卤化铵改性竹炭对单质汞吸附性能的影响

,  ,  ,  ,

downloadPDF

上一篇

下一篇

徐欢, 沈伯雄, 张笑, 田灵辉, 李富宽. 卤化铵改性竹炭对单质汞吸附性能的影响[J]. 环境工程学报, 2017, 11(6): 3647-3652. doi: 10.12030/j.cjee.201603086
引用本文: 徐欢, 沈伯雄, 张笑, 田灵辉, 李富宽. 卤化铵改性竹炭对单质汞吸附性能的影响[J]. 环境工程学报, 2017, 11(6): 3647-3652. doi: 10.12030/j.cjee.201603086
shu
XU Huan, SHEN Boxiong, ZHANG Xiao, TIAN Linghui, LI Fukuan. Effects on elemental mercury adsorption characteristics of bamboo charcoal modified by ammonium halide[J]. Chinese Journal of Environmental Engineering, 2017, 11(6): 3647-3652. doi: 10.12030/j.cjee.201603086
Citation: XU Huan, SHEN Boxiong, ZHANG Xiao, TIAN Linghui, LI Fukuan. Effects on elemental mercury adsorption characteristics of bamboo charcoal modified by ammonium halide[J]. Chinese Journal of Environmental Engineering, 2017, 11(6): 3647-3652. doi: 10.12030/j.cjee.201603086
shu

卤化铵改性竹炭对单质汞吸附性能的影响

  • 1.

    河北工业大学能源与环境工程学院, 天津 300401

  • 2.

    南开大学环境科学与工程学院, 天津 300071

  • 基金项目:

    国家重点研发计划项目（2016YFC0209202）

    河北省重点基金资助项目（E2016202361）

    海外青年基金资助项目（51550110237）

  • 中图分类号: X511

Effects on elemental mercury adsorption characteristics of bamboo charcoal modified by ammonium halide

  • 1.

    School of Energy and Environmental Engineering, Hebei University of Technology, Tianjin 300401, China

  • 2.

    College of Environmental Science and Engineering, Nankai University, Tianjin 300071, China

  • Fund Project:

