氧氟沙星和诺氟沙星在磷酸改性生物炭上的等温吸附行为

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

储刚, 赵婧, 刘洋, 吴敏, 周丹丹, 李燕燕. 氧氟沙星和诺氟沙星在磷酸改性生物炭上的等温吸附行为[J]. 环境化学, 2018, 37(3): 462-470. doi: 10.7524/j.issn.0254-6108.2017090403
引用本文: 储刚, 赵婧, 刘洋, 吴敏, 周丹丹, 李燕燕. 氧氟沙星和诺氟沙星在磷酸改性生物炭上的等温吸附行为[J]. 环境化学, 2018, 37(3): 462-470. doi: 10.7524/j.issn.0254-6108.2017090403
shu
CHU Gang, ZHAO Jing, LIU Yang, WU Min, ZHOU Dandan, LI Yanyan. Sorption of ofloxacin and norfloxacin on modified biochars using phosphoric acid treatment[J]. Environmental Chemistry, 2018, 37(3): 462-470. doi: 10.7524/j.issn.0254-6108.2017090403
Citation: CHU Gang, ZHAO Jing, LIU Yang, WU Min, ZHOU Dandan, LI Yanyan. Sorption of ofloxacin and norfloxacin on modified biochars using phosphoric acid treatment[J]. Environmental Chemistry, 2018, 37(3): 462-470. doi: 10.7524/j.issn.0254-6108.2017090403
shu

氧氟沙星和诺氟沙星在磷酸改性生物炭上的等温吸附行为

  • 1.

    昆明理工大学环境科学与工程学院, 昆明, 650500

  • 基金项目:

    国家自然科学基金（41473116）和昆明理工大学校级人才培养项目（KKZ3201422028）资助.

Sorption of ofloxacin and norfloxacin on modified biochars using phosphoric acid treatment

  • 1.

    Faculty of Environmental Science and Engineering, Kunming University of Science and Technology, Kunming, 650500, China

  • Fund Project: Supported by the National Natural Science Foundation of China (41473116) and Talents Training Program of Kunming University of Science and Technology(KKZ3201422028).

  • 摘要: 本研究考察了不同制备温度下（200℃、350℃、500℃、650℃），磷酸改性前后生物炭的理化性质，及其对氧氟沙星（OFL）和诺氟沙星（NOR）的等温吸附行为.采用N2物理吸附、扫描电镜、热重及元素分析等表征，对离子型抗生素在磷酸改性的生物炭上的等温吸附行为进行了研究.结果表明，随着制备温度的增加，改性生物炭的总孔体积不断增大，孔隙结构广泛形成，比表面积急剧增加.磷酸改性有助于提高生物炭的产率以及保留生物炭的极性官能团.OFL和NOR在改性生物炭上的吸附显著高于原始生物炭，且350℃下制备的改性生物炭具有最大吸附量，其吸附机制归因于吸附剂的大比表面积和孔隙填充作用.由于孔隙的利用率降低和炭的疏水性增强，OFL和NOR在更高温度改性生物炭上的吸附量逐渐降低.因此，在处理以上两种污染物时，350℃可作为磷酸改性生物炭的最佳裂解温度，且有利于减少能耗，节约资源.
    Abstract: Physi-chemical properties of pine sawdust biochars modified by phosphoric acid at various pyrolysis temperatures (200℃, 350℃, 500℃, 650℃), and the sorption of ofloxacin (OFL) and norfloxacin (NOR) on the pristine and modified biochars were investigated. The sorption of ionic antibiotics on the modified biochars was analysed by using N2 adsorption, scanning electron microscopy, thermogravimetry and elemental analysis. The results showed that the total pore volume and specific surface area of the modified biochars increased sharply with increasing pyrolytic temperature, and microscale porous structure was abundant. The phosphoric acid treatment improved the yield and conserved the polar functional groups of biochars. As a result, the sorption of OFL and NOR on the modified biochars was much higher than that on normal biochars. Modified biochars prepared at 350℃ had the highest sorption capacity. The sorption mechanisms of these two antibiotics might be attributed to large specific surface area and pore-filling. The sorption of OFL and NOR on the modified biochars produced at higher temperatures decreased gradually due to the reduction in porosity utilization and increase in the hydrophobicity of the mofified biochars. To deal with these two contaminants, 350℃ can be selected as an optimum pyrolysis temperature for the preparation of modified biochars.
  • 加载中
  • [1] BROWN K D, KULIS J, THOMSON B, et al. Occurrence of antibiotics in hospital, residential, and dairy effluent, municipal wastewater, and the Rio Grande in New Mexico[J]. Science of the Total Environment, 2006, 366(2/3):772-783.
    [2] LUO Y, XU L, RYSZ M, et al. Occurrence and transport of tetracycline, sulfonamide, quinolone, and macrolide antibiotics in the Haihe River Basin, China[J]. Environmental Science & Technology, 2016, 45(5):1827-1833.
    [3] XU W, ZHANG G, LI X, et al. Occurrence and elimination of antibiotics at four sewage treatment plants in the Pearl River Delta (PRD), South China[J]. Water Research, 2007, 41(19):4526-4534.
    [4] GULLBERG E, SHA C, BERG O G, et al. Selection of resistant bacteria at very low antibiotic concentrations[J]. Plos Pathogens, 2011, 7(7):e1002158.
    [5] SEGURA P A, FRANCOIS M, GAGNON C, et al. Review of the occurrence of anti-infectives in contaminated wastewaters and natural and drinking waters[J]. Environmental Health Perspectives, 2009, 117(5):675-684.
    [6] 尉小旋,陈景文,王如冰,等. 氧氟沙星和诺氟沙星的水环境光化学转化:pH值及溶解性物质的影响[J]. 环境化学, 2015,34(3):448-454.

