倒置AAO-MBR处理黑水

,  ,

downloadPDF

上一篇

下一篇

张静, 唐贤春, 陈洪斌. 倒置AAO-MBR处理黑水[J]. 环境工程学报, 2016, 10(7): 3657-3663. doi: 10.12030/j.cjee.201507104
引用本文: 张静, 唐贤春, 陈洪斌. 倒置AAO-MBR处理黑水[J]. 环境工程学报, 2016, 10(7): 3657-3663. doi: 10.12030/j.cjee.201507104
shu
ZHANG Jing, TANG Xianchun, CHEN Hongbin. Black water treatment with process of reversed AAO-MBR[J]. Chinese Journal of Environmental Engineering, 2016, 10(7): 3657-3663. doi: 10.12030/j.cjee.201507104
Citation: ZHANG Jing, TANG Xianchun, CHEN Hongbin. Black water treatment with process of reversed AAO-MBR[J]. Chinese Journal of Environmental Engineering, 2016, 10(7): 3657-3663. doi: 10.12030/j.cjee.201507104
shu

倒置AAO-MBR处理黑水

  • 1.

    同济大学环境科学与工程学院, 上海 200092

  • 2.

    上海电气集团股份有限公司中央研究院, 上海 200070

  • 基金项目:

    科技部国际合作重点课题(2012DFG91380,2014DFA91650)

  • 中图分类号: X703

Black water treatment with process of reversed AAO-MBR

  • 1.

    College of Environmental Science and Engineering, Tongji University, Shanghai 200092, China

  • 2.

    Shanghai Electrical Group Co.Ltd.Central Academy, Shanghai 200070, China

  • Fund Project:

