海南省典型饮用水源地水体与沉积物中抗生素的残留及风险评价
Residual and Risk Assessment of Antibiotics in Water and Sediments of Typical Drinking Water Sources in Hainan Province
-
摘要: 抗生素因其高效性而被大量使用，排放进入环境后成为新污染物，其健康风险日益引起广泛关注。目前在多种环境介质中均检测到抗生素的存在，而海南省尚缺乏有关饮用水源地抗生素污染的数据。本研究选取海南省5个典型饮用水源地采集水样和底泥沉积物样品，分析了5类抗生素（磺胺类、喹诺酮类、四环素类、大环内酯类和其他类）的污染水平，并评估水体中抗生素的生态和健康风险。结果表明，在水体中共检出9种抗生素，总浓度范围为2.48～112.87 ng·L-1，主要污染物为磺胺甲恶唑、氟罗沙星和强力霉素。沉积物中共检出12种抗生素，总浓度范围为3.46～28.92 ng·g-1，主要污染物为氟罗沙星。生态风险评估结果表明，水体中检出的抗生素风险商（RQ）值均<1，未发现单一抗生素在各水源地存在高风险。人体健康风险评估结果表明，各水源地中检出的抗生素健康风险商（RQH）值均远<0.01，对成人和儿童健康造成的损害可忽略。Abstract: Antibiotics are widely used owing to their high efficiency. However, the discharge of antibiotics into the ambient environment resulting in them as a category of emerging contaminants, causing potential human health risks which are attracting increasingly attention in recent years. To date, antibiotics have been detected in a variety of environmental matrices, whereas there is still a lack of data on antibiotic contamination in drinking water sources in Hainan Province. In this study, water and sediment samples were collected from five typical drinking water sources in Hainan Province, the pollution levels of five classes of antibiotics, including sulfonamides, quinolones, tetracyclines, macrolides and others, were analyzed, and the potential health risks were assessed. The results indicated that nine antibiotics were frequently detected in the water, with total concentrations ranging from 2.48 to 112.87 ng·L-1. The main pollutants were sulfamethoxazole, fleroxacin and doxycycline. Twelve antibiotics were detected in the sediments, with concentrations ranging from 3.46 to 28.92 ng·g-1. The major pollutant was fleroxacin. The ecological risk assessment results of antibiotics in water showed that the risk quotient (RQ) value is less than 1in all water samples, and no antibiotic is found to have high risk in each water source. The results of human health risk assessment showed that the health risk quotient (RQH) value of antibiotics detected in each water source is far less than 0.01, and the damage to adults and children can be neglected.
-
Key words:
- antibiotics /
- drinking water sources /
- water /
- sediments /
- ecological risks /
- human health risks
-
-
Gao L H, Shi Y L, Li W H, et al. Occurrence of antibiotics in eight sewage treatment plants in Beijing, China[J]. Chemosphere, 2012, 86(6):665-671 张秀蓝, 张烃, 董亮, 等. 固相萃取/液相色谱-串联质谱法检测医院废水中21种抗生素药物残留[J]. 分析测试学报, 2012, 31(4):453-458 Zhang X L, Zhang T, Dong L, et al. Determination of antibiotics in hospital wastewater using HPLC-MS/MS coupled with solid phase extraction[J]. Journal of Instrumental Analysis, 2012, 31(4):453-458(in Chinese)
张烜瑞. 山东半岛海水养殖场中抗生素在不同养殖阶段的分布与生物积累特征[D]. 济南:山东大学, 2021:1-90 Zhang H R. The distribution and bioaccumulation characteristics of antibiotics in different aquaculture stages in Shandong peninsula mariculture farms[D]. Jinan:Shandong University, 2021:1 -90(in Chinese)
Li S, Shi W Z, Liu W, et al. A duodecennial national synthesis of antibiotics in China's major rivers and seas (2005-2016)[J]. The Science of the Total Environment, 2018, 615:906-917 Ci M W, Zhang G D, Yan X S, et al. Occurrence of antibiotics in the Xiaoqing River Basin and antibiotic source contribution:A case study of Jinan City, China[J]. Environmental Science and Pollution Research International, 2021, 28(20):25241-25254 Wang C, Zhao Y P, Liu S, et al. Contamination, distribution, and risk assessment of antibiotics in the urban surface water of the