兰永辉, 高仁富, 许世爱, 王璞, 张庆华. 利用蚀刻废液生产碱式氯化铜过程中二噁英类污染物的去除[J]. 环境化学, 2014, 33(10): 1744-1749. doi: 10.7524/j.issn.0254-6108.2014.10.017
引用本文: 兰永辉, 高仁富, 许世爱, 王璞, 张庆华. 利用蚀刻废液生产碱式氯化铜过程中二噁英类污染物的去除[J]. 环境化学, 2014, 33(10): 1744-1749. doi: 10.7524/j.issn.0254-6108.2014.10.017
shu
LAN Yonghui, GAO Renfu, XU Shiai, WANG Pu, ZHANG Qinghua. Elimination of dioxin-like compounds in the production process of tribasic copper chloride with the spent etching solutions[J]. Environmental Chemistry, 2014, 33(10): 1744-1749. doi: 10.7524/j.issn.0254-6108.2014.10.017
Citation: LAN Yonghui, GAO Renfu, XU Shiai, WANG Pu, ZHANG Qinghua. Elimination of dioxin-like compounds in the production process of tribasic copper chloride with the spent etching solutions[J]. Environmental Chemistry, 2014, 33(10): 1744-1749. doi: 10.7524/j.issn.0254-6108.2014.10.017
shu

利用蚀刻废液生产碱式氯化铜过程中二噁英类污染物的去除

  • 1.

    东江环保股份有限公司, 深圳, 518057;

  • 2.

    东江环保股份有限公司沙井处理基地, 深圳, 518104;

  • 3.

    中国科学院生态环境研究中心, 环境化学与生态毒理学国家重点实验室, 北京, 100085

Elimination of dioxin-like compounds in the production process of tribasic copper chloride with the spent etching solutions

  • 1.

    Dongjiang Environmental Co., Ltd, Shenzhen, 518057, China;

  • 2.

    Shajing Treatment Center of DJE, Shenzhen, 518104, China;

  • 3.

    State Key Laboratory of Environmental Chemistry and Ecotoxicology, Research Center for Eco-Environmental Sciences, Chinese Academy of Sciences, Beijing, 100085, China

