铁钴共掺杂的Mn-Ce/TiO2催化剂低温SCR脱硝

,  ,  ,

downloadPDF

上一篇

下一篇

朱少文, 沈伯雄, 池桂龙, 张笑. 铁钴共掺杂的Mn-Ce/TiO2催化剂低温SCR脱硝[J]. 环境工程学报, 2017, 11(6): 3633-3639. doi: 10.12030/j.cjee.201609229
引用本文: 朱少文, 沈伯雄, 池桂龙, 张笑. 铁钴共掺杂的Mn-Ce/TiO2催化剂低温SCR脱硝[J]. 环境工程学报, 2017, 11(6): 3633-3639. doi: 10.12030/j.cjee.201609229
shu
ZHU Shaowen, SHEN Boxiong, CHI Guilong, ZHANG Xiao. Low-temperature SCR of NO over Fe and Co co-doped Mn-Ce/TiO2 catalyst[J]. Chinese Journal of Environmental Engineering, 2017, 11(6): 3633-3639. doi: 10.12030/j.cjee.201609229
Citation: ZHU Shaowen, SHEN Boxiong, CHI Guilong, ZHANG Xiao. Low-temperature SCR of NO over Fe and Co co-doped Mn-Ce/TiO2 catalyst[J]. Chinese Journal of Environmental Engineering, 2017, 11(6): 3633-3639. doi: 10.12030/j.cjee.201609229
shu

铁钴共掺杂的Mn-Ce/TiO2催化剂低温SCR脱硝

  • 1.

    南开大学环境科学与工程学院, 天津 300350

  • 2.

    河北工业大学能源与环境工程学院, 天津 300401

  • 基金项目:

    国家自然科学基金资助项目（51541602）

    河北省重点基金资助项目（E2016202361）

  • 中图分类号: X511

Low-temperature SCR of NO over Fe and Co co-doped Mn-Ce/TiO2 catalyst

  • 1.

    College of Environmental Science and Engineering, Nankai University, Tianjin 300350, China

  • 2.

    College of Energy and Environmental Engineering, Hebei University of Technology, Tianjin 300401, China

  • Fund Project:

  • 摘要: 采用浸渍法制备了Fe和Co改性的Mn-Ce/TiO2催化剂，研究了Fe和Co共同掺杂对催化剂脱硝及抗水抗硫性的影响。发现Fe和Co以1：2摩尔比共同掺杂的催化剂具有最佳的脱硝活性。通过BET、XRD、XPS和FTIR等表征手段对其微观结构和抗毒性机理进行研究，发现Fe和Co的掺杂能明显提高催化剂的比表面积和孔隙率，增强催化剂的氧化还原性能。Fe和Co的引入还能减少硫酸根离子和水分子在催化剂表面的累积，从而增强催化剂的抗水抗硫性能。
    Abstract: Fe and Co co-doped Mn-Ce/TiO2 catalysts prepared by impregnation method were investigated for low temperature SCR of NO with NH3. The activity experiment showed that the Fe and Co co-doped catalyst with a Fe/Co molar ratio of 1:2 achieved the highest NO conversion. The resistance to SO2 andH2O of the catalyst was also studied. The catalyst was characterized by BET, XRD, XPS and FTIR to discuss the property and mechanism of resistance to SO2 andH2O of the catalyst. The result indicated that BET surface area and porosity of the Mn-Ce/TiO2 catalyst was greatly improved after co-doping Fe and Co. The XPS result demonstrated that the redox state of the catalyst was well balanced by the introduction of Fe and Co. The result indicated that the co-doping of Fe and Co could inhibit the accumulation of sulfate and water molecule on the surface of the catalyst,as a result, enhance the catalysts resistance to SO2 andH2O.
  • 加载中
  • [1] PENA Donovan A, UPHADE Balu S, SMIRNIOTIS Panagiotis G. TiO2-supported metal oxide catalysts for low-temperature selective catalytic reduction of NO with NH3 I. Evaluation and characterization of first row transition metals[J]. Journal of Catalysis,2004,221(2):421-431
    [2] CHEN Lei, SI Zhichun, WU Xiaodong, et al. Rare earth containing catalysts for selective catalytic reduction of NOx with ammonia:A Review[J]. Journal of Rare Earths,2014,32(10):907-917
    [3] GU Tingting, LIU Yue, WENG Xiaole, et al. The enhanced performance of ceria with surface sulfation for selective catalytic reduction of NO by NH3[J]. Catalysis Communications,2010,12(4):310-313
    [4] LI Li, WANG Lishan, PAN Siwei, et al. Effects of cerium on the selective catalytic reduction activity and structural properties of manganese oxides supported on multi-walled carbon nanotubes catalysts[J]. Chinese Journal of Catalysis,2013,34(6):1087-1097
    [5] QI Gongshin, YANG Ralph T. Low-temperature selective catalytic reduction of NO with NH3 over iron and manganese oxides supported on titania[J]. Applied Catalysis B:Environmental,2003,44(3):217-225
    [6] SHEN Boxiong, LIU Ting, ZHAO Ning, et al. Iron-doped Mn-Ce/TiO2 catalyst for low temperature selective catalytic reduction of NO with NH3[J]. Journal of Environmental Sciences,2010,22(9):1447-1454
    [7] SHANG Danhong, ZHONG Qin, CAI Wei, High performance of NO oxidation over Ce-Co-Ti catalyst:The interaction between Ce and Co[J]. Applied Surface Science,2015,325:211-216
    [8] HU Hang, CAI Sixiang, LI Hongrui, et al. Mechanistic Aspects of deNOx processing over TiO2 supported Co-Mn oxide catalysts:Structure-Activity relationships and in situ DRIFTs analysis[J]. ACS Catalysis:,2015,5(10):6069-6077
    [9] QIU Lu, MENG Jiaojiao, PANG Dandan, et al. Reaction and characterization of Co and Ce doped Mn/TiO2 catalysts for low-temperature SCR of NO with NH3[J]. Catalysis Letters,2015,145(7):1500-1509
    [10] SHEN Boxiong, YAO Yan, MA Hongqing, et al. Ceria modified MnOx/TiO2-pillared clays catalysts for the selective catalytic reduction of NO with NH3 at low temperature[J]. Chinese Journal of Catalysis,2011,32(12):1803-1811
    [11] LI Jun, YANG Chengwu, ZHANG Jian, et al. Effects of Fe addition on the structure and catalytic performance of mesoporous Mn/Al-SBA-15 catalysts for the reduction of NO with ammonia[J]. Catalysis Communications, 2015,62:24-28
    [12] JIANG B Q, WU Z B, LIU Y, et al. DRIFT Study of the SO2 Effect on Low-Temperature SCR Reaction over Fe-Mn/TiO2[J]. The Journal of Physical Chemistry C, 2010,114(11):4961-4965
    [13] LEE Sang Moon, PARK Kwang Hee, HONG Sung Chang. MnOx/CeO2-TiO2 mixed oxide catalysts for the selective catalytic reduction of NO with NH3 at low temperature[J]. Chemical Engineering Journal,2012,195-196:323-331
    [14] PATSALAS P, LOGOTHETIDIS S, SYGELLOU L, et al. Structure-dependent electronic properties of nanocrystalline cerium oxide films[J]. Physical Review B,2003,68(3):1-12
    [15] SHEN Boxiong, WANG Fumei, LIU Ting. Homogeneous MnOx-CeO2 pellets prepared by a one-step hydrolysis process for low-temperature NH3-SCR[J]. Powder Technology, 2014,253:152-157
    [16] XIONG Zhibo, HU Qiang, LIU Dunyu, et al. Influence of partial substitution of iron oxide by titanium oxide on the structure and activity of iron-cerium mixed oxide catalyst for selective catalytic reduction of NOx with NH3[J]. Fuel, 2016,165:432-439
    [17] NISSINEN Terhi, LESKELA Markku, GASIK Michael, et al. Decomposition of mixed Mn and Co nitrates supported on carbon[J]. Thermochimica Acta,2005,427(1):155-161
    [18] SHU Yun, AIKEBAIER Tanana, QUAN Xie, et al. Selective catalytic reaction of NOx with NH3 over Ce-Fe/TiO2-loaded wire-mesh honeycomb:Resistance to SO2 poisoning[J]. Applied Catalysis B:Environmental, 2014,150-151:630-635
    [19] YAMAMOTO Akira, TERAMURA Kentaro, HOSOKAWA Saburo, et al. Effects of SO2 on selective catalytic reduction of NO with NH3 over a TiO2 photocatalyst[J]. Science and Technology of Advanced Materials,2015,16(2):1-9
    [20] HUANG Helen Y, YANG Ralph T. Removal of NO by reversible adsorption on Fe-Mn based transition metal oxides[J]. Langmuir,2001,17(16):4997-5003
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  2017
  • HTML全文浏览数:  1637
  • PDF下载数:  541
  • 施引文献:  0
出版历程
  • 收稿日期:  2016-11-23
  • 刊出日期:  2017-06-23
朱少文, 沈伯雄, 池桂龙, 张笑. 铁钴共掺杂的Mn-Ce/TiO2催化剂低温SCR脱硝[J]. 环境工程学报, 2017, 11(6): 3633-3639. doi: 10.12030/j.cjee.201609229
引用本文: 朱少文, 沈伯雄, 池桂龙, 张笑. 铁钴共掺杂的Mn-Ce/TiO2催化剂低温SCR脱硝[J]. 环境工程学报, 2017, 11(6): 3633-3639. doi: 10.12030/j.cjee.201609229
shu
ZHU Shaowen, SHEN Boxiong, CHI Guilong, ZHANG Xiao. Low-temperature SCR of NO over Fe and Co co-doped Mn-Ce/TiO2 catalyst[J]. Chinese Journal of Environmental Engineering, 2017, 11(6): 3633-3639. doi: 10.12030/j.cjee.201609229
Citation: ZHU Shaowen, SHEN Boxiong, CHI Guilong, ZHANG Xiao. Low-temperature SCR of NO over Fe and Co co-doped Mn-Ce/TiO2 catalyst[J]. Chinese Journal of Environmental Engineering, 2017, 11(6): 3633-3639. doi: 10.12030/j.cjee.201609229
shu

铁钴共掺杂的Mn-Ce/TiO2催化剂低温SCR脱硝

  • 1. 南开大学环境科学与工程学院, 天津 300350
  • 2. 河北工业大学能源与环境工程学院, 天津 300401
  • 收稿日期:  2016-11-23
基金项目:

国家自然科学基金资助项目（51541602）

河北省重点基金资助项目（E2016202361）

摘要: 采用浸渍法制备了Fe和Co改性的Mn-Ce/TiO2催化剂，研究了Fe和Co共同掺杂对催化剂脱硝及抗水抗硫性的影响。发现Fe和Co以1：2摩尔比共同掺杂的催化剂具有最佳的脱硝活性。通过BET、XRD、XPS和FTIR等表征手段对其微观结构和抗毒性机理进行研究，发现Fe和Co的掺杂能明显提高催化剂的比表面积和孔隙率，增强催化剂的氧化还原性能。Fe和Co的引入还能减少硫酸根离子和水分子在催化剂表面的累积，从而增强催化剂的抗水抗硫性能。
