响应曲面法优化微波诱导载铜活性炭处理焦化废水

,  ,  ,

downloadPDF

上一篇

下一篇

孟海玲, 张回, 刘再亮, 朱丽莎. 响应曲面法优化微波诱导载铜活性炭处理焦化废水[J]. 环境工程学报, 2017, 11(2): 872-878. doi: 10.12030/j.cjee.201509055
引用本文: 孟海玲, 张回, 刘再亮, 朱丽莎. 响应曲面法优化微波诱导载铜活性炭处理焦化废水[J]. 环境工程学报, 2017, 11(2): 872-878. doi: 10.12030/j.cjee.201509055
shu
MENG Hailing, ZHANG Hui, LIU Zailiang, ZHU Lisha. Optimization of microwave induced copper-loaded activated carbon of coking wastewater using response surface methodology[J]. Chinese Journal of Environmental Engineering, 2017, 11(2): 872-878. doi: 10.12030/j.cjee.201509055
Citation: MENG Hailing, ZHANG Hui, LIU Zailiang, ZHU Lisha. Optimization of microwave induced copper-loaded activated carbon of coking wastewater using response surface methodology[J]. Chinese Journal of Environmental Engineering, 2017, 11(2): 872-878. doi: 10.12030/j.cjee.201509055
shu

响应曲面法优化微波诱导载铜活性炭处理焦化废水

  • 1.

    安徽工业大学能源与环境学院, "生物膜法水质净化及利用技术"教育部工程研究中心, 马鞍山 243032

  • 基金项目:

    安徽省科技攻关计划项目（11010401010）

    安徽工业大学研究生创新基金资助项目（2013037）

Optimization of microwave induced copper-loaded activated carbon of coking wastewater using response surface methodology

  • 1.

    Energy and Environment School, "Water Purification and Utilization Technology of Biofilm Process" Engineering Research Center of Ministry of Education, Anhui University of Technology, Maanshan 243032, China

  • Fund Project:

