P204-熔融石蜡固液萃取废水中铜、钴、镍

,  ,  ,  ,

downloadPDF

上一篇

下一篇

万建新, 任学昌, 蒋煜峰, 郭效军, 彭波. P204-熔融石蜡固液萃取废水中铜、钴、镍[J]. 环境化学, 2018, 37(12): 2688-2693. doi: 10.7524/j.issn.0254-6108.2018082001
引用本文: 万建新, 任学昌, 蒋煜峰, 郭效军, 彭波. P204-熔融石蜡固液萃取废水中铜、钴、镍[J]. 环境化学, 2018, 37(12): 2688-2693. doi: 10.7524/j.issn.0254-6108.2018082001
shu
WAN Jianxin, REN Xuechang, JIANG Yufeng, GUO Xiaojun, PENG Bo. Solid-liquid extraction of nickel, cobalt and copper waste water using P204 in molten paraffin wax[J]. Environmental Chemistry, 2018, 37(12): 2688-2693. doi: 10.7524/j.issn.0254-6108.2018082001
Citation: WAN Jianxin, REN Xuechang, JIANG Yufeng, GUO Xiaojun, PENG Bo. Solid-liquid extraction of nickel, cobalt and copper waste water using P204 in molten paraffin wax[J]. Environmental Chemistry, 2018, 37(12): 2688-2693. doi: 10.7524/j.issn.0254-6108.2018082001
shu

P204-熔融石蜡固液萃取废水中铜、钴、镍

  • 1.

    兰州交通大学环境与市政工程学院, 兰州, 730070;

  • 2.

    西北师范大学化学化工学院, 兰州, 730070

  • 基金项目:

    国家自然科学基金（51268026，51068016）资助.

Solid-liquid extraction of nickel, cobalt and copper waste water using P204 in molten paraffin wax

  • 1.

    School of Environmental & Municipal Engineering, Lanzhou Jiaotong University, Lanzhou, 730070, China;

  • 2.

    College of Chemistry and Chemical Engineering, Northwest Normal University, Lanzhou, 730070, China

  • Fund Project: Supported by the National Natural Science Foundation of China (51268026, 51068016).

  • 摘要: 本文研究了二-（2-乙基己基）磷酸（P204）-熔融石蜡对废水中Cu2+、Co2+、Ni2+的固液萃取行为.探讨了水相的酸度、萃取剂P204用量及搅拌时间等对废水中Cu2+、Co2+、Ni2+的萃取率的影响.结果表明，当pH=2.5时，Cu2+萃取率几乎达到100%，远高于Co2+和Ni2+；当P204用量为0.05 mL时，水相中Co2+不被萃取，Cu2+和Ni2+萃取率不到60%；当搅拌时间为3 min时，Ni2+萃取达到平衡，萃取完全，Cu2+和Co2+萃取平衡时间需要7 min.用斜率法确定其萃取机理，测定并计算出表观萃取平衡常数Kex和相关热力学参数.
    Abstract: In this paper, solid-liquid extraction of nickel, cobalt and copper ions in waste water with di-2-ethylhexyl phosphoric acid (P204) in molten paraffin waxes was investigated. The effects of agitation time, P204 dosage, and pH on the extraction rate were evaluated. The results showed that the extraction rate of copper ion was up to 100% at pH 2.5, and it was much higher than that of cobalt and nickel ions in waste water. When P204 dosage was 0.05 mL, the extraction rate of copper and nickel ions was less than 60%. However, the cobalt ion could not be extracted under this condition. For extraction time, nickel ion was extracted completely with 3 minutes stirring, while copper and cobalt ions needed 7 minutes to reach extraction equilibrium. The stoichiometry of the extracted species was determined on the basis of slope analysis method. Extraction equilibrium constant and thermodynamic data were also calculated and discussed.
  • 加载中
  • [1] 谌可颂. 从废弃炉渣中回收钴、镍、铜的研究[J]. 湖南有色金属,2006,22(6):24-28.

    CHEN K S. Study on separating and recovering cobalt、nickel and copper from waste slag[J]. Hunan Nonferrous Metals, 2006,22(6):24-28(in Chinese).

    [2] HUANG Y, ZHOU C S. Hydrometallurgical process for recovery of cobalt from zinc plant residue[J]. Hydrometallurgy, 2002,63(3):225-234.
    [3] 唐娜娜,马少健. 废弃物料中钴、镍的回收[J]. 有色矿冶, 2005, 21(s1):119-120.

    TANG N N, MA S J. Recovering cobalt and nickel from waste materials[J]. Non-Ferrous Mining and Metallurcy, 2005, 21(s1):119-120(in Chinese).

    [4]
    [5] 王正达,马鲁铭,朱萍,等.新铜萃取剂萃取盐酸介质中铜的实验研究[J]. 稀有金属,2005, 29(6):944-947.

    WANG Z D, MA L M, ZHU P, et al. Solvent extraction of copper from hydrochloric acid media using new extractant[J]. Chinese Journal of Rare Metals, 2005, 29(6):944-947(in Chinese).

