羧基化多壁碳纳米管与镉复合干扰蚕豆幼苗生理特性的研究
Study on the Disturbation of Physiological Characteristics in Vicia faba L. Seedlings Exposed to Combination of Carboxylated Multi-Walled Carbon Nanotubes and Cadmium
-
摘要: 为探究羧基化多壁碳纳米管（MWCNTs-COOH）复合镉（Cd）对蚕豆幼苗的毒性效应，利用水培实验研究了MWCNTs-COOH（0、1.5、3.0、6.0和12.0 mg·L-1）与Cd（10 μmol·L-1）单一、复合胁迫下蚕豆幼苗生理的变化。结果表明，MWCNTs-COOH单一处理，随着其浓度的增加，根系活力呈下降趋势，当浓度达到12.0 mg·L-1时，与对照相比下降35.7%；低浓度的MWCNTs-COOH促使叶绿素含量增加，且1.5 mg·L-1 MWCNTs-COOH显著诱导叶中过氧化物酶（POD）活性升高；6.0～12.0 mg·L-1 MWCNTs-COOH促进叶·O2-产生速率加快，超氧化物歧化酶（SOD）活性升高，叶中红褐色斑点增多；MWCNTs-COOH浓度为12.0 mg·L-1时，根·O2-产生速率显著加快，SOD活性下降，根细胞染色加深，死亡加剧。MWCNTs-COOH与Cd复合后，当MWCNTs-COOH低于6.0 mg·L-1，与MWCNTs-COOH单一处理组比较，根系活力未见明显变化；增至6.0 mg·L-1后，根系活力降低至10 μmol·L-1 Cd单独处理组之下。所有复合处理组根和叶丙二醛（MDA）含量皆高于对应的MWCNTs-COOH单一处理，6.0 mg·L-1 MWCNTs-COOH复合Cd诱导根和叶POD活性增加，而12.0 mg·L-1 MWCNTs-COOH与Cd共同作用使叶中红褐色斑点加深且所占叶面积加大，达到64.02%，H2O2含量急剧增加，根尖细胞受损并部分脱落。因此，高浓度的MWCNTs-COOH能够加剧Cd对蚕豆幼苗的氧化胁迫。Abstract: In order to explore the joint toxic effects of carboxylated multi-walled carbon nanotubes (MWCNTs-COOH) and cadmium (Cd) on Vicia faba seedlings, the physiological changes of the seedlings hydroponically cultured in solution of MWCNTs-COOH (0, 1.5, 3.0, 6.0, and 12.0 mg·L-1), Cd (10 μmol·L-1) alone or their combination were investigated in present experiments. The results showed that root activities tended to decrease with the increase of the single treatment concentration of MWCNTs-COOH. The root activity decreased by 35.7% at 12.0 mg·L-1 MWCNTs-COOH in comparison to that of the control. In addition, low concentrations of MWCNTs-COOH promoted the production of chlorophyll, and peroxidase (POD) activity was significantly elevated at 1.5 mg·L-1 MWCNTs-COOH compared with the control in the leaves. Moreover,·O2- production rates, superoxide dismutase (SOD) activities and reddish-brown spots were increased with the increase of MWCNTs-COOH concentration from 6.0 to 12.0 mg·L-1 in the leaves. In roots, at 12.0 mg·L-1 MWCNTs-COOH, the·O2- was significantly produced, and the SOD activity was obviously declined compared with the control. Additionally, the dead cells in stained roots increased under the treatment. Under the combination of MWCNTs-COOH and Cd, no obvious changes were observed in the root activities at the concentrations of MWCNTs-COOH lower than 6.0 mg·L-1, compared with the single MWCNTs treatments with the corresponding concentrations. When the MWCNTs-COOH increased up to 6.0 mg·L-1, the root activities decreased below that of 10 μmol·L-1 Cd single treatment. Malondialdehyde (MDA) contents increased to be more than the corresponding treatment of MWCNTs-COOH in the roots or leaves under the combined treatments. POD activity was boosted in all the roots or leaves under the joint treatment by 6.0 mg·L-1 MWCNTs-COOH and 10 μmol·L-1 Cd. Particularly, the reddish-brown spots were expanded to 64.02%, and hydrogen peroxide production was markedly accumulated in the leaves, while the root tip cells were damaged and partially fell off the roots under the combination of 12.0 mg·L-1 MWCNTs-COOH and 10 μmol·L-1 Cd. Thus, it can be concluded that higher concentrations of MWCNTs-COOH (no less than 6.0 mg·L-1) may exacerbate the oxidative stress in V. faba seedlings exposed to Cd in culture solution.
