混凝-酵母菌生物膜联合工艺处理三元驱采油废水

,  ,  ,  ,  ,

downloadPDF

上一篇

下一篇

高芳, 刘东方, 张丽, 刘岩, 黄建, 陈娟. 混凝-酵母菌生物膜联合工艺处理三元驱采油废水[J]. 环境工程学报, 2015, 9(8): 3871-3877. doi: 10.12030/j.cjee.20150846
引用本文: 高芳, 刘东方, 张丽, 刘岩, 黄建, 陈娟. 混凝-酵母菌生物膜联合工艺处理三元驱采油废水[J]. 环境工程学报, 2015, 9(8): 3871-3877. doi: 10.12030/j.cjee.20150846
shu
Gao Fang, Liu Dongfang, Zhang Li, Liu Yan, Huang Jian, Chen Juan. Oilfield produced water from Alkali Surfactant Polymer(ASP) flooding by process of coagulation combined yeast biofilm[J]. Chinese Journal of Environmental Engineering, 2015, 9(8): 3871-3877. doi: 10.12030/j.cjee.20150846
Citation: Gao Fang, Liu Dongfang, Zhang Li, Liu Yan, Huang Jian, Chen Juan. Oilfield produced water from Alkali Surfactant Polymer(ASP) flooding by process of coagulation combined yeast biofilm[J]. Chinese Journal of Environmental Engineering, 2015, 9(8): 3871-3877. doi: 10.12030/j.cjee.20150846
shu

混凝-酵母菌生物膜联合工艺处理三元驱采油废水

  • 1.

    南开大学环境科学与工程学院, 天津 300457

  • 基金项目:

  • 中图分类号: X74

Oilfield produced water from Alkali Surfactant Polymer(ASP) flooding by process of coagulation combined yeast biofilm

  • 1.

    College of Environmental Science and Engineering, Nankai University, Tianjin 300457, China

  • Fund Project:

  • 摘要: 为解决三元驱采油废水的处理与回注问题,研究使用混凝预处理与特种产酸酵母菌生物膜法联合工艺对废水进行处理,再将酵母菌生物膜出水经过砂滤和超滤装置进行深度处理。探究pH,混凝剂种类和投加量等对混凝效果的影响,酵母菌生物膜工艺中外加碳源投加量对处理效果的影响。实验结果表明,将三元驱采油废水pH调至6.0左右,三氯化铁投加量600 mg/L,外加碳源投加量1.0 COD g/L时处理效果最佳。在进水COD为1 850 mg/L,粘度5.10 MPa·s,SS 256 mg/L,含油量131 mg/L,粒径中值105.25 μm的情况下,经过混凝预处理和酵母菌生物膜处理后的COD、SS、含油量的去除率分别达到84.86%、85.55%和98.54%,粘度降至1.05 MPa·s,经砂滤和超滤装置后,出水含油量< 0.5 mg/L,SS <1.0 mg/L,粒径中值 <0.1 μm,达到SYT 5329-2012中渗透层注水标准。
    Abstract: To solve the problem of treatment and reinjection of oilfield produced wastewater from ASP flooding, a laboratory study of coagulation pretreatment followed by special acid-producing yeast biofilm process for the wastewater treatment was undertaken, and then the effluent was passed through sand filtration and ultrafiltration devices for advanced treatment. The influencing factors, such as pH, coagulant type and coagulant dosage for the coagulation process were investigated. The effects of external carbon dosage in the yeast biofim reactor for the treatment performance were examed. The results show that the optimal treatment effect is achieved as the pH of the raw wastewater is about 6, coagulant (ferric chloride) dosage is 600 mg/L, and external carbon dosage is 1.0 g COD/L. When the COD, SS, crude oil, viscosity, and median particle size of the raw wastewater are 1850 mg/L, 256 mg/L, 131 mg/L, 5.10 MPa·s, and 105.25 μm, respectively, after the treatment of coagulation and yeast biofilm process, the COD, SS and crude oil can be removed by 84.86%, 85.55% and 98.54%, respectively, and the viscosity is reduced to 1.05 MPa·s. Advanced treatment by sand filtration and ultrafiltration devices enable the crude oil <0.5 mg/L, SS <1.0 mg/L, and median particle size <0.1 μm, which meet the injection water quality of medium permeability oilfield in SYT 5329-2012.
  • 加载中
  • [1] 叶清. 三元复合驱采出水特性分析及其处理方法研究. 上海: 上海交通大学硕士学位论文, 2008 Ye Qing. Research on oil/water separation characteristic and treatment ASP produced water. Shanghai: Master's Degree Thesis of Jiaotong University, 2008 (in Chinese)
    [2] 陈雷, 祁佩时, 王永庆, 等. 三元复合驱采石油废水的处理与回用研究. 中国给水排水, 2001, 17(6): 4-6 Chen Lei, Qi Peishi, Wang Yongqing, et al. Studies on the treatment and reuse of wastewater from the ternary compound oil drive. China Water ＆ Wastewater, 2001, 17(6): 4-6 (in Chinese)
    [3] Deng Shubo, Bai Renbi, Chen J. P., et al. Effects of alkaline/surfactant/polymer on stability of oil droplets in produced water from ASP flooding. Colloids and Surfaces A: Physicochemical and Engineering Aspects, 2002, 211(2): 275-284
    [4] Wang Baohui, Chen Ying, Liu Shuizhi, et al. Photocatalytical visbreaking of wastewater produced from polymer flooding in oilfields. Colloids and Surfaces A: Physicochemical and Engineering Aspects, 2006, 287(1-3): 170-174
    [5] 刘江红, 郭城. 化学药剂在三元复合驱采出水处理中的应用. 广东化工, 2010, 37(2): 83-84 Liu Jianghong, Guo Cheng. Application of chemical agents to the treatment of ASP flooding produced water. Guangdong Chemical Industry, 2010, 37(2): 83-84 (in Chinese)
    [6] 蒋惠敏, 叶清, 朱南文. 现场三元复合驱采出污水理化性质及沉降特性研究. 中国农村水利水电, 2008, (8): 40-43
    [7] 杨清香, 王哲. 酵母菌在自然界中的生态分布及功能. 环境科学与技术, 2009, 32(4): 86-91 Yang Qingxiang, Wang Zhe. Distribution and function of yeast in eco-environments. Environmental Science & Technology, 2009, 32(4): 86-91 (in Chinese)
    [8] Zheng Shaokui, Yang Min, Park Y. H., et al. Washout of a yeast population during continuous treatment of salad-oil-manufacturing wastewater. Bioresource Technology, 2003, 86(3): 235-237
    [9] Shokrollahzadeh S., Azizmohseni F., Golmohammad F., et al. Biodegradation potential and bacterial diversity of a petrochemical wastewater treatment plant in Iran. Bioresource Technology, 2008, 99(14): 6127-6133
    [10] 吕文洲, 刘英, 朱建林. 不同酵母菌组合处理含油废水的效能及酵母菌群落结构研究. 环境科学, 2008, 29(9): 2488-2492 Lü Wenzhou, Liu Ying, Zhu Jianlin. Efficiency and yeast community structure of oil-containing wastewater treatment system inoculated by different yeast strains complex. Environmental Science, 2008, 29(9): 2488-2492 (in Chinese)
    [11] 杨清香, 李玉慧, 俞宁, 等. 酵母菌生物膜系统对印染废水的中试处理研究. 工业水处理, 2009, 29(2): 52-55 Yang Qingxiang, Li Yuhui, Yu Ning, et al. Research on the pilot test of the treatment of printing and dyeing wastewater by the yeast biofilm reactor. Industrial Water Treatment, 2009, 29(2): 52-55 (in Chinese)
    [12] 顾军. 砂滤预处理与超滤膜组合工艺处理太湖原水的研究. 污染防治技术, 2010, 23(4): 13-16 Gu Jun. Study on the of raw water treatment of from Taihu Lake by using sand leach Pretreatment and ultrafiltration membrane combination process. Pollution Control Technology, 2010, 23 (4): 13-16 (in Chinese)
    [13] 张炳虎, 蒋进元, 周岳溪, 等. 二级A/O对腈纶废水强化处理的中试研究. 工业水处理, 2012, 32(10): 31-34 Zhang Binghu, Jiang Jinyuan, Zhou Yuexi, et al. Study on the strengthened treatment of acrylic fiber wastewater by two-grade A/O. Industrial Water Treatment, 2012, 32(10): 31-34 (in Chinese)
    [14] 汪严明, 杨敏, 郑少奎, 等. 用酵母菌处理油田钻井废水的研究. 环境科学, 2002, 23(5): 72-75 Wang Yanming, Yang Min, Zheng Shaokui, et al. Treatment of drilling wastewater from oil field by using yeast. Environmental Science, 2002, 23(5): 72-75 (in Chinese)