  • 摘要: 以焦化废水好氧池出水为研究对象，采用微波诱导载铜活性炭深度处理焦化废水。在单因素实验的基础上，以焦化废水COD去除率为评价指标，微波功率、微波时间、催化剂用量为考察因素，采用Box-Behnken响应曲面法考察各影响因素的单独作用及交互作用对焦化废水COD去除率的影响，建立数学模型。通过响应曲面分析可知，微波功率、时间、催化剂用量以及微波功率与微波时间的交互作用对COD去除率均有显著影响，模型预测最佳工艺条件为微波功率550 W，微波时间5 min，催化剂用量20 g·L-1，COD去除率为84.23%，在该条件下通过两次验证实验得出结果平均值为82.63%，预测值与测定值相对误差为1.90%，两者具有较好的一致性。
    Abstract: In this article, we studied microwave induced copper-loaded activated carbon for treating wastewater. The aerobic tank effluent of coking wastewater was used as the water samples for the study. The COD removal rate of the coking wastewater was selected as the evaluation index, based on single-factor tests. The catalyst dosages, microwave power, and the microwave time were considered as the influential factors. The Box-Behnken response surface method was used to examine the effects of the independent variables and their interactions on the removal rate of COD from the coking wastewater. The mathematical model was subsequently constructed. The response surface analysis showed that the microwave power, time, catalyst dosages, and the interaction between the microwave power and the microwave time significantly correlated with the removal rate of COD. The model predicted the optimal conditions, which were indicated as microwave power 550 W, microwave time 5 min, and the catalyst dosage 20 g·L-1. The removal rate of COD was 84.23% in such conditions, the average value determined by two experiments was 82.63%, the relative error between the model-predicted and the measured values was 1.90%, and both showed good consistency.
  • 加载中
  • [1] 环境保护部. GB 16171-2012炼焦化学工业污染物排放标准[S]. 北京:中国环境科学出版社, 2012
    [2] 袁茂彪, 马雄风, 王书萍, 等. 絮凝-微波辐射-Fenton试剂氧化法深度处理焦化废水[J]. 化工环保, 2013, 33(6):513-517
    [3] 汪昆平, 赵越, 郭劲松, 等. 微波诱导AC/Cu、AC/Fe催化非均相Fenton反应催化降解垃圾渗滤液[J]. 环境工程学报, 2012, 6(11):3947-3952
    [4] PRASANNAKUMAR B R, REGUPATHI I, MURUGESAN T. An optimization study on microwave irradiated decomposition of phenol in the presence of H2O2[J]. Journal of Chemical Technology and Biotechnology, 2009, 84(1):83-91
    [5] REMYA N, LIN J G. Current status of microwave application in wastewater treatment-A review[J]. Chemical Engineering Journal, 2011, 166(3):797-813
    [6] 张静, 张惠灵, 袁修彬, 等. 微波诱导催化剂Fe2O3/沸石氧化处理印染废水[J]. 环境工程学报, 2011, 5(12):2778-2782
    [7] ATTA A Y, JIBRIL B Y, AL-WAHEIBI T K, et al. Microwave-enhanced catalytic degradation of 2-nitrophenol on alumina-supported copper oxides[J]. Catalysis Communications, 2012, 26:112-116
    [8] 李雨, 彭金辉, 雷鹰, 等. 微波-活性炭法处理焦化废水生化后出水实验研究[J]. 中国稀土学报, 2010, 28(S):649-653
    [9] 邓振伟, 于萍, 罗运柏, 等. 微波-Fenton试剂法去除焦化废水中COD和色度的研究[J]. 工业用水与废水, 2009, 40(6):40-43
    [10] 范明霞, 张智. 微波-活性炭-Fenton法处理焦化废水的研究[J]. 湖北工业大学学报, 2011, 26(5):36-39
    [11] 张惠灵, 张静, 刘海波, 等. 微波诱导Fe2O3/沸石负载型催化剂催化氧化焦化废水的研究[J]. 环境污染与防治, 2011, 33(2):69-73
    [12] ARSLAN A, VELI S, BINGÖL D. Use of response surface methodology for pretreatment of hospital wastewater by O3/UV and O3/UV/H2O2 processes[J]. Separation and Purification Technology, 2014, 132:561-567
    [13] CHAVALPARIT O, ONGWANDEE M. Optimizing electrocoagulation process for the treatment of biodiesel wastewater using response surface methodology[J]. Journal of Environmental Sciences, 2009, 21(11):1491-1496
    [14] SABER A, HASHEMINEJAD H, TAEBI A, et al. Optimization of Fenton-based treatment of petroleum refinery wastewater with scrap iron using response surface methodology[J]. Applied Water Science, 2014, 4(3):283-290
    [15] 王勇, 李伟光, 宿程远, 等. 响应曲面法优化均相Fenton深度处理皮革废水[J]. 环境科学学报, 2012, 32(10):2408-2414
    [16] IBOUKHOULEF H, AMRANE A, KADI H. Microwave-enhanced Fenton-like system, Cu(Ⅱ)/H2O2, for olive mill wastewater treatment[J]. Environmental Technology, 2013, 34(7):853-860
    [17] 占昌朝, 钟明强, 陈枫, 等. 微波诱导改性膨胀石墨-H2O2催化氧化刚果红废水[J]. 环境科学与技术, 2013, 36(10):186-190
    [18] 苗肖君, 王楠楠, 赵姗姗, 等. 微波辅助Cu(Ⅱ)-Fenton体系催化氧化处理对硝基苯酚废水[J]. 环境工程学报, 2014, 8(6):2299-2305
    [19] ZHANG Gaoke, GAO Yuanyuan, ZHANG Yalei, et al. Fe2O3-Pillared rectorite as an efficient and stable Fenton-like heterogeneous catalyst for photodegradation of organic contaminants[J]. Environmental Science & Technology, 2010, 44(16):6384-6389
    [20] 王栗, 岳琳, 王开红, 等. 响应曲面法优化电化学氧化技术处理染料废水[J]. 环境工程学报, 2014, 8(3):990-996
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1742
  • HTML全文浏览数:  1417
  • PDF下载数:  303
  • 施引文献:  0
出版历程
  • 收稿日期:  2015-12-01
  • 刊出日期:  2017-02-18
孟海玲, 张回, 刘再亮, 朱丽莎. 响应曲面法优化微波诱导载铜活性炭处理焦化废水[J]. 环境工程学报, 2017, 11(2): 872-878. doi: 10.12030/j.cjee.201509055
引用本文: 孟海玲, 张回, 刘再亮, 朱丽莎. 响应曲面法优化微波诱导载铜活性炭处理焦化废水[J]. 环境工程学报, 2017, 11(2): 872-878. doi: 10.12030/j.cjee.201509055
shu
MENG Hailing, ZHANG Hui, LIU Zailiang, ZHU Lisha. Optimization of microwave induced copper-loaded activated carbon of coking wastewater using response surface methodology[J]. Chinese Journal of Environmental Engineering, 2017, 11(2): 872-878. doi: 10.12030/j.cjee.201509055
Citation: MENG Hailing, ZHANG Hui, LIU Zailiang, ZHU Lisha. Optimization of microwave induced copper-loaded activated carbon of coking wastewater using response surface methodology[J]. Chinese Journal of Environmental Engineering, 2017, 11(2): 872-878. doi: 10.12030/j.cjee.201509055
shu

响应曲面法优化微波诱导载铜活性炭处理焦化废水

  • 1. 安徽工业大学能源与环境学院, "生物膜法水质净化及利用技术"教育部工程研究中心, 马鞍山 243032
  • 收稿日期:  2015-12-01
基金项目:

安徽省科技攻关计划项目（11010401010）

安徽工业大学研究生创新基金资助项目（2013037）

摘要: 以焦化废水好氧池出水为研究对象，采用微波诱导载铜活性炭深度处理焦化废水。在单因素实验的基础上，以焦化废水COD去除率为评价指标，微波功率、微波时间、催化剂用量为考察因素，采用Box-Behnken响应曲面法考察各影响因素的单独作用及交互作用对焦化废水COD去除率的影响，建立数学模型。通过响应曲面分析可知，微波功率、时间、催化剂用量以及微波功率与微波时间的交互作用对COD去除率均有显著影响，模型预测最佳工艺条件为微波功率550 W，微波时间5 min，催化剂用量20 g·L-1，COD去除率为84.23%，在该条件下通过两次验证实验得出结果平均值为82.63%，预测值与测定值相对误差为1.90%，两者具有较好的一致性。
