into MBR,the EPS concentration in sludge was also impacted.Comparing to the contrast test,the concentration of polysaccharide and protein increased by 17.2% and 8%,respectively.Sludge viscosity increased by 17.6%.The removal rates of TN and TP increased by 9.7% and 8.5%,respectively as the fine grid and particles were added into MBR.However.The results indicating fairly small influence on COD.
  • 加载中
  • [1] 张海丰,孙宝盛,赵新华,等.三氯化铁混凝作用提高膜生物反应器混合液可滤性.天津大学学报,2008,41(2):131-136 Zhang Haifen,Su Baosheng,Zhao Xinhua,et al.Improvement of filterability of mixed liquor in membrane bioreactor by coagulation of ferric chloride.Journal of Tianjin University,2008,41(2):131-136(in Chinese)
    [2] Wu Jingling,Chen Futai.Using inorganic coagulants to control membrane fouling in a submerged membrane bioreactor.Desalination,2006,197(1-3):124-136
    [3] 肖恩荣,梁威.膜生物反应器稳定运行的操作条件优化研究.中国给水排水,2007,23(5):26-28 Xiao Enrong,Liang Wei.Study on optimization of operational condition of membrane bioreactor.China Water & Wastewater,2007,23(5):26-28(in Chinese)
    [4] 张传义,王勇,黄霞,等.一体式膜-生物反应器经济曝气量的试验研究.膜科学与技术,2004,24(5):11-15 Zhang Chuanyi,Wang Yong,Huang Xia,et al.Experimental study on economical aeration intensity in a submerged membrane bioreactor.Membrane Science and Technology,2004,24(5):11-15(in Chinese)
    [5] 李照静,张玉先,范建伟,等.纳米TIO2改性膜生物反应器处理污水的研究.中国给水排水,2008,24(3):75-78 Li Zhaojin,Zhang Yuxian,Fan Jianwei,et al.Study on MBR modified by nanometer TiO2 for wastewater treatment.China Water & Wastewater,2008,24(3):75-78(in Chinese)
    [6] Stefan Krause,学贤,董正军,等.颗粒物质控制膜污染的增强型膜生物反应器工艺的研究.膜科学与技术,2010,30(2):74-78 Stefan Krause,Xue Xian,Dong Xuejun,et al.Enhanced MBR-process using added granulates for fouling control.Membrane Science and Technology,2010,30(2):74-78(in Chinese)
    [7] 晏再生,王世和.橡胶粒投量对MBBF-MBR膜过滤特性的影响.中国给水排水,2009,25(19):58-61 Yan Zaishen,Wang Shihe.Effect of rubber granules dosage on membrane filtration characteristics in moving bed biofilm/membrane bioreactor.China Water & Wastewater,2009,25(19):58-61(in Chinese)
    [8] Siembida B.,Cornel P.,Krause S.,et al.Effect of mechanical cleaning with granular material on the permeability of submerged membranes in the MBR process.Water Research,2010,44(14):4037-4046
    [9] 马金霞,王世和,沈倩宇.投加颗粒活性炭对膜生物反应器过滤特性的影响.中国给水排水,2010,26(3):87-89 Ma Jinxia,Wang Shihe,Shen Qianyu.Effects of granular activated carbon addition on MBR filtration performance.China Water & Wastewater,2010,26(3):87-89(in Chinese)
    [10] 封莉,张立秋.膜堵塞机理研究与膜阻力测定.环境工程,2002,20(3):75-77 Fen Li,Zhang Liqiu.Study on membrane fouling mechanisms and measuring of membrane resistance.Environmental Engineering,2002,20(3):75-77(in Chinese)
    [11] 刘玉君,丁忠伟,刘丽英,等.浸没式中空纤维膜污染控制措施比较.北京化工大学学报(自然科学版),2010,37(1):19-22 Liu Yujun,Ding Zhongwei,Liu Liyin,et al.A comparison of several hydrodynamic methods for alleviating fouling in submerged hollow fiber membrane filtration.Journal of Beijing University of Chemical Technology (Natural Science Edition),2010,37(1):19-22(in Chinese)
    [12] 李绍峰,崔崇威,刘玉强,等.MBR膜污染阻力及清洗效果研究.安全与环境学报,2006,6(2):9-12 Li Shaofen,Cui Chongwei,Liu Yuqiang,et al.Resistance and cleaning effect of MBR membrane fouling.Journal of Safety and Environment,2006,6(2):9-12(in Chinese)
    [13] Wu Jinling,Huang Xia.Effect of mixed liquor properties on fouling propensity in membrane bioreactors.Journal of Membrane Science,2009,342(1-2):88-96
    [14] 焦娜,张永刚.胞外聚合物及其对膜污染影响的研究进展.天津工业大学学报,2010,29(3):24-28 Jiao Na,Zhang Yong gang.Study progress of extracellular polymeric substances and effects of EPS on membrane fouling.Journal of Tianjin Polytechnic University,2010,29(3):24-28(in Chinese)
    [15] 秦亚敏,李亚峰.胞外聚合物对膜污染的影响及对策.工业用水与废水,2010,41(1):1-5 Qing Yaming,Li Yafeng.Influence of EPS on membrane fouling and countermeasures thereof.Industrial Water & Wasterwater,2010,41(1):1-5(in Chinese)