Pearl River in Guangzhou, South China[J]. Environmental Monitoring and Assessment, 2021, 193(2):98 Wang L F, Li H, Dang J H, et al. Occurrence, distribution, and partitioning of antibiotics in surface water and sediment in a typical tributary of Yellow River, China[J]. Environmental Science and Pollution Research International, 2021, 28(22):28207-28221 Zhu Y G, Johnson T A, Su J Q, et al. Diverse and abundant antibiotic resistance genes in Chinese swine farms[J]. Proceedings of the National Academy of Sciences of the United States of America, 2013, 110(9):3435-3440 中华人民共和国国务院办公厅. 新污染物治理行动方案[R]. 北京:国务院办公厅, 2022 Hu Y R, Jin L, Zhao Y, et al. Annual trends and health risks of antibiotics and antibiotic resistance genes in a drinking water source in East China[J]. The Science of the Total Environment, 2021, 791:148152 Feng L, Cheng Y R, Zhang Y Y, et al. Distribution and human health risk assessment of antibiotic residues in large-scale drinking water sources in Chongqing area of the Yangtze River[J]. Environmental Research, 2020, 185:109386 Liu Y H, Chen Y, Feng M J, et al. Occurrence of antibiotics and antibiotic resistance genes and their correlations in river-type drinking water source, China[J]. Environmental Science and Pollution Research International, 2021, 28(31):42339-42352 Zhang Q Q, Ying G G, Pan C G, et al. Comprehensive evaluation of antibiotics emission and fate in the river basins of China:Source analysis, multimedia modeling, and linkage to bacterial resistance[J]. Environmental Science & Technology, 2015, 49(11):6772-6782 于云江, 严骁, 石运刚, 等. 典型流域抗生素调查与排放量估算以长江流域重庆段为例[M]. 北京:中国环境出版集团, 2021:1 姚宏, 孙佩哲. 抗生素污染控制技术与原理[M]. 北京:科学出版社, 2020:10 Anh H Q, Le T P Q, da le N, et al. Antibiotics in surface water of East and Southeast Asian countries:A focused review on contamination status, pollution sources, potential risks, and future perspectives[J]. Science of the Total Environment, 2021, 764:142865 孟明辉, 贺泽英, 徐亚平, 等. QuEChERS方法结合高效液相色谱-串联质谱法同时测定土壤中20种抗生素[J]. 农业环境科学学报, 2017, 36(8):1672-1679 Meng M H, He Z Y, Xu Y P, et al. Simultaneous extraction and determination of antibiotics in soils using a QuEChERS-based method and liquid chromatography-tandem mass spectrometry[J]. Journal of Agro-Environment Science, 2017, 36(8):1672-1679(in Chinese)
李涛, 王策, 徐兆安, 等. 基于分散固相萃取-超高效液相色谱串联质谱法测定沉积物中大环内酯类抗生素[J]. 环境化学, 2022, 41(1):231-240 Li T, Wang C, Xu Z A, et al. Determination of macrolide antibiotics in the sediment based on dispersed solid-phase extraction coupled with ultra performance liquid chromatography-electrospray ionization tandem mass spectrometry[J]. Environmental Chemistry, 2022, 41(1):231-240(in Chinese)
European Commission. European Commission technical guidance document in support of Commission Directive 93/67/EEC on Risk assessment for new notified substances and Commission Regulation (EC) No.1488/94 on risk assessment for existing substance, part Ⅱ[R]. Brussel:European Commission Joint Research Centre, 2003:100-103 Papageorgiou M, Zioris I, Danis T, et al. Comprehensive investigation of a wide range of pharmaceuticals and personal care products in urban and hospital wastewaters in Greece[J]. Science of the Total Environment, 2019, 694:133565 Eguchi K, Nagase H, Ozawa M, et al. Evaluation of antimicrobial agents for veterinary use in the ecotoxicity test using microalgae[J]. Chemosphere, 2004, 57(11):1733-1738 应光国, 彭平安, 赵建亮. 流域化学品生态风险评价以东江流域为例[M]. 