    [6] JOHNSTON B E. Commerical application of phosphorus-based solvent extraction[J]. Chem Ind, 1988, 20:656-660.
    [7] PENG B, FAN H Y, GAO J Z. Solid-liquid solvent extraction of metal ions[J]. International Journal of Minerals, Metallurgy, and Materials, 2003, 10(1):1-7.
    [8] PENG B, WAN J X, LI X M, et al. Separation and recovery of cadmium from acidic leach liquors of Spent Ni-Cd batteries using molten paraffin wax solvent extraction[J]. Separation Science and Technology,2012, 47(8):1259-1260.
    [9] 万益群,郭岚,戴超. 石蜡相光度法测定痕量钯[J]. 分析化学,2000, 28(5):606-608.

    WAN Y Q, GUO L, DAI C. Determination of trace palladium by paraffin phase spectrophotometry[J]. Chinese Journal of Analytical Chemistry, 2000, 28(5):606-608(in Chinese).

    [10] 陆九芳,李总成,包铁竹. 分离过程化学[M]. 北京:清华大学出版社,1993:85-87. LU J F, LI Z C, BAO T Z. Separation process chemistry[M]. Beijing:Tsinghua University Press, 1993:85

    -87(in Chinese).

    [11] 万益群,龚涛. 石蜡相光度法测定矿石中的痕量金[J]. 分析化学,2000, 28(12):1563-1565.

    WAN Y Q, GONG T. Determination of trace gold in ores by paraffin phase spectrophotometry[J]. Chinese Journal of Analytical Chemistry, 2000, 28:1563-1565(in Chinese).

    [12] 喻正军. 从镍转炉渣中回收钴镍铜的理论与技术研究[D]. 长沙:中南大学, 2007. YU Z J. The study of theory and technology of recovey of Co, Ni and Cu from nickel converter slag[D]. Changsha:Central South University, 2007(in Chinese).
    [13] 高锦章,郭效军,王碧,等. 高温熔融固液萃取在分离与富集中的应用[J]. 稀有金属,1999, 23(4):304-308.

    GAO J Z, GUO X J, WANG B, et al.Application of high-temperature melten solid-liquid extraction in separation and concentration[J]. Chinese Journal of Rare Metals, 1999, 23(4):304-308(in Chinese).

    [14]
    [15] PENG B, GUO X J, MAO X F, et al. Molten solvent extraction behavior of palladium with 1-phenyl-3-methyl-4-benzoyl-5-pyrazolone at 60℃[J]. Central European Journal of Chemistry,2007, 5(3):916-921.
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1799
  • HTML全文浏览数:  1772
  • PDF下载数:  48
  • 施引文献:  0
出版历程
  • 收稿日期:  2018-08-20
  • 刊出日期:  2018-12-15
万建新, 任学昌, 蒋煜峰, 郭效军, 彭波. P204-熔融石蜡固液萃取废水中铜、钴、镍[J]. 环境化学, 2018, 37(12): 2688-2693. doi: 10.7524/j.issn.0254-6108.2018082001
引用本文: 万建新, 任学昌, 蒋煜峰, 郭效军, 彭波. P204-熔融石蜡固液萃取废水中铜、钴、镍[J]. 环境化学, 2018, 37(12): 2688-2693. doi: 10.7524/j.issn.0254-6108.2018082001
shu
WAN Jianxin, REN Xuechang, JIANG Yufeng, GUO Xiaojun, PENG Bo. Solid-liquid extraction of nickel, cobalt and copper waste water using P204 in molten paraffin wax[J]. Environmental Chemistry, 2018, 37(12): 2688-2693. doi: 10.7524/j.issn.0254-6108.2018082001
Citation: WAN Jianxin, REN Xuechang, JIANG Yufeng, GUO Xiaojun, PENG Bo. Solid-liquid extraction of nickel, cobalt and copper waste water using P204 in molten paraffin wax[J]. Environmental Chemistry, 2018, 37(12): 2688-2693. doi: 10.7524/j.issn.0254-6108.2018082001
shu

P204-熔融石蜡固液萃取废水中铜、钴、镍

  • 1.  兰州交通大学环境与市政工程学院, 兰州, 730070;
  • 2.  西北师范大学化学化工学院, 兰州, 730070
  • 收稿日期:  2018-08-20
基金项目:

国家自然科学基金（51268026，51068016）资助.

摘要: 本文研究了二-（2-乙基己基）磷酸（P204）-熔融石蜡对废水中Cu2+、Co2+、Ni2+的固液萃取行为.探讨了水相的酸度、萃取剂P204用量及搅拌时间等对废水中Cu2+、Co2+、Ni2+的萃取率的影响.结果表明，当pH=2.5时，Cu2+萃取率几乎达到100%，远高于Co2+和Ni2+；当P204用量为0.05 mL时，水相中Co2+不被萃取，Cu2+和Ni2+萃取率不到60%；当搅拌时间为3 min时，Ni2+萃取达到平衡，萃取完全，Cu2+和Co2+萃取平衡时间需要7 min.用斜率法确定其萃取机理，测定并计算出表观萃取平衡常数Kex和相关热力学参数.