-
Key words:
- MWCNTs-COOH /
- Cd /
- Vicia faba seedlings /
- toxic effect
-
-
Guaglianoni W C, Florence C L, Bonatto F, et al. Novel nanoarchitectured cobalt-doped TiO2 and carbon nanotube arrays:Synthesis and photocurrent performance[J]. Ceramics International, 2019, 45(2):2439-2445 Ninnora Meethal B, Ramanarayanan R, Swaminathan S. Surface modification of oxygen-deficient ZnO nanotubes by interstitially incorporated carbon:A superior photocatalytic platform for sustainable water and surface treatments[J]. Applied Nanoscience, 2018, 8(6):1545-1555 王婧雯, 张静静, 范同祥. 碳纳米管表面处理及其在铜基复合材料中的应用[J]. 材料导报, 2018, 32(17):2932-2939 , 2948 Wang J W, Zhang J J, Fan T X. Process in surface treatment of carbon nanotubes and its applications to copper matrix composites[J]. Materials Review, 2018, 32(17):2932-2939, 2948(in Chinese)
陈晓, 陈佳辉, 陈日耀, 等. 功能化多壁碳纳米管负载铁离子改性双极膜的制备与表征[J]. 高分子材料科学与工程, 2017, 33(4):148-153 Chen X, Chen J H, Chen R Y, et al. Preparation and characterization of bipolar membranes modified by functionalized multiwalled carbon nanotubes loaded with Fe3+[J]. Polymer Materials Science & Engineering, 2017, 33(4):148-153(in Chinese)
Petersen E J, Zhang L W, Mattison N T, et al. Potential release pathways, environmental fate, and ecological risks of carbon nanotubes[J]. Environmental Science & Technology, 2011, 45(23):9837-9856 贾建博, 江翠娟, 闫兵. 纳米材料在易感群体小鼠模型中的潜在毒性[J]. 科学通报, 2017, 62(24):2749-2757 Jia J B, Jiang C J, Yan B. Potential nanotoxicity in susceptible populations:Insight from investigation of mouse models[J]. Chinese Science Bulletin, 2017, 62(24):2749-2757(in Chinese)
Edgington A J, Roberts A P, Taylor L M, et al. The influence of natural organic matter on the toxicity of multiwalled carbon nanotubes[J]. Environmental Toxicology and Chemistry, 2010, 29(11):2511-2518 Mouchet F, Landois P, Puech P, et al. Carbon nanotube ecotoxicity in amphibians:Assessment of multiwalled carbon nanotubes and comparison with double-walled carbon nanotubes[J]. Nanomedicine, 2010, 5(6):963-974 Folkrnann J K, Risom L, Jacobsen N R, et al. Oxidatively damaged DNA in rats exposed by oral gavage to C60 fullerenes and single-walled carbon nanotubes[J]. Environmental Health Perspectives, 2009, 117(5):703-708 Liu S, Wei L, Hao L, et al. Sharper and faster "nanodarts" kill more bacteria:A still of antibacterial activity of individually dispersed pristine single-walled carbon nanotube[J]. ACS Nano, 2009, 3(12):3891-3902 Parvin B, Ikhtiari R, Fugetsu B, et al. Phytotoxicity of multi-walled carbon nanotubes assessed by selected plant species in the seedling stage[J]. Applied Surface Science, 2012, 262(13):120-124 Begum P, Ikhtiari R, Fugetsu B. Graphene phytotoxicity in the seedling stage of