有机物性质对混凝-微滤-纳滤去除水中重金属的影响

,  ,  ,  ,

downloadPDF

上一篇

下一篇

钱飞跃, 史梦婷, 王建芳, 刘小朋, 王翻翻. 有机物性质对混凝-微滤-纳滤去除水中重金属的影响[J]. 环境工程学报, 2016, 10(7): 3634-3640. doi: 10.12030/j.cjee.201509052
引用本文: 钱飞跃, 史梦婷, 王建芳, 刘小朋, 王翻翻. 有机物性质对混凝-微滤-纳滤去除水中重金属的影响[J]. 环境工程学报, 2016, 10(7): 3634-3640. doi: 10.12030/j.cjee.201509052
shu
QIAN Feiyue, SHI Mengting, WANG Jianfang, LIU Xiaopeng, WANG Fanfan. Influence of organic matter property on heavy metal removal by combined coagulation-microfiltration and nanofiltration processes[J]. Chinese Journal of Environmental Engineering, 2016, 10(7): 3634-3640. doi: 10.12030/j.cjee.201509052
Citation: QIAN Feiyue, SHI Mengting, WANG Jianfang, LIU Xiaopeng, WANG Fanfan. Influence of organic matter property on heavy metal removal by combined coagulation-microfiltration and nanofiltration processes[J]. Chinese Journal of Environmental Engineering, 2016, 10(7): 3634-3640. doi: 10.12030/j.cjee.201509052
shu

有机物性质对混凝-微滤-纳滤去除水中重金属的影响

  • 1.

    苏州科技大学环境科学与工程学院, 苏州 215009

  • 2.

    江苏省环境科学与工程重点实验室, 苏州 215009

  • 3.

    江苏省水处理技术与材料协同创新中心, 苏州 215009

  • 基金项目:

    江苏省自然科学基金资助项目(BK20150284)

    江苏高校优势学科建设工程资助项目

    苏州科技学院科研项目(331311203)

  • 中图分类号: X703

Influence of organic matter property on heavy metal removal by combined coagulation-microfiltration and nanofiltration processes

  • 1.

    School of Environmental Science and Engineering, Suzhou University of Science and Technology, Suzhou 215009, China

  • 2.

    Jiangsu Key Laboratory of Environmental Science and Engineering, Suzhou 215009, China

  • 3.

    Jiangsu Collaborative Innovation Center of Technology and Material of Water Treatment, Suzhou 215009, China

  • Fund Project:

  • 摘要: 为了探明有机物性质对混凝-微滤-纳滤去除水中重金属的影响,将腐殖酸和乙酸分别作为背景有机物,系统考察了组合工艺对镉(Cd)、铜(Cu)、镍(Ni)和锌(Zn)的去除效能及其膜通量变化过程,并通过物料衡算对4种重金属的去除行为进行了比较分析。结果表明,当原水中不含有机物时,Cu的截留率最高,达到97%以上,纳滤膜是去除其他3种重金属的主要步骤。随着原水中腐殖酸含量的增大,混凝-微滤阶段对重金属的截留能力显著增强,膜通量衰减速度加快。相反地,乙酸的存在对于组合工艺处理效能具有明显的负面效应。此时,重金属既不能被铝盐絮体有效吸附,也不能通过静电作用截留在NF膜表面。4种重金属在滤液和浓水中的回收率Rrec都超过了80%,膜通量的变化与处理无机重金属溶液时相近。
    Abstract: To understand the effect of the properties of organic matter on heavy metal removal by combined coagulation-microfiltration and nanofiltration,humic acid or acetic acid was chosen as an organics background in raw water,and the rejection of Cd,Cu,Ni,and Zn in different processes and the flux evolution of the membrane permeate were investigated in this study.Additionally,the removal of heavy metals was also analyzed based on material balance.The results indicated that the highest rejection of over 97% was achieved for Cu,and also that nanofiltration would be the main step for the removal of other heavy metals from solutions containing inorganic species.The rejection performance of the coagulation-microfiltration process increased significantly with increasing humic acid concentration in the raw water,whereas the flux declined notably.Moreover,dosing with acetic acid exerted an adverse effect the on permeate quality since it weakened both the adsorption and complexation of alum flocs and the electrostatic interaction with the NF surface.The recovery of heavy metals,Rrec,was higher than 80%,with the flux level close to that for inorganic solution purification.
  • 加载中
  • [1] 王占生,刘文君,董丽华.饮用水深度处理的必要性与发展趋势.给水排水,2014,40(2):1-5
    [2] ZHOU Ping,YAN Hui,GU Baohua.Competitive complexation of metal ions with humic substances.Chemosphere,2005,58(10):1327-1337
    [3] YAN Mingquan,LI Mingyang,WANG Dongsheng,et al.Optical property of iron binding to Suwannee River fulvic acid.Chemosphere,2013,91(7):1042-1048
    [4] TOKUYAMA H.,HISAEDA J.,NII S.,et al.Removal of heavy metal ions and humic acid from aqueous solutions by co-adsorption onto thermosensitive polymers.Separation and Purification Technology,2010,71(1):83-88
    [5] BORBéLY G.,NAGY E.Removal of zinc and nickel ions by complexation-membrane filtration process from industrial wastewater.Desalination,2009,240(1/2/3):218-226
    [6] LLANOS J.,WILLIAMS P.M.,CHENG S.,et al.Characterization of a ceramic ultrafiltration membrane in different operational states after its use in a heavy-metal ion removal process.Water Research,2010,44(11):3522-3530
    [7] LIU Feini,ZHANG Guoliang,MENG Qin,et al.Performance of nanofiltration and reverse osmosis membranes in metal effluent treatment.Chinese Journal of Chemical Engineering,2008,16(3):441-445
    [8] MONDAL P.,BHOWMICK S.,CHATTERJEE D.,et al.Remediation of inorganic arsenic in groundwater for safe water supply:A critical assessment of technological solutions.Chemosphere,2013,92(2):157-170
    [9] 候立安,张林.膜分离技术在缓解水安全问题中的应用.中国工程科学,2014,16(7):4-9HOU Li'an.,ZHANG Lin.The application of membrane technology for reducing water security problem.Engineering Science,2014,16(7):4-9(in Chinese)
    [10] AL-RASHDI B.A.M.,JOHNSON D.J.,HILAL N.Removal of heavy metal ions by nanofiltration.Desalination,2013,315:2-17
    [11] YU Yang,ZHAO Changwei,WANG Yangui,et al.Effects of ion concentration and natural organic matter on arsenic(V) removal by nanofiltration under different transmembrane pressures.Journal of Environmental Sciences,2013,25(2):302-307
    [12] GHERASIM C.V.,MIKULASEK P.Influence of operating variables on the removal of heavy metal ions from aqueous solutions by nanofiltration.Desalination,2014,343:67-72
    [13] KATSOU E.,MALAMIS S.,HARALAMBOUS K.J.,et al.Industrial wastewater pre-treatment for heavy metal reduction by employing a sorbent-assisted ultrafiltration system.Chemosphere,2011,82(4):557-564
    [14] QIU Yunren,MAO Lianjun.Removal of heavy metal ions from aqueous solution by ultrafiltration assisted with copolymer of maleic acid and acrylic acid.Desalination,2013,329:78-85
    [15] KALIS E.J.J.,TEMMINGHOFF E.J.M.,WENG Liping,et al.Effects of humic acid and competing cations on metal uptake by Lolium perenne.Environmental Toxicology and Chemistry,2006,25(3):702-711
    [16] KATSOYIANNIS A.,SAMARA C.The fate of dissolved organic carbon(DOC) in the wastewater treatment process and its importance in the removal of wastewater contaminants.Environmental Science and Pollution Research,2007,14(5):284-292
    [17] YAN Mingquan,WANG Dongsheng,NI Jinren,et al.Mechanism of natural organic matter removal by polyaluminum chloride:Effect of coagulation particle size and hydrolysis kinetics.Water Research,2008,42(13):3361-3370
    [18] YAN Mingquan,LI Dechao,GAO Junfa,et al.Influence of chlorination on metal binding by dissolved organic matter:A study using Log-transformed differential spectra.Chemosphere,2014,103:290-298
    [19] AL-ABRI M.,DAKHEEL A.,TIZAOUI C.,et al.Combined humic substance and heavy metals coagulation,and membrane filtration under saline conditions.Desalination,2010,253(1-3):46-50
    [20] HUANG Haiou,SCHWAB K.,JACANGELO J.G.Pretreatment for low pressure membranes in water treatment:A review.Environmental Science & Technology,2009,43(9):3011-3019
    [21] YU Wenzheng,LIU Huijuan,LIU Ting,et al.Comparison of submerged coagulation and traditional coagulation on membrane fouling:Effect of active flocs.Desalination,2013,309:11-17
    [22] CHON K.,KIM S.J.,MOON J.,et al.Combined coagulation-disk filtration process as a pretreatment of ultrafiltration and reverse osmosis membrane for wastewater reclamation:An autopsy study of a pilot plant.Water Research,2012,46(6):1803-1816
    [23] BALANYÀ T.,LABANDA J.,LLORENS J.,et al.Separation of metal ions and chelating agents by nanofiltration.Journal of Membrane Science,2009,345(1/2):31-35
    [24] 刘硕,李振山,汪成运.酒石酸钾钠(PST)对纳滤处理重金属废水的强化效果.环境工程学报,2014,8(4):1290-1296 LIU Shuo,LI Zhenshan,WANG Chengyun.Enhancing effect of potassium sodium tartrate(PST) in nanofiltration process for treatment of heavy metal wastewater.Chinese Journal of Environmental Engineering,2014,8(4):1290-1296(in Chinese)
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  1770
  • HTML全文浏览数:  1296
  • PDF下载数:  985
  • 施引文献:  0
出版历程
  • 收稿日期:  2015-09-30
  • 刊出日期:  2016-07-06
钱飞跃, 史梦婷, 王建芳, 刘小朋, 王翻翻. 有机物性质对混凝-微滤-纳滤去除水中重金属的影响[J]. 环境工程学报, 2016, 10(7): 3634-3640. doi: 10.12030/j.cjee.201509052
引用本文: 钱飞跃, 史梦婷, 王建芳, 刘小朋, 王翻翻. 有机物性质对混凝-微滤-纳滤去除水中重金属的影响[J]. 环境工程学报, 2016, 10(7): 3634-3640. doi: 10.12030/j.cjee.201509052
shu
QIAN Feiyue, SHI Mengting, WANG Jianfang, LIU Xiaopeng, WANG Fanfan. Influence of organic matter property on heavy metal removal by combined coagulation-microfiltration and nanofiltration processes[J]. Chinese Journal of Environmental Engineering, 2016, 10(7): 3634-3640. doi: 10.12030/j.cjee.201509052
Citation: QIAN Feiyue, SHI Mengting, WANG Jianfang, LIU Xiaopeng, WANG Fanfan. Influence of organic matter property on heavy metal removal by combined coagulation-microfiltration and nanofiltration processes[J]. Chinese Journal of Environmental Engineering, 2016, 10(7): 3634-3640. doi: 10.12030/j.cjee.201509052
shu