  • 摘要: 针对蚀刻废液及其回收后生产的碱式氯化铜产品中二噁英(PCDD/Fs)和二噁英类多氯联苯(dl-PCBs)进行了分析研究,并比较了采用去除工艺前后两类污染物含量水平的变化特征.利用高分辨气相色谱/高分辨质谱对样品中PCDD/Fs和dl-PCBs进行分析,结果表明,氯化铜废液中PCDD/Fs和dl-PCBs的平均总浓度分别为264、139 pg·mL-1,而铜氨液中浓度分别为0.09、0.50 pg·mL-1;碱式氯化铜产品中浓度分别为106 pg·g-1(2.79 pg WHO-TEQ2005·g-1)和27.8 pg·g-1(0.69 pg WHO-TEQ2005·g-1);而经过吸附和过滤等去除工艺后,产品中PCDD/Fs和dl-PCBs的TEQ浓度水平分别降低至0.10—0.25 pg WHO-TEQ2005·g-1和0.05—0.72 pg WHO-TEQ2005·g-1,满足欧盟对于矿物源性饲料添加剂中PCDD/Fs和dl-PCBs的限量标准要求.研究表明该工艺能够有效去除利用蚀刻废液生产碱式氯化铜过程中的二噁英类污染物.
    Abstract: Polychlorinated dibenzo-p-dioxins and dibenzofurans (PCDD/Fs) and dioxin-like polychlorinated biphenyls (dl-PCBs) were analyzed in the spent etching solutions and their recycling products tribasic copper chloride (TBCC). The contamination levels and distribution were evaluated after an elimination process was utilized. High resolution gas chromatograph/high resolution mass spectrometry (HRGC/HRMS) was employed for sample analysis. The results showed that the average concentrations of PCDD/Fs and dl-PCBs were 264 pg·mL-1 and 139 pg·mL-1 in the spent copper chloride solutions, while they were only 0.09 pg·mL-1 and 0.50 pg·mL-1 in the spent alkaline etching solutions. The concentrations in the TBCC samples were 106 pg·g-1 (2.79 pg WHO-TEQ2005·g-1) and 27.8 pg·g-1 (0.69 pg WHO-TEQ2005·g-1) for PCDD/Fs and dl-PCBs, respectively. However, when an elimination process including adsorption and filtration was introduced into the production, the levels of toxic equivalence (TEQ) for PCDD/Fs and dl-PCBs were reduced to 0.10—0.25 pg WHO-TEQ2005·g-1 and 0.05—0.72 pg WHO-TEQ2005·g-1, respectively, which are lower than the maximum levels established by European Commission. It suggested that the process could effectively reduce the amount of dioxin-like compounds during the production of TBCC with spent etching solutions.
  • 加载中
  • [1] Kang H N,Lee J Y,Kim J Y. Recovery of indium from etching waste by solvent extraction and electrolytic refining[J].Hydrometallurgy, 2011,110(1/4):120-127
    [2] Choi J Y,Kim D S. Production of ultrahigh purity copper using waste copper nitrate solution[J].J Hazard Mater,2003,99(2):147-158
    [3] Lee M S,Ahn J G,Ahn J W. Recovery of copper, tin and lead from the spent nitric etching solutions of printed circuit board and regeneration of the etching solution[J].Hydrometallurgy,2003,70 (1/3):23-29
    [4] Huang Z Y,Xie F C,Ma Y. Ultrasonic recovery of copper and iron through the simultaneous utilization of printed circuit boards (PCB) spent acid etching solution and PCB waste sludge[J].J Hazard Mater,2011,185(1):155-161
    [5] 巨佳,王吉坤. 废蚀刻液研究现状与展望[J].云南化工,2009,36(6):40-42
    [6] 丁教,舒红英. 饲料级硫酸铜中重金属的测定[J].江西化工,1999,1:24-25
    [7] Spears J W,Kegley E B,Mullis L A. Bioavailability of copper from tribasic copper chloride and copper sulfate in growing cattle[J].Anim Feed Sci Technol,2004,116 (1/2):1-13
    [8] 青宪,韩静磊,温炎燊. 蚀刻废液及其回收后生产的铜盐产品中PCDD/Fs含量水平及分布特征[J].环境科学,2013,34(2):642-646
    [9] Parera J,Abalos M,Pérez-Vendrell A M,et al. Occurrence and bioaccumulation study of PCDD and PCDF from mineral feed additives[J].Chemosphere,2008,73 (1 Suppl):S252-S260.
    [10] Jones KC,de Voogt P. Persistent organic pollutants (POPs): State of the science[J].Environ Pollut,1999,100:209-221
    [11] 王亚伟,张庆华,刘汉霞,等. 高分辨气相色谱-高分辨质谱测定活性污泥中多溴联苯醚[J].色谱,2005,23(5):492-495
    [12] European Food Safety Authority (EFSA). Commission Regulation (EU) No 277/2012 of 28 March 2012 amending Annexes I and II to Directive 2002/32/EC of the European Parliament and of the Council as regards maximum levels and action thresholds for dioxins and polychlorinated biphenyls[S].Official Journal of the European Commission,2012,L91:1-7
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2175
  • HTML全文浏览数:  2175
  • PDF下载数:  586
  • 施引文献:  0
出版历程
  • 收稿日期:  2014-07-08
兰永辉, 高仁富, 许世爱, 王璞, 张庆华. 利用蚀刻废液生产碱式氯化铜过程中二噁英类污染物的去除[J]. 环境化学, 2014, 33(10): 1744-1749. doi: 10.7524/j.issn.0254-6108.2014.10.017
引用本文: 兰永辉, 高仁富, 许世爱, 王璞, 张庆华. 利用蚀刻废液生产碱式氯化铜过程中二噁英类污染物的去除[J]. 环境化学, 2014, 33(10): 1744-1749. doi: 10.7524/j.issn.0254-6108.2014.10.017
shu
LAN Yonghui, GAO Renfu, XU Shiai, WANG Pu, ZHANG Qinghua. Elimination of dioxin-like compounds in the production process of tribasic copper chloride with the spent etching solutions[J]. Environmental Chemistry, 2014, 33(10): 1744-1749. doi: 10.7524/j.issn.0254-6108.2014.10.017
Citation: LAN Yonghui, GAO Renfu, XU Shiai, WANG Pu, ZHANG Qinghua. Elimination of dioxin-like compounds in the production process of tribasic copper chloride with the spent etching solutions[J]. Environmental Chemistry, 2014, 33(10): 1744-1749. doi: 10.7524/j.issn.0254-6108.2014.10.017
shu

利用蚀刻废液生产碱式氯化铜过程中二噁英类污染物的去除

  • 1.  东江环保股份有限公司, 深圳, 518057;
  • 2.  东江环保股份有限公司沙井处理基地, 深圳, 518104;
  • 3.  中国科学院生态环境研究中心, 环境化学与生态毒理学国家重点实验室, 北京, 100085
  • 收稿日期:  2014-07-08

摘要: 针对蚀刻废液及其回收后生产的碱式氯化铜产品中二噁英(PCDD/Fs)和二噁英类多氯联苯(dl-PCBs)进行了分析研究,并比较了采用去除工艺前后两类污染物含量水平的变化特征.利用高分辨气相色谱/高分辨质谱对样品中PCDD/Fs和dl-PCBs进行分析,结果表明,氯化铜废液中PCDD/Fs和dl-PCBs的平均总浓度分别为264、139 pg·mL-1,而铜氨液中浓度分别为0.09、0.50 pg·mL-1;碱式氯化铜产品中浓度分别为106 pg·g-1(2.79 pg WHO-TEQ2005·g-1)和27.8 pg·g-1(0.69 pg WHO-TEQ2005·g-1);而经过吸附和过滤等去除工艺后,产品中PCDD/Fs和dl-PCBs的TEQ浓度水平分别降低至0.10—0.25 pg WHO-TEQ2005·g-1和0.05—0.72 pg WHO-TEQ2005·g-1,满足欧盟对于矿物源性饲料添加剂中PCDD/Fs和dl-PCBs的限量标准要求.研究表明该工艺能够有效去除利用蚀刻废液生产碱式氯化铜过程中的二噁英类污染物.