cabbage, tomato, red spinach, and lettuce[J]. Carbon, 2011, 49(12):3907-3919 Khodakovskaya M, Dervishi E, Mahmood M, et al. Carbon nanotubes are able to penetrate plant seed coat and dramatically affect seed germination and plant growth[J]. ACS Nano, 2009, 3(10):3221-3227 Khodakovskaya M V, Dervishi E, Villagarcia H, et al. Carbon nanotubes induce growth enhancement of tobacco cells[J]. ACS Nano, 2012, 6(3):2128-2135 Hassan S E, Hijri M, St-Arnaud M. Effect of arbuscular mycorrhizal fungi on trace metal uptake by sunflower plants grown on cadmium contaminated soil[J]. New Biotechnology, 2013, 30(6):780-787 Sato A, Takeda H, Wataru O, et al. Reduction of cadmium uptake in spinach (Spinacia oleracea L.) by soil amendment with animal waste compost[J]. Journal of Hazardous Materials, 2010, 181(1-3):298-304 刘俊, 廖柏寒, 曾清如, 等. 镉胁迫对豆科作物生理生态效应研究进展[J]. 生态毒理学报, 2010, 5(2):295-301 Liu J, Liao B H, Zeng Q R, et al. Advances on physiological and ecological effects of cadmium onlegume crops[J]. Asian Journal of Ecotoxicology, 2010, 5(2):295-301(in Chinese)
王素娟. 水体重金属污染现状及其治理方法研究[J]. 中国化工贸易, 2015(19):151 Gomez M R, Cerutti S, Sombra L L, et al. Determination of heavy metals for the quality control in Argentinian herbal medicines by ETAAS and ICP-OES[J]. Food and Chemical Toxicology, 2006, 45(6):1060-1064 Gupta S K, Chabukdhara M, Singh J, et al. Evaluation and potential health hazard of selected metals in water, sediments, and fish from the Gomti River[J]. Human and Ecological Risk Assessment, 2015, 21(1):227-240 Zhang X R, Song K H, Liu J F, et al. Sorption of triclosan by carbon nanotubes in dispersion:The importance of dispersing properties using different surfactants[J]. Colloids and Surfaces A:Physicochemical and Engineering Aspects, 2019, 562:280-288 Wang C, Liu H, Chen J, et al. Carboxylated multi-walled carbon nanotubes aggravated biochemical and subcellular damages in leaves of broad bean (Vicia faba L.) seedlings under combined stress of lead and cadmium[J]. Journal of Hazardous Materials, 2014, 274(15):404-412 胡秉芬, 黄华梨, 季元祖, 等. 分光光度法测定叶绿素含量的提取液的适宜浓度[J]. 草业科学, 2018, 35(8):1965-1974 Hu B F, Huang H L, Ji Y Z, et al. Evaluation of the optimum concentration of chlorophyll extract for determination of chlorophyll content by spectrophotometry[J]. Pratacultural Science, 2018, 35(8):1965-1974(in Chinese)
张志勇, 卜晶晶, 王素芳, 等. 冠菌素对不同钾水平下TTC法测定的棉花根系活力的影响[J]. 植物生理学报, 2015, 51(5):695-701 Zhang Z Y, Bu J J, Wang S F, et al. Effect of coronatine on cotton root activity determined by TTC assay at different levels of potassium[J]. Plant Physiology Journal, 2015, 51(5):695-701(in Chinese)
李忠光, 龚明. 植物中超氧阴离子自由基测定方法的改进[J]. 云南植物研究, 2005, 27(2):211-216 Li Z G, Gong M. Improvement of measurement method for superoxide anion radical in plant[J]. Acta Botanica Yunnanica, 2005, 27(2):211-216(in Chinese)