北京:科学出版社, 2012:183 Backhaus T, Scholze M, Grimme L H. The single substance and mixture toxicity of quinolones to the bioluminescent bacterium Vibrio fischeri[J]. Aquatic Toxicology, 2000, 49(1-2):49-61 Brain R A, Johnson D J, Richards S M, et al. Effects of 25 pharmaceutical compounds to Lemna gibba using a seven-day static-renewal test[J]. Environmental Toxicology and Chemistry, 2004, 23(2):371-382 Halling-Sørensen B, Lützhøft H C, Andersen H R, et al. Environmental risk assessment of antibiotics:Comparison of mecillinam, trimethoprim and ciprofloxacin[J]. The Journal of Antimicrobial Chemotherapy, 2000, 46(Suppl 1):53-58 Lützhøft H H, Halling-Sørensen B, Jørgensen S E. Algal toxicity of antibacterial agents applied in Danish fish farming[J]. Archives of Environmental Contamination and Toxicology, 1999, 36(1):1-6 Hernando M D, Mezcua M, Fernández-Alba A R, et al. Environmental risk assessment of pharmaceutical residues in wastewater effluents, surface waters and sediments[J]. Talanta, 2006, 69(2):334-342 Hanna N D, Sun P, Sun Q, et al. Presence of antibiotic residues in various environmental compartments of Shandong Province in Eastern China:Its potential for resistance development and ecological and human risk[J]. Environment International, 2018, 114:131-142 Wang H X, Yang J Q, Yu X, et al. Exposure of adults to antibiotics in a Shanghai suburban area and health risk assessment:A biomonitoring-based study[J]. Environmental Science & Technology, 2018, 52(23):13942-13950 段小丽. 中国人群暴露参数手册(儿童卷)概要[M]. 北京:中国环境出版社, 2016:38-166 中华人民共和国环境保护部. 中国人群暴露参数手册(成人卷)[M]. 北京:中国环境出版社, 2013:45-764 李辉, 陈瑀, 封梦娟, 等. 南京市饮用水源地抗生素污染特征及风险评估[J]. 环境科学学报, 2020, 40(4):1269-1277 Li H, Chen Y, Feng M J, et al. Pollution characteristics and risk assessment of antibiotics in Nanjing drinking water sources[J]. Acta Scientiae Circumstantiae, 2020, 40(4):1269-1277(in Chinese)
张晶晶, 陈娟, 王沛芳, 等. 中国典型湖泊四大类抗生素污染特征[J]. 中国环境科学, 2021, 41(9):4271-4283 Zhang J J, Chen J, Wang P F, et al. Pollution characteristics of four-type antibiotics in typical lakes in China[J]. China Environmental Science, 2021, 41(9):4271-4283(in Chinese)
Kim S C, Carlson K. Temporal and spatial trends in the occurrence of human and veterinary antibiotics in aqueous and river sediment matrices[J]. Environmental Science & Technology, 2007, 41(1):50-57 Matongo S, Birungi G, Moodley B, et al. Pharmaceutical residues in water and sediment of Msunduzi River, KwaZulu-Natal, South Africa[J]. Chemosphere, 2015, 134:133-140 王同飞, 张伟军, 李立青, 等. 白洋淀清淤示范区沉积物中抗生素和多环芳烃的分布特征与风险评估[J]. 环境科学, 2021, 42(11):5303-5311 Wang T F, Zhang W J, Li L Q, et al. Distribution characteristics and risk assessment of antibiotics and polycyclic aromatic hydrocarbons in the sediments of desilting demonstration area in Baiyangdian Lake[J]. Environmental Science, 2021, 42(11):5303-5311(in Chinese)
Zhang P W, Zhou H D, Li K, et al. Occurrence of pharmaceuticals and personal care products, and their associated environmental risks in Guanting Reservoir and its upstream rivers in North China[J]. RSC Advances, 2018, 8(9):4703-4712 金磊, 姜蕾, 韩琪, 等. 华东地区某水源水中13种磺胺类抗生素的分布特征及人体健康风险评价[J]. 环境科学, 2016, 37(7):2515-2521 Jin L, Jiang L, Han Q, et al. Distribution characteristics and health risk assessment of thirteen sulfonamides antibiotics in a drinking water source in East China[J]. Environmental Science, 2016, 37(7):2515-2521(in Chinese)