  • 摘要: 为了研究廉价吸附剂竹炭的脱汞性能，将经过CO2活化并采用NH4Cl、NH4I超声浸渍改性的竹炭（BC）应用于单质汞的吸附，并对比不同负载量的NH4Cl以及NH4I改性和温度等因素对竹炭的汞脱除性能的影响。采用了元素分析、扫描电镜分析、XPS表征、比表面积及孔径分布等对材料进行研究。结果表明，NH4Cl和NH4I改性显著提高竹炭的脱汞能力，并且在同等条件下NH4I改性剂效果优于NH4Cl。研究表明提高负载量会造成吸附材料孔堵塞，但在0~8wt.%的负载量情况下，孔道的堵塞不足以抵消化学吸附带来的积极作用，表明改性竹炭对汞的吸附主要表现为化学吸附。同时改性竹炭存在随着温度升高其吸附效率先降低后升高的趋势，暗示竹炭对汞的吸附在低温时物理吸附占优势，温度升高时化学吸附占优势。
    Abstract: To study the mercury removal performance of a low-cost adsorbent, bamboo charcoal (BC) was applied to elemental mercury after activation by CO2 and ultrasonic modification by NH4Cl and NH4I.The loading amount of the modifier and temperature were taken into account.Ultimate analysis, scanning electron microscopy (SEM), and X-ray photoelectron spectroscopy (XPS) were conducted;specific surface area, and pore size distribution of the materials were studied.The pore structures were investigated based on Brunauer-Emmett-Teller (BET) surface area.The experimental results and characterization data indicate that both NH4Cl and NH4I can significantly improve the mercury removal ability of BC.The BC sample modified by NH4I performed better than the one modified by NH4Cl did, under the same experimental conditions.The modifier may block the fine pores in the BC samples by increasing the concentration of NH4Cl solution, which is not conducive to the physical adsorption of elemental mercury during the initial adsorption period;however, the blockage of the pores of the modified BC was not enough to offset the positive effect of chemical adsorption.This study shows that the mercury adsorption ability of modified BC depended mainly on chemical adsorption rather than physical adsorption.The adsorption efficiency of the modified BC first increased and then decreased, indicating that physical adsorption played a leading role at lower temperatures while chemical adsorption played a major role at higher temperatures.
  • 加载中
  • [1] LEE S H, RHIM Y J, CHO S P, et al.Carbon-based novel sorbent for removing gas-phase mercury[J].Fuel, 2006, 85(2):219-226
    [2] KRISHNAN S V, GULLETT B K, JOZEWICZ W.Sorption of Elemental Mercury by Activated Carbons[J].Environmental Science & Technology, 1994, 28(8):1506-1512
    [3] MENDELSOHN M, HARKNESS J.Enhanced flue gas denitrification using ferrous EDTA and a polyphenolic compound having combined antioxidant and reducing properties[R].Argonne National Lab., IL (USA), 1990
    [4] 赵毅, 陈周燕, 汪黎东, 等.湿式烟气脱硫系统同时脱汞研究[J].环境工程学报, 2008, 2(1):64-69
    [5] ESWARAN S, STENGER H G.Understanding mercury conversion in selective catalytic reduction (SCR) catalysts[J].Energy & Fuels, 2005, 19(6):2328-2334
    [6] SKODRAS G, DIAMANTOPOUJOU I, SAKELLAROPOUJO G P.Role of activated carbon structural properties and surface chemistry in mercury adsorption[J].Desalination, 2007, 210(1-3):281-286
    [7] VIDIC R D, SILER D P.Vapor-phase elemental mercury adsorption by activated carbon impregnated with chloride and chelating agents[J].Carbon, 2001, 39(1):3-14
    [8] SHU T, LU P, HE N.Mercury adsorption of modified mulberry twig chars in a simulated flue gas[J].Bioresource Technology, 2013, 136:182-187
    [9] LIU W J, ZENG F X, JIANG H, et al.Preparation of high adsorption capacity bio-chars from waste biomass[J].Bioresource Technology, 2011, 102(17):8247-8252
    [10] TAN Z, XIANG J, SU S, et al.Enhanced capture of elemental mercury by bamboo-based sorbents[J].Journal of Hazardous Materials, 2012, 239-240:160-166
    [11] ZENG H C, JIN F, GUO J.Removal of elemental mercury from coal combustion flue gas by chloride-impregnated activated carbon[J].Fuel, 2004, 83(1):143-146
    [12] GHORISHI S B, KEENEY R M, SERRE S D, et al.Development of a Cl-impregnated activated carbon for entrained-flow capture of elemental mercury[J].Environmental Science & Technology, 2002, 36(20):4454-4459
    [13] LEE S J, SEO Y C, JURNG J, et al.Removal of gas-phase elemental mercury by iodine-and chlorine-impregnated activated carbons[J].Atmospheric Environment, 2004, 38(29):4887-4893
    [14] 徐丽梅玫, 许飘, 李彩亭, 等.稻壳活性炭对单质汞吸附性能的实验研究[J].环境工程学报,2010, 4(9):2065-2068
    [15] LI G, SHEN B, WANG Y, et al.Comparative study of element mercury removal by three bio-chars from various solid wastes[J].Fuel, 2015, 145:189-195
    [16] 张东升, 江泽慧, 任海青, 等.竹炭微观构造形貌表征[J].竹子研究汇刊, 2006(4):1-8
    [17] 高德霖, 孙小玉.活性炭纤维和微孔吸附的容积充填理论[J].精细化工原料及中间体, 2003(10):2-6
    [18] 冒咏秋.NH4Cl/NH4Br改性活性炭脱除模拟烟气中Hg0的实验研究[D].南京:东南大学, 2013
    [19] TAN Z, QIU J, ZENG H, et al.Removal of elemental mercury by bamboo charcoal impregnated with H2O2[J].Fuel, 2011, 90(4):1471-1475
    [20] FENG W, BORGUET E, VIDIC R D.Sulfurization of carbon surface for vapor phase mercury removal-I:Effect of temperature and sulfurization protocol[J].Carbon, 2006, 44(14):2990-2997
    [21] 戴嘉璐, 郭兴忠, 杨辉, 等.竹炭微结构的研究[J].材料科学与工程学报, 2007(5):743-745
    [22] 左宋林, 高尚愚, 徐柏森, 等.炭化过程中竹材内部形态结构的变化[J].林产化学与工业, 2004(4):56-60
    [23] 谭增强, 邱建荣, 向军, 等.氯化锌改性竹炭脱除单质汞的特性与机理分析[J].化工学报, 2011(7):1944-1950
    [24] LI G, SHEN B, WANG Y, et al.Comparative study of element mercury removal by three bio-chars from various solid wastes[J].Fuel, 2015, 145:189-195
    [25] LI G, SHEN B, LI Y, et al.Removal of element mercury by medicine residue derived biochars in presence of various gas compositions[J].Journal of Hazardous Materials, 2015, 298:162-169