有机物性质对混凝-微滤-纳滤去除水中重金属的影响

  • 1.  苏州科技大学环境科学与工程学院, 苏州 215009
  • 2.  江苏省环境科学与工程重点实验室, 苏州 215009
  • 3.  江苏省水处理技术与材料协同创新中心, 苏州 215009
  • 收稿日期:  2015-09-30
基金项目:

江苏省自然科学基金资助项目(BK20150284)

江苏高校优势学科建设工程资助项目

苏州科技学院科研项目(331311203)

摘要: 为了探明有机物性质对混凝-微滤-纳滤去除水中重金属的影响,将腐殖酸和乙酸分别作为背景有机物,系统考察了组合工艺对镉(Cd)、铜(Cu)、镍(Ni)和锌(Zn)的去除效能及其膜通量变化过程,并通过物料衡算对4种重金属的去除行为进行了比较分析。结果表明,当原水中不含有机物时,Cu的截留率最高,达到97%以上,纳滤膜是去除其他3种重金属的主要步骤。随着原水中腐殖酸含量的增大,混凝-微滤阶段对重金属的截留能力显著增强,膜通量衰减速度加快。相反地,乙酸的存在对于组合工艺处理效能具有明显的负面效应。此时,重金属既不能被铝盐絮体有效吸附,也不能通过静电作用截留在NF膜表面。4种重金属在滤液和浓水中的回收率Rrec都超过了80%,膜通量的变化与处理无机重金属溶液时相近。