丛国强, 尹成林, 何邦令, 等. 水分胁迫下内生真菌球毛壳ND35对冬小麦苗期生长和抗旱性的影响[J]. 生态学报, 2015, 35(18):6120-6128 Cong G Q, Yin C L, He B L, et al. Effect of the endophytic fungus Chaetomium globosum ND35 on the growth and resistance to drought of winter wheat at the seedling stage under water stress[J]. Acta Ecologica Sinica, 2015, 35(18):6120-6128(in Chinese)
Romero-Puertas M C, Rodriguez-Serrano M, Corpas F J, et al. Cadmium-induced subcellular accumulation of·O2- and H2O2 in pea leaves[J]. Plant, Cell and Environment, 2004, 27(9):1122-1134 刘楠, 林植芳. 用伊文思蓝染色法检测植物整体叶片的细胞活性[J]. 植物生理学报, 2011, 47(6):570-574 Liu N, Lin Z F. Use of Evans blue for testing cell viability of intact leaves of plant[J]. Plant Physiology Journal, 2011, 47(6):570-574(in Chinese)
Rong H, Wang C R, Yu X R, et al. Carboxylated multi-walled carbon nanotubes exacerbated oxidative damage in roots of Vicia faba L. seedlings under combined stress of lead and cadmium[J]. Ecotoxicology and Environmental Safety, 2018, 161:616-623 Jiang L, Ma L, Sui Y, et al. Effect of manure compost on the herbicide prometryne bioavailability to wheat plants[J]. Journal of Hazardous Materials, 2010, 184(1-3):337-344 Zhou Z S, Wang S J, Yang Z M. Biological detection and analysis of mercury toxicity to alfalfa (Medicago sativa) plants[J]. Chemosphere, 2008, 70(8):1500-1509 张栋. 干旱胁迫对苹果光合作用和叶绿素荧光的影响及叶片衰老特性研究[D]. 杨凌:西北农林科技大学, 2011:6-7 Zhang D. Effects of drought stress on photosynthesis and fluorescence chlorophyll parameters of apple leaves and leaf senescence characteristics[D]. Yangling:Northwest A & F University, 2011:6 -7(in Chinese)
李香玲, 冯跃华. 水稻根系生长特性及其与地上部分关系的研究进展[J]. 中国农学通报, 2015, 31(6):1-6 Li X L, Feng Y H. Research advance on relation of aerial part and root traits of rice[J]. Chinese Agricultural Science Bulletin, 2015, 31(6):1-6(in Chinese)
杨祥宇. 纳米二氧化钛对人工湿地水处理系统的影响机制研究[D]. 重庆:重庆大学, 2018:55-56 Yang X Y. Impacts mechanism of titanium oxidation nanoparticles on functionalities of constructed wetlands[D]. Chongqing:Chongqing University, 2018:55 -56(in Chinese)
Begum P, Ikhtiari R, Fugetsu B, et al. Phytotoxicity of multi-walled carbon nanotubes assessed by selected plant species in the seedling stage[J]. Applied Surface Science, 2012, 262:120-124 Wang H J, Zhou A L, Peng F, et al. Adsorption characteristic of acidified carbon nanotubes for heavy metal Pb(Ⅱ) in aqueous solution[J]. Materials Science and Engineering:A, 2007, 466(1-2):201-206 Noctor G, Reichheld J P, Foyer C H. ROS-related redox regulation and signaling in plants[J]. Seminars in Cell & Developmental Biology, 2018, 80:3-12 Segal L M, Wilson R A. Reactive oxygen species metabolism and