    WEI X X, CHEN J W, WANG R B, et al. Aquatic photochemical transformation of ofloxacin and norfloxacin:Effects of pH and water constituents[J]. Environmental Chemistry, 2015,34(3):448-454(in Chinese).

    [7] YIRUHAN, WANG Q J, MO C H, et al. Determination of four fluoroquinolone antibiotics in tap water in Guangzhou and Macao[J]. Environmental Pollution, 2010, 158(7):2350-2358.
    [8] CHU G, ZHAO J, CHEN F Y, et al. Physi-chemical and sorption properties of biochars prepared from peanut shell using thermal pyrolysis and microwave irradiation[J]. Environmental Pollution, 2017, 227:372-379.
    [9] XIAO X, CHEN B L. A direct observation of the fine aromatic clusters and molecular structures of biochars[J]. Environmental Science & Technology, 2017, 51:5473-5482.
    [10] BEESLEY L, MORENO-JIMENEZ E, GOMEZ-EYLES J L, et al. A review of biochars' potential role in the remediation, revegetation and restoration of contaminated soils[J]. Environmental Pollution, 2011, 159(12):3269-3282.
    [11] AZARGOHAR R, DALAI A K. Steam and KOH activation of biochar:Experimental and modeling studies[J]. Microporous & Mesoporous Materials, 2008, 110(2-3):413-421.
    [12] TAHA S M, AMER M E, ELMARSAFY A E, et al. Adsorption of 15 different pesticides on untreated and phosphoric acid treated biochar and charcoal from water[J]. Journal of Environmental Chemical Engineering, 2014, 2(4):2013-2025.
    [13] JAGTOYEN M, DERBYSHIRE F. Activated carbons from yellow poplar and white oak by H3PO4, activation[J]. Carbon, 1998, 36(7-8):1085-1097.
    [14] GUO Y, ROCKSTRAW D A. Physical and chemical properties of carbons synthesized from xylan, cellulose, and Kraft lignin by H3PO4, activation[J]. Carbon, 2006, 44(8):1464-1475.
    [15] ZHAO L, CAO X, ZHENG W, et al. Phosphorus-assisted biomass thermal conversion:Reducing carbon loss and improving biochar stability[J]. Plos One, 2014, 9(12):e115373.
    [16] PENG H B, PAN B, WU M, et al. Adsorption of ofloxacin and norfloxacin on carbon nanotubes:Hydrophobicity- and structure-controlled process[J]. Journal of Hazardous Materials, 2012, 233-234(3):89-96.
    [17] SIGMUND G, HUFFER T, HOFMANN T, et al. Biochar total surface area and total pore volume determined by N2 and CO2 physisorption are strongly influenced by degassing temperature[J]. Science of the Total Environment, 2016, 580:770-775.
    [18] CHEN Z M, CHEN B L, CHIOU C T. Fast and slow rates of naphthalene sorption to biochars produced at different temperatures[J]. Environmental Science & Technology, 2012, 46(20):11104-11111.
    [19] HAN L F, RO K S, SUN K, et al. New evidence for high sorption capacity of hydrochar for hydrophobic organic pollutants[J]. Environmental Science & Technology, 2016, 50(24):13274-13282.
    [20] XIAO X, CHEN B L, ZHU L. Transformation, morphology, and dissolution of silicon and carbon in rice straw-derived biochars under different pyrolytic temperatures[J]. Environmental Science & Technology, 2014, 48(6):3411-3419.
    [21] QIU C, HE Y, BROOKES P, et al. The systematic characterization of nanoscale bamboo charcoal and its sorption on phenanthrene:A comparison with microscale[J]. Science of the Total Environment, 2016, 578:399-407.
    [22] PENG H B, PAN B, WU M, et al. Adsorption of ofloxacin on carbon nanotubes:solubility, pH and cosolvent effects[J]. Journal of Hazardous Materials, 2012, 211:342-348.
    [23] ZHANG G, ZHANG Q, SUN K, et al. Sorption of simazine to corn straw biochars prepared at different pyrolytic temperatures[J]. Environmental Pollution, 2011, 159(10):2594-2601.
    [24] ZHAO L, ZHENG W, MASEK O, et al. Roles of phosphoric acid in biochar formation:Synchronously improving carbon retention and sorption capacity[J]. Journal of Environmental Quality, 2017, 46(2):393-401.
    [25] PENG H B, LI H, WANG C, et al. Sorption and solubility of ofloxacin and norfloxacin in water-methanol cosolvent[J]. Chemosphere, 2014, 103(5):322-328.
    [26] PAN B, XING B S. Adsorption mechanisms of organic chemicals on carbon nanotubes[J]. Environmental Science & Technology, 2009, 42(24):9005-9013.