Kong M, Bu Y Q, Zhang Q, et al. Distribution, abundance, and risk assessment of selected antibiotics in a shallow freshwater body used for drinking water, China[J]. Journal of Environmental Management, 2021, 280:111738 Wang Z Y, Chen Q W, Zhang J Y, et al. Characterization and source identification of tetracycline antibiotics in the drinking water sources of the Lower Yangtze River[J]. Journal of Environmental Management, 2019, 244:13-22 武俊梅, 魏琳, 彭晶倩, 等. 长江中游典型饮用水水源中药物的时空分布及风险评价[J]. 环境科学, 2022, 43(6):2996-3004 Wu J M, Wei L, Peng J Q, et al. Spatiotemporal distribution and risk assessment of pharmaceuticals in typical drinking water sources in the middle reaches of the Yangtze River[J]. Environmental Science, 2022, 43(6):2996-3004(in Chinese)
Liu Y H, Feng M J, Wang B, et al. Distribution and potential risk assessment of antibiotic pollution in the main drinking water sources of Nanjing, China[J]. Environmental Science and Pollution Research International, 2020, 27(17):21429-21441 Chen Y H, Cui K P, Huang Q L, et al. Comprehensive insights into the occurrence, distribution, risk assessment and indicator screening of antibiotics in a large drinking reservoir system[J]. The Science of the Total Environment, 2020, 716:137060 Cui C Z, Han Q, Jiang L, et al. Occurrence, distribution, and seasonal variation of antibiotics in an artificial water source reservoir in the Yangtze River Delta, East China[J]. Environmental Science and Pollution Research International, 2018, 25(20):19393-19402 Kolpin D W, Furlong E T, Meyer M T, et al. Pharmaceuticals, hormones, and other organic wastewater contaminants in US streams, 1999-2000:A national reconnaissance[J]. Environmental Science & Technology, 2002, 36(6):1202-1211 Tamtam F, Mercier F, Le Bot B, et al. Occurrence and fate of antibiotics in the Seine River in various hydrological conditions[J]. The Science of the Total Environment, 2008, 393(1):84-95 张慧, 郭文建, 朱晨, 等. 山东省主要河流中抗生素污染组成及空间分布特征[J]. 中国环境监测, 2019, 35(1):89-94 Zhang H, Guo W J, Zhu C, et al. Composition and spatial distribution characteristics of antibiotics in main rivers of Shandong Province[J]. Environmental Monitoring in China, 2019, 35(1):89-94(in Chinese)
Chen K, Zhou J L. Occurrence and behavior of antibiotics in water and sediments from the Huangpu River, Shanghai, China[J]. Chemosphere, 2014, 95:604-612 赵旭蕾, 董佳玥, 陆隽鹤. 氧氟沙星敏化光解磺胺甲恶唑[J]. 环境科学学报, 2022, DOI:10.13671/j.hjkxxb.2022. 0049
刘晓晖, 王炜亮, 国晓春, 等. 抗生素的水体赋存、毒性及风险[J]. 给水排水, 2015, 51(12):116-121 Liu X H, Wang W L, Guo X C, et al. Occurrence, toxicity and risk of antibiotics in water[J]. Water & Wastewater Engineering, 2015, 51(12):116-121(in Chinese)
Gorokhova E, Rivetti C, Furuhagen S, et al. Bacteria-mediated effects of antibiotics on Daphnia nutrition[J]. Environmental Science & Technology, 2015, 49(9):5779-5787 谢全模, 陈云, 万金泉, 等. 东莞市饮用水源地中抗生素分布特征及风险评价[J]. 环境科学学报, 2020, 40(1):166-178 Xie Q M, Chen Y, Wan J Q, et al. Occurrence, distribution and risk assessment of antibiotics in drinking water source in Dongguan[J]. Acta Scientiae Circumstantiae, 2020, 40(1):166-178(in Chinese)
张君, 程艳茹, 封丽, 等. 三峡库区饮用水水源抗生素健康风险评价[J]. 环境科学与技术, 2018, 41(8):192-198 Zhang J, Cheng Y R, Feng L, et al. Health risk assessment of antibiotics in the centralized drinking water source in the Three Gorges Reservoir area[J]. Environmental Science& Technology, 2018, 41(8):192-198(in Chinese)
Liu X H, Lu S Y, Guo W, et al. Antibiotics in the aquatic environments:A review of lakes, China[J]. The Science of the Total Environment, 2018, 627:1195-1208 Zhou L J, Wu Q L, Zhang B B, et al. Occurrence, spatiotemporal distribution, mass balance and ecological risks of antibiotics in subtropical shallow Lake Taihu, China[J]. Environmental Science Processes & Impacts, 2016, 18(4):500-513 -