plant-fungal interactions[J]. Fungal Genetics & Biology, 2018, 110(110):1-9 Begum P, Ikhtiari R, Fugetsu B. Potential impact of multi-walled carbon nanotubes exposure to the seedling stage of selected plant species[J]. Nanomaterials, 2014, 4(2):203-221 Begum P, Fugetsu B. Phytotoxicity of multi-walled carbon nanotubes on red spinach (Amaranthus tricolor L.) and the role of ascorbic acid as an antioxidant[J]. Journal of Hazardous Materials, 2012, 243:212-222 Tan X M, Lin C, Fugetsu B. Studies on toxicity of multi-walled carbon nanotubes on suspension rice cells[J]. Carbon, 2009, 47(15):3479-3487 刘雪琴. 纳米ZnO/AM真菌对玉米的生物效应及作用机理研究[D]. 重庆:西南大学, 2015:28-29 Liu X Q. Biological effects of nano-ZnO and arbuscular mycorrhizal fungi on maize and its mechanism[D]. Chongqing:Southwest University, 2015:28 -29(in Chinese)
邱清华, 邓绍云, 黄娟, 等. 铅胁迫对十字花科种子萌发及幼苗生长的影响[J]. 中国农学通报, 2010, 26(18):175-179 Qiu Q H, Deng S Y, Huang J, et al. Study on the influence of lead stress on the mustard family's seed sprouting and seedling growing[J]. Chinese Agricultural Science Bulletin, 2010, 26(18):175-179(in Chinese)
张苗苗. Se4+对Cd2+胁迫下蚕豆根生理生化特性的研究[D]. 成都:四川师范大学, 2008:27-29 Zhang M M. The research on the physiological and chemical characteristic of Vicia faba cultivating in Se-Cd compounds[D]. Chengdu:Sichuan Normal University, 2008:27 -29(in Chinese)
俞萍, 高凡, 刘杰, 等. 镉对植物生长的影响和植物耐镉机制研究进展[J]. 中国农学通报, 2017, 33(11):89-95 Yu P, Gao F, Liu J, et al. Effect of Cd on plant growth and its tolerance mechanism[J]. Chinese Agricultural Science Bulletin, 2017, 33(11):89-95(in Chinese)
钟建丹, 陈红春, 罗春燕, 等. 碳纳米管与菲暴露对水稻发芽及幼苗生长的影响[J]. 农业环境科学学报, 2018, 37(10):2110-2117 Zhong J D, Chen H C, Luo C Y, et al. Exposure to carbon nanotube and phenanthrene:Impact on germination and seedling growth of rice[J]. Journal of Agro-Environment Science, 2018, 37(10):2110-2117(in Chinese)
Seppänen M, Turakainen M, Hartikainen H. Selenium effects on oxidative stress in potato[J]. Plant Science, 2003, 165(2):311-319 杨淑慎, 高俊凤. 活性氧、自由基与植物的衰老[J]. 西北植物学报, 2001, 21(2):215-220 Yang S S, Gao J F. Influence of active oxygen and free radicals on plant senescence[J]. Acta Botanica Boreali-Occidentalia Sinica, 2001, 21(2):215-220(in Chinese)
郭敏, 龚继来, 曾光明. 多壁碳纳米管对水稻幼苗的植物毒性研究[J]. 生态毒理学报, 2016, 11(5):94-102 Guo M, Gong J L, Zeng G M. Comprehensive phytotoxicity assessment of multi-wall carbon nanotubes on rice seedlings[J]. Asian Journal of Ecotoxicology, 2016, 11(5):94-102(in Chinese)
罗潇宇, 任垠安, 高浩杰, 等. 羧基化多壁碳纳米管对蛋白核小球藻的生物学效应研究[J]. 生态毒理学报, 2017, 12(5):212-218 Luo X Y, Ren Y A, Gao H J, et al. Effects of carboxylated multi-walled carbon nanotubes on the physiology of Chlorella pyrenoidosa[J]. Asian Journal of Ecotoxicology, 2017, 12(5):212-218(in Chinese)
-