  • 摘要: 针对黑水污染物浓度高、悬浮成分多、碳氮磷比例失调等问题,小试条件下探索了采用倒置AAO-MBR工艺处理黑水的技术可行性,开展了水温、水力停留时间、外加碳源和溶解氧对主要污染物去除的影响。结果表明:冬季低温、HRT为42 h与夏秋季HRT为31 h的除污效果相近,出水的COD、氨氮、TN分别为110、26.7和104.5 mg·L-1;碱度是影响氨氮去除效率的最主要因素;HRT为31 h条件下,未加外碳源(C/N为3.14)时,COD、氨氮、TN平均去除率分别为83.8%、88.2%和52.9%,磷酸盐没有去除效果;外加碳源至C/N为4.63,COD、氨氮、TN和磷酸盐的平均去除率分别提高到93.4%、98.1%、91.3%和20.7%;随着运行时间的延长,MBR出水COD呈下降趋势,平均达到56 mg·L-1,达到一级B排放标准;好氧区的DO控制0.2~0.4 mg·L-1时生物脱氮效率较佳。
    Abstract: Black water consists of a mixture of feces,urine,toilet paper,and transportation water.It contains high amounts of organic SS and has low ratios of C/N/P.In this study,bench-scale experiments treating blackwater by the reversed AAO-MBR process were implemented,and the effects of temperature,HRT,adding external carbon nutrients,and DO on the removal efficiency were studied.The following results were obtained:for decontamination under the conditions of hypothermia,HRT=42 h,under the conditions of moderate temperature,HRT=31 h,which were close,and effluent COD,NH3-N,and TN were 110,26.7,and 104.5 mg·L-1,respectively.Ammonia removal was affected by alkalinity shortage.Under the moderate temperature conditions HRT=31 h without adding any external carbon nutrients(C/N=3.14),average removal efficiencies of COD,ammonia,and TN were 83.8%,88.2%,and 52.9%,respectively.There was no phosphate removal efficiency.When adding an external carbon source(sodium acetate) to increase the ratio of C/N of blackwater to 4.63,the average removal efficiencies of COD,ammonia,TN,and phosphate were 93.4%,98.1%,91.3%,and 20.7%,respectively.Effluent COD decreased with the system running,and under the best conditions effluent COD was 56 mg·L-1,which nearly met the 1st B discharge standard.Biological nitrogen removal remained optimal within the DO range of 0.2 to 0.4 mg·L-1 in the aerobic area.
  • 加载中
  • [1] 郑永菊,陈洪斌,何群彪.黑水处理与资源化进展.中国沼气,2008,26(5):9-13ZHENG Yongju,CHEN Hongbin,HE Qunbiao.A review on blackwater treatment and resourcization.China Biogas,2008,26(5):9-13(in Chinese)
    [2] 阮久丽,于凤,陈洪斌,等.生活污水分类收集处理的探讨.中国给水排水,2010,26(8):25-29RUAN Jiuli,YU Feng,CHEN Hongbin,et al.Discussion on categorized collection and quality-based treatment of domestic sewage.China Water & Wastewater,2010,26(8):25-29(in Chinese)
    [3] ZEEMAN G.,LETTINGA G.The role of anaerobic digestion of domestic sewage in closing the water and nutrient cycle at community level.Water Science and Technology,1999,39(5):187-194(in Chinese)
    [4] 李辰.黑水的处理与资源化研究.上海:同济大学硕士学位论文,2013LI Chen.The research on the treatment and reutilization of the blackwater.Shanghai:Master Dissertation of Tongji University,2013(in Chinese)
    [5] 张静.黑水好氧处理技术研究.上海:同济大学硕士学位论文,2014ZHANG Jing.The research on the aerobic treatment of black water.Shanghai:Master Dissertation of Tongji University,2014(in Chinese)
    [6] 徐慧芳,樊耀波.膜生物反应器在粪便污水处理中的研究与应用.环境污染治理技术与设备,2002,3(6):75-81XU Huifang,FAN Yaobo.The study and application of membrane bio-reactor for black water and night soil treatment.Techniques and Equipment for Environmental Pollution Control,2002,3(6):75-81(in Chinese)
    [7] HOCAOGLU S.M.,INSEL G.,COKGOR E.U.,et al.Effect of low dissolved oxygen on simultaneous nitrification and denitrification in a membrane bioreactor treating black water.Bioresource Technology,2011,102(6):4333-4340
    [8] HOCAOGLU S.M.,INSEL G.,COKGOR E.U.,et al.Effect of sludge age on simultaneous nitrification and denitrification in membrane bioreactor.Bioresource Technology,2011,102(12):6665-6672
    [9] 侯立安,郭珍珍,左莉.小型污水处理与回用技术及装置.北京:化学工业出版社,2003
    [10] 张道勇,王鹤平.中国实用肥料学.上海:上海科学技术出版社,1997
    [11] 陈朱蕾.国内外城市粪便处理系统模式比较的研究.武汉城市建设学院学报,2000,17(1):48-51
    [12] 王斌.粪便污水处理技术和机械设备应用.环境卫生工程,2004,12(2):123-125 WANG Bin.Application of nightsoil sewage treatment technology and machine.Environmental Sanitation Engineering,2004,12(2):123-125(in Chinese)
    [13] CHIEMCHAISRI C.,YAMAMOTO K.,VIGNESWARAN S.Household membrane bioreactor in domestic wastewater treatment.Water Science and Technology,1993,27(1):171-178
    [14] SHAMMAS N.K.Interactions of temperature,pH,and biomass on the nitrification process.Journal Water Pollution Control Federation,1986,58(1):52-59
    [15] 郑兴灿,李亚新.污水除磷脱氮技术.北京:中国建筑工业出版社,1998:37-41
    [16] HOCAOGLU S.M.,ORHON D.Fate of soluble residual organics in membrane bioreactor.Journal of Membrane Science,2010,364(1/2):65-74
    [17] KNERR H.,RECHENBURG A.,KISTEMANNETAL T.,et al.Performance of a MBR for the treatment of blackwater.Water Scicence and Technology,2011,63(6):1247-1254
  • 加载中
WeChat 点击查看大图
计量
  • 文章访问数:  3138
  • HTML全文浏览数:  2655
  • PDF下载数:  627
  • 施引文献:  0
出版历程
  • 收稿日期:  2015-08-24
  • 刊出日期:  2016-07-06
张静, 唐贤春, 陈洪斌. 倒置AAO-MBR处理黑水[J]. 环境工程学报, 2016, 10(7): 3657-3663. doi: 10.12030/j.cjee.201507104
引用本文: 张静, 唐贤春, 陈洪斌. 倒置AAO-MBR处理黑水[J]. 环境工程学报, 2016, 10(7): 3657-3663. doi: 10.12030/j.cjee.201507104
shu
ZHANG Jing, TANG Xianchun, CHEN Hongbin. Black water treatment with process of reversed AAO-MBR[J]. Chinese Journal of Environmental Engineering, 2016, 10(7): 3657-3663. doi: 10.12030/j.cjee.201507104
Citation: ZHANG Jing, TANG Xianchun, CHEN Hongbin. Black water treatment with process of reversed AAO-MBR[J]. Chinese Journal of Environmental Engineering, 2016, 10(7): 3657-3663. doi: 10.12030/j.cjee.201507104
shu

倒置AAO-MBR处理黑水

  • 1.  同济大学环境科学与工程学院, 上海 200092
  • 2.  上海电气集团股份有限公司中央研究院, 上海 200070
  • 收稿日期:  2015-08-24
基金项目:

科技部国际合作重点课题(2012DFG91380,2014DFA91650)

摘要: 针对黑水污染物浓度高、悬浮成分多、碳氮磷比例失调等问题,小试条件下探索了采用倒置AAO-MBR工艺处理黑水的技术可行性,开展了水温、水力停留时间、外加碳源和溶解氧对主要污染物去除的影响。结果表明:冬季低温、HRT为42 h与夏秋季HRT为31 h的除污效果相近,出水的COD、氨氮、TN分别为110、26.7和104.5 mg·L-1;碱度是影响氨氮去除效率的最主要因素;HRT为31 h条件下,未加外碳源(C/N为3.14)时,COD、氨氮、TN平均去除率分别为83.8%、88.2%和52.9%,磷酸盐没有去除效果;外加碳源至C/N为4.63,COD、氨氮、TN和磷酸盐的平均去除率分别提高到93.4%、98.1%、91.3%和20.7%;随着运行时间的延长,MBR出水COD呈下降趋势,平均达到56 mg·L-1,达到一级B排放标准;好氧区的DO控制0.2~0.4 mg·L-1时生物脱氮效率较佳。
